SEC-138
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2110 SHIFT POSITION/CLUTCH INTERLOCK SWITCH
B2110 SHIFT POSITION/C
LUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000006226302
DTC DETECTION LOGIC
NOTE:
If DTC B2110 is displayed with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to PCS-
28, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Shift selector lever to the N position and wait 1 second or more.
4. Shift selector lever to any position other than P and N, and wait 1 second or more.
5. Check DTC in “Self Diagnostic Result” mode of “IPDM E/R” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-138, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226303
1.CHECK DTC OF BCM
Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BCS-57, "DTCIndex".
NO >> GO TO 2.
2.CHECK DTC OF TCM
Check DTC in “Self Diagnostic Result ” mode of “TCM” using CONSULT-III.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to TM-78, "DTC Index".
NO >> GO TO 3.
3.CHECK IPDM E/R SIGNAL CIRCUIT OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Disconnect A/T assembly connector.
4. Check continuity between IPDM E/R harnes s connector and A/T assembly harness connector.
5. Check continuity between IP DM E/R harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2110 INTER LOCK/PNP SW OFF There is a difference between P/N position
signal from TCM and P/N position signal from
BCM (CAN). Harness or connectors
(CAN communication line is open or
shorted.)
Harness or connectors (TCM circuit is open or shorted.)
A/T assembly (TCM)
IPDM E/R
BCM
IPDM E/R A/T assembly Continuity
Connector Terminal Connector Terminal
E15 48 F51 9 Existed
Revision: 2010 May2011 QX56
Page 4746 of 5598
B2110 SHIFT POSITION/CLUTCH INTERLOCK SWITCHSEC-139
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace harness.
(+)
(–) Continuity
IPDM E/R
Connector Terminal E15 48 Ground Not existed
Revision: 2010 May2011 QX56
Page 4747 of 5598
SEC-140
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HEADLAMP FUNCTION
HEADLAMP FUNCTION
Component Function CheckINFOID:0000000006226719
1.CHECK FUNCTION
1. Perform “HEAD LAMP(HI)” in “ACTIVE TEST” m ode of “THEFT ALM” of “BCM” using CONSULT-III.
2. Check headlamps operation.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Refer to SEC-140, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006226720
1.CHECK HEADLAMP FUNCTION
Refer to EXL-86, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Te s t i t e m D e s c r i p t i o n
HEAD LAMP (HI) ON
Headlamps (Hi) Light
OFF Do not light
Revision: 2010 May2011 QX56
Page 4748 of 5598
![INFINITI QX56 2011 Factory Service Manual
HOOD SWITCHSEC-141
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
HOOD SWITCH
Component Function CheckINFOID:0000000006226305
1.CHECK FUNCTION
1. Select “ INFINITI QX56 2011 Factory Service Manual
HOOD SWITCHSEC-141
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
HOOD SWITCH
Component Function CheckINFOID:0000000006226305
1.CHECK FUNCTION
1. Select “](/manual-img/42/57033/w960_57033-4747.png)
HOOD SWITCHSEC-141
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
HOOD SWITCH
Component Function CheckINFOID:0000000006226305
1.CHECK FUNCTION
1. Select “HOOD SW” in “Data Monitor” m ode of “IPDM E/R” using CONSULT-III.
2. Check “HOOD SW” indication under the following condition.
Is the indication normal?
YES >> Hood switch is OK.
NO >> Go to SEC-141, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006226306
1.CHECK HOOD SWITCH SIGNAL CIRCUIT 1
1. Turn ignition switch OFF.
2. Disconnect hood switch connector.
3. Check voltage between hood switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK HOOD SWITCH SIGNAL CIRCUIT 2
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R har ness connector and hood switch harness connector.
3. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK HOOD SWITCH GROUND CIRCUIT
Check continuity between hood switch harness connector and ground.
Monitor item Condition Indication
HOOD SW Hood Open ON
Close OFF
(+) (–)Voltage (V)
(Approx.)
Hood switch
Connector Terminal E57 1 Ground 12
IPDM E/R Hood switch Continuity
Connector Terminal Connector Terminal
E13 32 E57 1 Existed
IPDM E/R GroundContinuity
Connector Terminal
E13 32 Not existed
Hood switch GroundContinuity
Connector Terminal
E57 2 Existed
Revision: 2010 May2011 QX56
Page 4749 of 5598
SEC-142
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HOOD SWITCH
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK HOOD SWITCH
Refer to SEC-142, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace hood switch.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006226307
1.CHECK HOOD SWITCH
1. Turn ignition switch OFF.
2. Disconnect hood switch connector.
3. Check continuity between hood switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace hood switch.
Hood switch Condition Continuity
Te r m i n a l
1 2 Hood switch Press Not existed
Release Existed
Revision: 2010 May2011 QX56
Page 4750 of 5598
![INFINITI QX56 2011 Factory Service Manual
HORN FUNCTIONSEC-143
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
HORN FUNCTION
Component Function CheckINFOID:0000000006226308
1.CHECK FUNCTION 1
1. Disc INFINITI QX56 2011 Factory Service Manual
HORN FUNCTIONSEC-143
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
HORN FUNCTION
Component Function CheckINFOID:0000000006226308
1.CHECK FUNCTION 1
1. Disc](/manual-img/42/57033/w960_57033-4749.png)
HORN FUNCTIONSEC-143
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
HORN FUNCTION
Component Function CheckINFOID:0000000006226308
1.CHECK FUNCTION 1
1. Disconnect vehicle security horn relay.
2. Perform “VEHICLE SECURITY HORN” in “ACTIVE TEST” mode of “THEFT ALM” of “BCM” using CON\
-
SULT-III.
