Page 5377 of 5598

INFINITI QX56 2011 Factory Service Manual MID SUN GEAR, REAR SUN GEAR, HIGH AND LOW REVERSE CLUTCH HUB TM-289 < UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B] C EF G H I J K L M A B TM N O P 8. Remove seal rings from mid sun gear. AssemblyIN

Page 5378 of 5598

INFINITI QX56 2011 Factory Service Manual TM-290 < UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B] MID SUN GEAR, REAR SUN GEAR, HIGH AND LOW REVERSE CLUTCH HUB 4. Install rear sun gear assembly to mid sun gear assembly. 5. Install needle bear

Page 5379 of 5598

INFINITI QX56 2011 Factory Service Manual MID SUN GEAR, REAR SUN GEAR, HIGH AND LOW REVERSE CLUTCH HUB TM-291 < UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B] C EF G H I J K L M A B TM N O P a. Hold mid sun gear and turn rear sun gear. b. Ch

Page 5380 of 5598

INFINITI QX56 2011 Factory Service Manual TM-292 < UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B] HIGH AND LOW REVERSE CLUTCH HIGH AND LOW REVERSE CLUTCH Exploded ViewINFOID:0000000006226936 DisassemblyINFOID:0000000006226937 1. Remove bearin

Page 5381 of 5598

INFINITI QX56 2011 Factory Service Manual HIGH AND LOW REVERSE CLUTCHTM-293 < UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B] C EF G H I J K L M A B TM N O P AssemblyINFOID:0000000006226938 1. Install high and low reverse clutch drive plates,

Page 5382 of 5598

INFINITI QX56 2011 Factory Service Manual TM-294 < UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B] DIRECT CLUTCH DIRECT CLUTCH Exploded ViewINFOID:0000000006226940 DisassemblyINFOID:0000000006226941 1. Remove snap rings from direct clutch drum

Page 5383 of 5598

INFINITI QX56 2011 Factory Service Manual DIRECT CLUTCHTM-295 < UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B] C EF G H I J K L M A B TM N O P 2. Install snap rings in direct clutch drum using a flat-bladed screw- driver. CAUTION:  Be caref

Page 5384 of 5598

INFINITI QX56 2011 Factory Service Manual TM-296 < SERVICE DATA AND SPECIFICATIONS (SDS) [7AT: RE7R01B] SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) General SpecificationIN
