INFINITI QX56 2011 Factory Service Manual ADP-112 < DTC/CIRCUIT DIAGNOSIS > LIFTING MOTOR (REAR) LIFTING MOTOR (REAR) Component Function CheckINFOID:0000000006248408 1.CHECK FUNCTION 1. Select “SEAT LIFTER RR” in “A ctive test” mode

Page 122 of 5598

INFINITI QX56 2011 Factory Service Manual LIFTING MOTOR (REAR)ADP-113 < DTC/CIRCUIT DIAGNOSIS > C DE F G H I K L M A B ADP N O P Is the inspection result normal? YES >> Replace driver seat control unit. NO >> Repair or replace harness or con

Page 123 of 5598

INFINITI QX56 2011 Factory Service Manual ADP-114 < DTC/CIRCUIT DIAGNOSIS > TILT MOTOR TILT MOTOR Component Function CheckINFOID:0000000006248410 1.CHECK FUNCTION 1. Select “TILT MOTOR” in “Act ive test” mode with CONSULT-III. 2. Che

Page 124 of 5598

INFINITI QX56 2011 Factory Service Manual TILT MOTORADP-115 < DTC/CIRCUIT DIAGNOSIS > C DE F G H I K L M A B ADP N O P Is the inspection result normal? YES >> Replace automatic drive positioner control unit. NO >> Repair or replace harness o

Page 125 of 5598

INFINITI QX56 2011 Factory Service Manual ADP-116 < DTC/CIRCUIT DIAGNOSIS > TELESCOPIC MOTOR TELESCOPIC MOTOR Component Function CheckINFOID:0000000006248412 1.CHECK FUNCTION 1. Select “TELESCO MOTOR” in “Act ive test” mode with CONS

Page 126 of 5598

INFINITI QX56 2011 Factory Service Manual TELESCOPIC MOTORADP-117 < DTC/CIRCUIT DIAGNOSIS > C DE F G H I K L M A B ADP N O P Is the inspection result normal? YES >> Replace automatic drive positioner control unit. NO >> Repair or replace har

Page 127 of 5598

INFINITI QX56 2011 Factory Service Manual ADP-118 < DTC/CIRCUIT DIAGNOSIS > DOOR MIRROR MOTOR DOOR MIRROR MOTOR Component Function CheckINFOID:0000000006248414 1.CHECK DOOR MIRROR MOTOR FUNCTION Check the operation with “MIRROR MOTOR RH”

Page 128 of 5598

INFINITI QX56 2011 Factory Service Manual DOOR MIRROR MOTORADP-119 < DTC/CIRCUIT DIAGNOSIS > C DE F G H I K L M A B ADP N O P [driver side] [passenger side] Is the inspection result normal? YES >> Replace automatic drive positioner control
