Page 3569 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
AV BRANCH LINE CIRCUITLAN-149
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256292
1.CHECK CONNECTOR
1. INFINITI QX56 2011 Factory Service Manual
LAN
AV BRANCH LINE CIRCUITLAN-149
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256292
1.CHECK CONNECTOR
1.](/manual-img/42/57033/w960_57033-3568.png)
LAN
AV BRANCH LINE CIRCUITLAN-149
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256292
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (unit side and con- nector side).
- AV control unit
- Harness connector M222
- Harness connector M119
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of AV control unit.
2. Check the resistance between the AV control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the AV control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circui t of the AV control unit. Refer to AV-161, "
AV CONTROL UNIT :
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the AV control unit. Refer to AV-212, "Removal and Installation".
YES (Past error)>>Error was detected in the AV control unit branch line.
NO >> Repair the power supply and the ground circuit.
AV control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M210 90 74 Approx. 54 – 66
Revision: 2010 May2011 QX56
Page 3570 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-150
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
BCM BRANCH LINE CIRCUIT
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256293
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. INFINITI QX56 2011 Factory Service Manual
LAN-150
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
BCM BRANCH LINE CIRCUIT
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256293
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2.](/manual-img/42/57033/w960_57033-3569.png)
LAN-150
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
BCM BRANCH LINE CIRCUIT
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256293
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the BCM for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of BCM.
2. Check the resistance between the BCM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the BCM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the BCM. Refer to BCS-75, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the BCM. Refer to BCS-81, "Removal and Installation".
YES (Past error)>>Error was detected in the BCM branch line.
NO >> Repair the power supply and the ground circuit.
BCM harness connector Resistance (Ω)
Connector No. Terminal No.
M68 39 40 Approx. 54 – 66
Revision: 2010 May2011 QX56
Page 3571 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
CGW BRANCH LINE CIRCUIT (CAN COMMUNICATION CIRCUIT 1)LAN-151
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
CGW BRANCH LINE CI
RCUIT (CAN COMMUNICATION CIRCUIT 1)
D INFINITI QX56 2011 Factory Service Manual
LAN
CGW BRANCH LINE CIRCUIT (CAN COMMUNICATION CIRCUIT 1)LAN-151
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
CGW BRANCH LINE CI
RCUIT (CAN COMMUNICATION CIRCUIT 1)
D](/manual-img/42/57033/w960_57033-3570.png)
LAN
CGW BRANCH LINE CIRCUIT (CAN COMMUNICATION CIRCUIT 1)LAN-151
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
CGW BRANCH LINE CI
RCUIT (CAN COMMUNICATION CIRCUIT 1)
Diagnosis ProcedureINFOID:0000000006256294
1.CHECK DTC
Check DTC of the CAN gat eway with CONSULT-III.
Is U1010 or B2600 indicated?
YES >> Perform a diagnosis of the indicated DTC.
NO >> GO TO 2.
2.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the CAN gateway for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the terminal and connector.
3.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of CAN gateway.
2. Check the resistance between the CA N gateway harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 4.
NO >> Repair the CAN gateway branch line (CAN communication circuit 1). Refer to LAN-57, "
System
Diagram".
4.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the CAN gateway. Refer to LAN-116, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the CAN gateway. Refer to LAN-117, "Removal and Installation".
YES (Past error)>>Error was detected in the CAN gateway branch line (CAN communication circuit 1).
NO >> Repair the power supply and the ground circuit.
CAN gateway harness connector Resistance (Ω)
Connector No. Terminal No.
M125 1 7 Approx. 54 – 66
Revision: 2010 May2011 QX56
Page 3572 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-152
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
CGW BRANCH LINE CIRCUIT (CAN
COMMUNICATION CIRCUIT 2)
CGW BRANCH LINE CIRCUIT (CAN COMMUNICATION CIRCUIT 2)
Diagnosis ProcedureINFOID:000000000 INFINITI QX56 2011 Factory Service Manual
LAN-152
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
CGW BRANCH LINE CIRCUIT (CAN
COMMUNICATION CIRCUIT 2)
CGW BRANCH LINE CIRCUIT (CAN COMMUNICATION CIRCUIT 2)
Diagnosis ProcedureINFOID:000000000](/manual-img/42/57033/w960_57033-3571.png)
LAN-152
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
CGW BRANCH LINE CIRCUIT (CAN
COMMUNICATION CIRCUIT 2)
CGW BRANCH LINE CIRCUIT (CAN COMMUNICATION CIRCUIT 2)
Diagnosis ProcedureINFOID:0000000006256295
1.CHECK DTC
Check DTC of the CAN gateway with CONSULT-III.
