Page 4521 of 5598
SE-62
< WIRING DIAGRAM >
CLIMATE CONTROLLED SEAT SYSTEM
JCJWM1526GB
Revision: 2010 May2011 QX56
Page 4522 of 5598
CLIMATE CONTROLLED SEAT SYSTEM
SE-63
< WIRING DIAGRAM >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
JCJWM1527GB
Revision: 2010 May2011 QX56
Page 4523 of 5598
SE-64
< WIRING DIAGRAM >
CLIMATE CONTROLLED SEAT SYSTEM
JCJWM1528GB
Revision: 2010 May2011 QX56
Page 4524 of 5598
CLIMATE CONTROLLED SEAT SYSTEM
SE-65
< WIRING DIAGRAM >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
JCJWM1529GB
Revision: 2010 May2011 QX56
Page 4525 of 5598

SE-66
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORK FLOW
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work FlowINFOID:0000000006217388
DETAILED FLOW
1.OBTAIN INFORMATION ABOUT SYMPTOM
Interview the customer to obtain the malfunction information (conditions and environment when the malfunc-
tion occurred) as much as possible when the customer brings the vehicle in.
>> GO TO 2.
2.REPRODUCE THE MALFUNCTION INFORMATION
Check the malfunction on the vehicle that the customer describes.
Inspect the relation of the symptoms and the condition when the symptoms occur.
>> GO TO 3.
3.IDENTIFY THE MALFUNCTIONING SYS TEM WITH “SYMPTOM DIAGNOSIS”
Use “Symptom diagnosis” from the symptom inspection re sult in step 2 and then identify where to start per-
forming the diagnosis based on possible causes and symptoms.
>> GO TO 4.
4.IDENTIFY THE MALFUNCTIONING PART S WITH “COMPONENT DIAGNOSIS”
Perform the diagnosis with “Component diagnosis” of the applicable system.
>> GO TO 5.
5.REPAIR OR REPLACE THE MALFUNCTIONING PARTS
Repair or replace the specified malfunctioning parts.
>> GO TO 6.
6.FINAL CHECK
Check that malfunctions are not reproduced when obtaini ng the malfunction information from the customer,
referring to the symptom inspection result in step 2.
Are the malfunctions corrected?
YES >> INSPECTION END
NO >> GO TO 3.
Revision: 2010 May2011 QX56
Page 4526 of 5598

POWER SUPPLY AND GROUND CIRCUITSE-67
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
DTC/CIRCUIT DIAGNOSIS
POWER SUPPLY AND GROUND CIRCUIT
CLIMATE CONTROLLED SEAT CONTROL UNIT
CLIMATE CONTROLLED SEAT CONT ROL UNIT : Diagnosis ProcedureINFOID:0000000006217389
Driver side
1.CHECK FUSE
Check that the following fuses are not fusing.
Is the fuse fusing?
YES >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
NO >> GO TO 2.
2.CHECK CLIMATE CONTROLLED SEAT CONTRO L UNIT (DRIVER SIDE) POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect climate controlled seat control unit (driver side) connector.
3. Turn ignition switch ON.
4. Check voltage between climate controlled seat c ontrol unit (driver side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 3.
3.CHECK CLIMATE CONTROLLED SEAT CONTROL UNI T (DRIVER SIDE) POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect climate controlled seat relay.
3. Check continuity between climate controlled seat control unit (driver side) harness connector and climate
controlled seat relay harness connector.
4. Check continuity between climate controlled seat control unit (driver side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
Signal name Fuse No.
Battery power supply 82(15A) IGN power supply 3 (10A)
(+) (− ) Voltage (V)
(Approx.)
Climate controlled seat co
ntrol unit (driver side)
Connector Terminal B508 53 Ground Battery voltage
B509 74
Climate controlled seat control unit (dri ver side) Climate controlled seat relay
Continuity
Connector Terminal Connector Terminal
B508 53 E18 6 Existed
B509 74
Climate controlled seat co ntrol unit (driver side)
GroundContinuity
Connector Terminal
B508 53 Not existed
B509 74
Revision: 2010 May2011 QX56
Page 4527 of 5598

SE-68
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
4.CHECK CILMATE CONTROLLED SEAT RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between climate controlled seat relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness or connector.
5.CHECK CLIMATE CONTROLLED SEAT RELAY GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between climate cont rolled seat relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace harness.
6.CHECK CLIMATE CONTROLLED SEAT RELAY
Check climate controlled seat relay.
Refer to SE-70, "
CLIMATE CONTROLLED SEAT CONTROL UNIT : Component Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace climate controlled seat relay.
7.CHECK CLIMATE CONTROLLED SEAT CONTRO L UNIT (DRIVER SIDE) GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between climate contro l unit (driver side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace harness or connector.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Passenger side
1.CHECK FUSE
Check that the following fuses are not fusing.
(+)
(− ) Voltage (V)
(Approx.)
Climate controled seat relay
Connector Terminal
E18 2
Ground Battery voltage
7
Climate controlled seat relay
GroundContinuity
Connector Terminal
E18 1 Existed
Climate controlled seat co ntrol unit (driver side)
GroundContinuity
Connector Terminal
B509 43 Existed
Revision: 2010 May2011 QX56
Page 4528 of 5598

POWER SUPPLY AND GROUND CIRCUITSE-69
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
Is the fuse fusing?
YES >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
NO >> GO TO 2.
2.CHECK CLIMATE CONTROLLED SEAT CONTROL UNIT (PASSENGER SIDE) POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect climate controlled seat c ontrol unit (passenger side) connector.
3. Turn ignition switch ON.
4. Check voltage between climate controlled seat control unit (passenger side) harness connector and
ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 3.
3.CHECK CLIMATE CONTROLLED SEAT CONTROL UNI T (PASSENGER SIDE) POWER SUPPLY CIR-
CUIT
1. Turn ignition switch OFF.
2. Disconnect climate controlled seat relay.
3. Check continuity between climate controlled seat control unit (passenger side) harness connector and cli-
mate controlled seat relay harness connector.
4. Check continuity between climate controlled seat control unit (passenger side) harness connector and
ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK CILMATE CONTROLLED SEAT RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between climate controll ed seat relay harness connector and ground.
Signal name Fuse No.
Battery power supply 81 (15A) IGN power supply 3 (10A)
(+) (− ) Voltage (V)
(Approx.)
Climate controlled seat control unit (passenger side)
Connector TerminalB518 53 Ground Battery voltage
B519 74
Climate controlled seat control unit (passenger side) Climate controlled seat relay Continuity
Connector Terminal Connector Terminal
B518 53 E18 3 Existed
B519 74
Climate controlled seat control unit (passenger side)
GroundContinuity
Connector Terminal
B518 53 Not existed
B519 74
Revision: 2010 May2011 QX56
