Page 1145 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-180
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U0415 VDC CAN 1
U0415 VDC CAN 1
DTC LogicINFOID:0000000006228141
DTC DETECTION LOGIC
NOTE:
If DTC “U0415” is detected along with DTC “U
1000”, first dia

Page 1146 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
U0428 STRG SEN CAN 2DAS-181
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U0428 STRG SEN CAN 2
DTC LogicINFOID:0000000006228143
DTC DETECTION LOGIC
NOTE:
If DTC “U0428” is det

Page 1147 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-182
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
ADAS CONTROL UNIT
ADAS CONTROL UNIT : DescriptionINFOID:0000000006228145
CAN COMMUNICATION
CAN (Controller Area Ne

DAS-182
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
ADAS CONTROL UNIT
ADAS CONTROL UNIT : DescriptionINFOID:0000000006228145
CAN COMMUNICATION
CAN (Controller Area Network) is a serial communication
line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control units , and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H, CAN-L) allowing a hi gh rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads the required data only.
CAN communication signal chart. Refer to LAN-28, "
CAN COMMUNICATION SYSTEM : CAN Communica-
tion Signal Chart".
ITS COMMUNICATION
ITS communication is a multiplex communication system . This enables the system to transmit and receive
large quantities of data at high speed by connecting control units with 2 communication lines.
ITS communication lines adopt twisted-pair line st yle (two lines twisted) for noise immunity.
ADAS CONTROL UNIT : DTC LogicINFOID:0000000006228146
DTC DETECTION LOGIC
NOTE:
If “U1000” is detected, first diagnose the CAN communication system.
ADAS CONTROL UNIT : Diagnosis ProcedureINFOID:0000000006228147
1.PERFORM THE SELF-DIAGNOSIS
1. Turn the ignition switch ON.
2. Turn the DCA system ON, and then wait for 30 seconds or more.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “U1000” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected as the current malfunction?
YES >> Refer to LAN-18, "Trouble Diagnosis Flow Chart".
NO >> Refer to GI-40, "
Intermittent Incident".
ACCELERATOR PEDAL ACTUATOR
ACCELERATOR PEDAL ACTUATOR : DescriptionINFOID:0000000006223619
ITS COMMUNICATION
ITS communication is a multiplex communication system . This enables the system to transmit and receive
large quantities of data at high speed by connecting control units with 2 communication lines
ITS communication lines adopt twisted-pair line st yle (two lines twisted) for noise immunity.
ACCELERATOR PEDAL ACTUATOR : DTC LogicINFOID:0000000006223620
DTC DETECTION LOGIC
DTC
(On board
display) Trouble diagnosis name DTC detecting condition Possible causes
U1000 (100) CAN COMM CIRCUIT If ADAS control unit is not transmitting or receiv-
ing CAN communication signal or ITS communi-
cation signal for 2 seconds or more CAN communication system
ITS communication system
Revision: 2010 May2011 QX56

Page 1148 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
U1000 CAN COMM CIRCUITDAS-183
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
ACCELERATOR PEDAL ACTUATOR : Diagnosis ProcedureINFOID:0000000006223621
1.PERFORM THE SELF-DIAGNOSIS
1.

Page 1149 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-184
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
ADAS CONTROL UNIT
ADAS CONTROL UNIT : DescriptionINFOID:0000000006228148
CAN controller controls the communica

DAS-184
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
ADAS CONTROL UNIT
ADAS CONTROL UNIT : DescriptionINFOID:0000000006228148
CAN controller controls the communication of CA
N communication signal and ITS communication signal, and
the error detection.
ADAS CONTROL UNIT : DTC LogicINFOID:0000000006228149
DTC DETECTION LOGIC
ADAS CONTROL UNIT : Diagnosis ProcedureINFOID:0000000006228150
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn the DCA system ON.
2. Perform “All DTC Reading” with CONSULT-III.
3. Check if the “U1010” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1010” detected as the current malfunction?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> INSPECTION END
ACCELERATOR PEDAL ACTUATOR
ACCELERATOR PEDAL ACTUATOR : DescriptionINFOID:0000000006223625
CAN controller controls the communication of ITS communication signal and the error detection.
ACCELERATOR PEDAL ACTUATOR : DTC LogicINFOID:0000000006223626
DTC DETECTION LOGIC
ACCELERATOR PEDAL ACTUATOR : Diagnosis ProcedureINFOID:0000000006223627
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn the DCA system ON.
2. Perform “All DTC Reading” with CONSULT-III.
3. Check if the “U1010” is detected as the current malfunction in “Self Diagnostic Result” of “ACCELE
PEDAL ACT”.
Is
“U1010” detected as the current malfunction?
YES >> Replace the accelerator pedal actuator. Refer to DAS-213, "Exploded View".
NO >> INSPECTION END
DTC
(On board display) Trouble diagnosis name DTC detecting condition Possible causes
U1010 (110) CONTROL UNIT (CAN) If ADAS control unit detects malfunction by
CAN controller initial diagnosis ADAS control unit
DTC Trouble diagnosis name DTC detecting condition Possible causes
U1010 CONTROL UNIT (CAN) If accelerator pedal actuator detects malfunc-
tion by CAN controller initial diagnosis Accelerator pedal actuator
Revision: 2010 May2011 QX56

Page 1150 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
U150B ECM CAN 3DAS-185
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U150B ECM CAN 3
DTC LogicINFOID:0000000006228151
DTC DETECTION LOGIC
NOTE:
If DTC “U150B” is detected alon

Page 1151 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-186
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U150C VDC CAN 3
U150C VDC CAN 3
DTC LogicINFOID:0000000006228153
DTC DETECTION LOGIC
NOTE:
If DTC “U150C” is detected along with DTC “U
1000”, first dia

Page 1152 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
U150D TCM CAN 3DAS-187
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U150D TCM CAN 3
DTC LogicINFOID:0000000006228155
DTC DETECTION LOGIC
NOTE:
If DTC “U150D” is detected alon