Is U1010 or B2600 indicated?
YES >> Perform a diagnosis of the indicated DTC.
NO >> GO TO 2.
2.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors fo r damage, bend and loose connection (unit side and con-
nector side).
- CAN gateway
- Harness connector M19
- Harness connector B2
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the terminal and connector.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of CAN gateway.
2. Check the continuity between the CA N gateway harness connector terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair the CAN gateway branch line (CAN communication circuit 2). Refer to LAN-57, "
System
Diagram".
4.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circ uit of the CAN gateway. Refer to LAN-116, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the CAN gateway. Refer to LAN-117, "Removal and Installation".
YES (Past error)>>Error was detected in the CAN gateway branch line (CAN communication circuit 2).
NO >> Repair the power supply and the ground circuit.
CAN gateway harness connector Continuity
Connector No. Terminal No.
M125 46Existed
10 12 Existed
Revision: 2010 May2011 QX56
Page 3573 of 5598
LAN
DLC BRANCH LINE CIRCUITLAN-153
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256296
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the data link connector for damage, bend and loose connection (connector side and harness side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
Check the resistance between the data link connector terminals.
Is the measurement value within the specification?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the data link connector branch line circuit.
NO >> Repair the data link connector branch line.
Data link connector Resistance (Ω)
Connector No. Terminal No.
M4 6 14 Approx. 54 – 66
Revision: 2010 May2011 QX56
Page 3574 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-154
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
HVAC BRANCH LINE CIRCUIT
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256297
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
INFINITI QX56 2011 Factory Service Manual
LAN-154
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
HVAC BRANCH LINE CIRCUIT
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256297
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.](/manual-img/42/57033/w960_57033-3573.png)
LAN-154
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
HVAC BRANCH LINE CIRCUIT
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256297
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the A/C auto amp. for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of A/C auto amp.
2. Check the resistance between the A/C auto amp. harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the A/C auto amp. branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circ uit of the A/C auto amp. Refer to HAC-110, "
A/C AUTO AMP. :
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the A/C auto amp. Refer to HAC-146, "Removal and Installation".
YES (Past error)>>Error was detect ed in the A/C auto amp. branch line.
NO >> Repair the power supply and the ground circuit.
A/C auto amp. harness connector Resistance (Ω)
Connector No. Terminal No.
M50 1 21 Approx. 54 – 66
Revision: 2010 May2011 QX56
Page 3575 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
M&A BRANCH LINE CIRCUITLAN-155
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256298
1.CHECK CONNECTOR
1 INFINITI QX56 2011 Factory Service Manual
LAN
M&A BRANCH LINE CIRCUITLAN-155
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256298
1.CHECK CONNECTOR
1](/manual-img/42/57033/w960_57033-3574.png)
LAN
M&A BRANCH LINE CIRCUITLAN-155
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256298
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the combination meter for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of combination meter.
2. Check the resistance between the combination meter harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the combination meter branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the combination meter. Refer to MWI-64, "
COMBINATION
METER : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the combination meter. Refer to MWI-85, "Removal and Installation".
YES (Past error)>>Error was detected in the combination meter branch line.
NO >> Repair the power supply and the ground circuit.
Combination meter harness connector Resistance (Ω)
Connector No. Terminal No.
M34 21 22 Approx. 54 – 66
Revision: 2010 May2011 QX56
Page 3576 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-156
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256299
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
INFINITI QX56 2011 Factory Service Manual
LAN-156
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256299
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.](/manual-img/42/57033/w960_57033-3575.png)
LAN-156
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256299
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the steer ing angle sensor for damage, bend and loose connection
(unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of steering angle sensor.
2. Check the resistance between the steeri ng angle sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the steering angle sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the steering angle sensor. Refer to BRC-53, "
Wiring Dia-
gram".
Is the inspection result normal?
YES (Present error)>>Replace the steering angle sensor. Refer to BRC-139, "Removal and Installation".
YES (Past error)>>Error was detected in the steering angle sensor branch line.
NO >> Repair the power supply and the ground circuit.
Steering angle sensor harness connector Resistance (Ω)
Connector No. Terminal No.
M30 5 2 Approx. 54 – 66
Revision: 2010 May2011 QX56