3. Check the horn operation.
Is the operation normal?
YES >> GO TO 2.
NO >> Go to SEC-143, "
DiagnosisProcedure".
2.CHECK FUNCTION 2
1. Reconnect vehicle security horn relay.
2. Disconnect horn relay.
3. Perform “VEHICLE SECURITY HORN” in “ACTIVE TEST” mode of “THEFT ALM” of “BCM” using CON\
-
SULT-III.
4. Check the horn operation.
Is the operation normal?
YES >> INSPECTION END
NO >> Go to SEC-143, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006226309
1.INSPECTION START
Perform inspection in accordance with procedure that confirms malfunction.
Which procedure confirms malfunction?
Component Function Check 1>>GO TO 2.
Component Function Check 2>>GO TO 4.
2.CHECK HORN FUNCTION
Check that horns function properly using horn switch.
Do horns sound?
YES >> GO TO 3.
NO >> Check horn circuit. Refer to HRN-3, "
Wiring Diagram".
3.CHECK HORN CONTROL CIRCUIT
1. Disconnect horn relay.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R har ness connector and horn relay harness connector.
4. Check continuity between IPDM E/R harness connector and ground.
Test item Description
VEHICLE SECURITY HORN ON Horn Sounds (for 0.5 sec)
Test item Description
VEHICLE SECURITY HORN ON Vehicle security horn Sounds (for 0.5 sec)
IPDM E/R Horn relay Continuity
Connector Terminal Connector Terminal
E13 34 E5 1 Existed
Revision: 2010 May2011 QX56
Page 4751 of 5598
![INFINITI QX56 2011 Factory Service Manual
SEC-144
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HORN FUNCTION
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to
PCS-32, "Removal and Installation".
NO >> Repair or re INFINITI QX56 2011 Factory Service Manual
SEC-144
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HORN FUNCTION
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to
PCS-32, "Removal and Installation".
NO >> Repair or re](/manual-img/42/57033/w960_57033-4750.png)
SEC-144
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HORN FUNCTION
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to
PCS-32, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK VEHICLE SECURITY HORN RELAY POWER SUPPLY
1. Disconnect vehicle security horn relay.
2. Check voltage between vehicle security horn relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO-1 >> Check 10 A fuse [No. 36 located in the fuse block (J/B)].
NO-2 >> Check harness for open or short between vehicle security horn relay and fuse.
5.CHECK VEHICLE SECURITY HORN CONTROL CIRCUIT
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R harness connec tor and vehicle security horn relay harness connec-
tor.
3. Check continuity between IP DM E/R harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace harness.
6.CHECK VEHICLE SECURITY HORN CIRCUIT
1. Disconnect vehicle security horn connector.
2. Check continuity between vehicle security horn relay harness connector and vehicle security horn har-
ness connector.
3. Check continuity between vehicle secu rity horn relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
IPDM E/R GroundContinuity
Connector Terminal
E13 34 Not existed
(+) (–)Voltage (V)
(Approx.)
Vehicle security horn relay
Connector Terminal E124 1 Ground Battery voltage
IPDM E/R Vehicle se curity horn relay
Continuity
Connector Terminal Connector Terminal
E1334E1243Existed
IPDM E/R GroundContinuity
Connector Terminal
E13 34 Not existed
Vehicle security horn re lay Vehicle security horn
Continuity
Connector Terminal Connector Terminal
E124 2 E125 1 Existed
Vehicle security horn relay GroundContinuity
Connector Terminal
E124 2 Not existed
Revision: 2010 May2011 QX56
Page 4752 of 5598
HORN FUNCTIONSEC-145
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
NO >> Repair or replace harness.
7.CHECK VEHICLE SECURITY HORN RELAY
Refer to SEC-145, "
Component Inspection".
Is the inspection result normal?
YES >> Replace vehicle security horn.
NO >> Replace vehicle security horn relay.
Component InspectionINFOID:0000000006248777
1.CHECK VEHICLE SECURITY HORN RELAY
1. Turn ignition switch OFF.
2. Disconnect vehicle security horn relay.
3. Check voltage between vehicle security horn relay terminal and ground under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace vehicle security horn relay.
(+)
(− ) Condition Voltage (V)
(Approx.)
Vehicle security horn relay
Te r m i n a l
2Ground 12 V direct current supply between terminals 1 and 3 12
No current supply 0
Revision: 2010 May2011 QX56
