Page 4905 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-112
< DTC/CIRCUIT DIAGNOSIS >
B1129 SIDE AIR BAG MODULE RH
B1129 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220052
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
W

Page 4906 of 5598

INFINITI QX56 2011 Factory Service Manual
B1129 SIDE AIR BAG MODULE RHSRC-113
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4907 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-114
< DTC/CIRCUIT DIAGNOSIS >
B1130 SIDE AIR BAG MODULE RH
B1130 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220054
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
W

SRC-114
< DTC/CIRCUIT DIAGNOSIS >
B1130 SIDE AIR BAG MODULE RH
B1130 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220054
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-114, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220055
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-114, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module RH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-114, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1130 SIDE MODULE RH
[VB-SHORT] Side air bag module RH circuit is shorted
to power supply circuit Disconnection of wiring harness and short
Malfunction in side air bag module RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4908 of 5598

INFINITI QX56 2011 Factory Service Manual
B1130 SIDE AIR BAG MODULE RHSRC-115
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4909 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-116
< DTC/CIRCUIT DIAGNOSIS >
B1131 SIDE AIR BAG MODULE RH
B1131 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220056
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
W

SRC-116
< DTC/CIRCUIT DIAGNOSIS >
B1131 SIDE AIR BAG MODULE RH
B1131 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220056
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-116, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220057
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-116, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module RH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-116, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1131 SIDE MODULE RH
[GND-SHORT] Side air bag module RH circuit is shorted
to ground Disconnection of wiring harness and short
Malfunction in side air bag module RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4910 of 5598

INFINITI QX56 2011 Factory Service Manual
B1131 SIDE AIR BAG MODULE RHSRC-117
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4911 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-118
< DTC/CIRCUIT DIAGNOSIS >
B1132 SIDE AIR BAG MODULE RH
B1132 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220058
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
W

SRC-118
< DTC/CIRCUIT DIAGNOSIS >
B1132 SIDE AIR BAG MODULE RH
B1132 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220058
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-118, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220059
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-118, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module RH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-118, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1132 SIDE MODULE RH
[SHORT] Side air bag module RH circuits are short-
ed to each other Disconnection of wiring harness and short
Malfunction in side air bag module RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4912 of 5598

INFINITI QX56 2011 Factory Service Manual
B1132 SIDE AIR BAG MODULE RHSRC-119
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> INSPECTION END
Revision: 2010 May2011 QX56
