INTELLIGENT KEY
Component Function CheckINFOID:0000000006225961
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT-III.
2. Select “RKE OPE COUN1” in “DATA MONITOR” mode.
3. Check that the function operates normall y according to the following conditions.
Is the inspection result normal?
YES >> Intelligent Key is OK.
NO >> Refer to DLK-145, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225962
1.CHECK INTELLIGENT KEY BATTERY
Check by connecting a resistance (approximately 300 Ω) so that the
current value becomes about 10 mA. Refer to DLK-260, "
Removal
and Installation".
Is the measurement value within the specification?
YES >> Replace Intelligent Key.
NO >> Replace Intelligent Key battery.
Monitor item Condition
RKE OPE COUN1 Check that the numerical value is changing while operating on the Intelligent Key.
Standard : Approx. 2.5 - 3.0V
OCC0607D
Revision: 2010 May2011 QX56
Page 1682 of 5598
DLK-146
< DTC/CIRCUIT DIAGNOSIS >
COMBINATION METER BUZZER
COMBINATION METER BUZZER
Component Function CheckINFOID:0000000006225963
1.CHECK FUNCTION
1. Select “INTELLIGE NT KEY” of “BCM” using CONSULT-III.
2. Select “INSIDE BUZZER ” in “ACTIVE TEST” mode.
3. Touch “Key”, “Knob” or “Take Out” to check that it works normally.
Is the inspection result normal?
Yes >> Combination meter buzzer is OK.
No >> Refer to DLK-146, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225964
1.CHECK COMBINATION METER BUZZER CIRCUIT
Refer to WCS-40, "
Component Function Check".
Is the inspection result normal?
Ye s > > G O T O 2 .
No >> Repair or replace the malfunctioning parts.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 1683 of 5598
INFORMATION DISPLAYDLK-147
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
INFORMATION DISPLAY
Component Function CheckINFOID:0000000006225965
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT-III.
2. Select “LCD” in “ACTIVE TEST” mode.
3. Check each warning display on meter display.
Is the inspection result normal?
YES >> Information display is OK.
NO >> Refer to DLK-147, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225966
1.CHECK COMBINATION METER
Refer to MWI-29, "
On Board Diagnosis Function".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 1684 of 5598
DLK-148
< DTC/CIRCUIT DIAGNOSIS >
KEY WARNING LAMP
KEY WARNING LAMP
Component Function CheckINFOID:0000000006225967
1.CHECK FUNCTION
1. Select “INTELLIGE NT KEY” of “BCM” using CONSULT-III.
2. Select “INDICATOR” in “ACTIVE TEST” mode.
3. Touch “KEY IND” or “KEY ON” to check that it works normally.
Is the inspection result normal?
YES >> Key warning lamp is OK.
NO >> Refer to DLK-148, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225968
1.CHECK KEY WARNING LAMP
Refer to MWI-29, "
On Board Diagnosis Function".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 1685 of 5598
HAZARD FUNCTIONDLK-149
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD FUNCTION
Component Function CheckINFOID:0000000006225969
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT-III.
2. Select “FLASHER” in “ACTIVE TEST” mode.
3. Touch “LH” or “RH” to check that it works normally.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-149, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225970
1.CHECK HAZARD SWITCH CIRCUIT
Refer to EXL-105, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 1686 of 5598

DLK-150
< DTC/CIRCUIT DIAGNOSIS >
AUTOMATIC BACK DOOR CLOSE SWITCH
AUTOMATIC BACK DOOR CLOSE SWITCH
Component Function CheckINFOID:0000000006225971
1.CHECK FUNCTION
1. Select “AUTOMATIC BACK DOOR CONTROL UNIT” using CONSULT-III.
2. Select “BK DOOR CL SW” in “DATA MONITOR” mode.
3. Check that the function operates normall y according to the following conditions.
Is the inspection result normal?
YES >> Automatic back door close switch is OK.
NO >> Refer to DLK-150, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225972
1.CHECK AUTOMATIC BACK DOOR CLOSE SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect automatic back door close switch connector.
3. Check voltage between automatic back door close switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK AUTOMATIC BACK DOOR CLOSE SWITCH CIRCUIT
1. Disconnect automatic back door control module connector.
2. Check continuity between automatic back door control module harness connector and automatic back
door close switch harness connector.
3. Check continuity between automatic back door control module harness connector and ground.
Is the inspection result normal?
YES >> Replace automatic back door control module. Refer to DLK-262, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK AUTOMATIC BACK DOOR CLOSE SWITCH GROUND CIRCUIT
Check continuity between automatic back door close switch harness connector and ground.
Monitor item Condition Status
BK DOOR CL SW Automatic back door close switch Pressed ON
Released OFF
(+)
(–)Vol tag e
(Approx.)
Automatic back door close switch
Connector Terminal D158 1 Ground Battery voltage
Automatic back door control module Automatic back door close switch Continuity
Connector Terminal Connector Terminal
B26 4 D158 1 Existed
Automatic back door control module GroundContinuity
Connector Terminal
B26 4 Not existed
Revision: 2010 May2011 QX56
Page 1687 of 5598

AUTOMATIC BACK DOOR CLOSE SWITCHDLK-151
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK AUTOMATIC BACK DOOR CLOSE SWITCH
Refer to DLK-151, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace automatic back door close switch.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006225973
1.CHECK AUTOMATIC BACK DOOR CLOSE SWITCH
1. Turn ignition switch OFF.
2. Disconnect automatic back door close switch connector.
3. Check continuity between automatic back door close switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace automatic back door close switch.
Automatic back door close switch GroundContinuity
Connector Terminal
D158 2 Existed
Automatic back door close switch Condition Continuity
Te r m i n a l
12 Automatic back door
close switch Pressed Existed
Released Not existed
Revision: 2010 May2011 QX56
Page 1688 of 5598

DLK-152
< DTC/CIRCUIT DIAGNOSIS >
AUTOMATIC BACK DOOR MAIN SWITCH
AUTOMATIC BACK DOOR MAIN SWITCH
Component Function CheckINFOID:0000000006225974
1.CHECK FUNCTION
1. Select “AUTOMATIC BACK DOOR CONTROL UNIT” using CONSULT-III.
2. Select “MAIN SW” in “DATA MONITOR” mode.
3. Check that the function operates normall y according to the following conditions.
Is the inspection result normal?
YES >> Automatic back door main switch is OK.
NO >> Refer to DLK-152, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225975
1.CHECK AUTOMATIC BACK DOOR MAIN SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect automatic back door main switch connector.
3. Check voltage between automatic back door main switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK AUTOMATIC BACK DO OR MAIN SWITCH CIRCUIT
1. Disconnect automatic back door control module connector.
2. Check continuity between automatic back door control module harness connector and automatic back
door main switch harness connector.
3. Check continuity between automatic back door control module connector and ground.
Is the inspection result normal?
YES >> Replace automatic back door control module. Refer to DLK-262, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK AUTOMATIC BACK DOOR MAIN SWITCH GROUND CIRCUIT
Check continuity between automatic back door main switch connector and ground.
Monitor item Condition Status
MAIN SW Automatic back door main switch ON ON
OFF OFF
(+)
(–)Voltag e
(Approx.)
Automatic back door main switch
Connector Terminal M110 1 Ground Battery voltage
Automatic back door control module Automatic back door main switch Continuity
Connector Terminal Connector Terminal
B26 17 M110 1 Existed
Automatic back door control module GroundContinuity
Connector Terminal
B26 17 Not existed
