2011 INFINITI QX56 Factory Service Manual

automatic transmission battery replacement hood release night vision deactivate airbag oil level

Page 3137 of 5598

INFINITI QX56 2011 Factory Service Manual
OPERATIONHAC-31
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
AUTO switch Turns the switch indicator lamp and "AUTO" indicator on the display ON, and then fron

OPERATIONHAC-31
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
AUTO switch Turns the switch indicator lamp and "AUTO" indicator on the display ON, and then front air condition-
ing system becomes the following state.
Air inlet: Automatic control
Air outlet: Automatic control
Blower fan: Automatic control
Compressor: ON
A/C switch Turns the compressor control (switch indicator) between ON
⇔ OFF each time while front blower fan
is activated.
NOTE:
When front blower fan is OFF, the compressor control cannot be activated.
When the compressor control (switch indicator) is in the OFF position, air inlet is fresh air intake (FRE).
Defroster (DEF) switch Turns DEF mode (switch indicator) between ON
⇔ OFF each time.
When DEF switch is pressed while front air conditioning system is in the ON position.
When DEF mode is turned ON, front air conditioning system becomes the following state.
- Air inlet: Fresh air intake
- Air outlet: DEF
- Blower fan: Automatic control (If fan speed other than AUTO is selected before pressing DEF switch, fan speed is manual control.)
- Compressor: ON
When DEF mode is turned OFF, front air conditioning system state returns to the previous state before DEF mode is selected. But, the following state is continued.
- Air inlet: Fresh air intake
- Compressor: ON When DEF switch is pressed while front air conditioning system is in the OFF position.
When DEF mode is turned ON, front air conditioning system becomes the following state.
- Air inlet: Fresh air intake
- Air outlet: DEF
- Blower fan: Automatic control
- Compressor: ON
When DEF mode is turned OFF, entire front air conditioning system is set to auto mode.
NOTE:
When DEF mode turns ON while front air conditioning system is in automatic control (“AUTO” is indi-
cated), automatic control is released (“AUTO” turns OFF).
DUAL switch Turns left and right ventilation temperature separately control (switch indicator) between ON
⇔
OFF each time.
When DUAL switch indicator is ON, the driver side and passenger side temperatures can each be set independently.
When DUAL switch indicator is OFF, the driver side outlet and setting temperature is applied to both sides.
Left and right ventilation temperature separately control is cancelled by turning the DEF mode ON.
NOTE:
When front air conditioning system is in the OFF position, left and right ventilation temperature sepa-
rately control can be selected only while front air conditioning system state (when MODE switch is
pressed) is indicated on the display.
Fan switch (UP/DOWN) Blower fan speed is manually controlled with these switches. Seven speeds are available for manual
control (as shown on the display screen)
NOTE:
When fan switch is pressed while front air conditioning system is in OFF, front air conditioning sys-
tem is activated. (Compressor control state returns to the previous state before front air condition-
ing system OFF.)
When fan switch is pressed while front air conditioning system is in automatic control (“AUTO” is
indicated), automatic control is released (“AUTO” turns OFF).
MODE switch Selects air outlet sequentially from VENT
⇒ B/L ⇒ FOOT ⇒ D/F ⇒ VENT each time.
NOTE:
When front air conditioning system is in the OFF position, air outlet can be selected.
When MODE switch is pressed while front air conditioning system is in automatic control (“AUTO” is indicated), automatic control is released (“AUTO” turns OFF).
OFF switch Turns front air conditioning system OFF.
When front air conditioning system turns OFF, air inlet and air outlet become the automatic control.
Revision: 2010 May2011 QX56

Page 3138 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-32
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
OPERATION
WITHOUT ACCS (ADVANCED CLIMATE CONTROL SYSTEM)
A/C Display
Front air conditioning system state is indicated on the display.
Whe

HAC-32
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
OPERATION
WITHOUT ACCS (ADVANCED CLIMATE CONTROL SYSTEM)
A/C Display
Front air conditioning system state is indicated on the display.
When “STATUS” on multifunction switch is pressed while
front air conditioning system is in the ON position,
the display changes to state indication display of fr ont air conditioning system. When front air conditioning
system is operated while navigation system or audio system is displayed, front air conditioning system state
is indicated in the lower portion of display for several seconds.
When MODE switch is pressed while front air conditioni ng system is in the OFF position, state indication dis-
play is indicated for several seconds.
Display Screen
Controller (Preset Switch)
Intake switch Air inlet changes between recirculation (REC)
⇔ fresh air intake (FRE) each time this switch is
pressed.
Intake switch indicator ON: Recirculation
Intake switch indicator OFF: Fresh air intake
NOTE:
When front air conditioning system is in the OFF position, air inlet can be selected.
When MODE switch and DEF switch is in the D/F or DEF position, air inlet cannot be selected to recirculation (REC).
Temperature control dial
(driver side) Selects set temperature within a range between 18.0
°C (60 °F) – 32.0 °C (90 °F) at a rate of 0.5 °C
(1.0 °F) each time the dial is rotated.
- Clockwise rotation: Set temperature increases.
- Counterclockwise rotation: Set temperature decreases.
NOTE:
When front air conditioning system is in the OFF position, set temperature can be selected only while
front air conditioning system state (when MODE switch is pressed) is indicated on the display.
Temperature control dial
(passenger side) Selects set temperature within a range between 18.0
°C (60 °F) – 32.0 °C (90 °F) at a rate of 0.5 °C
(1.0 °F) each time the dial is rotated.
- Clockwise rotation: Set temperature increases.
- Counterclockwise rotation: Set temperature decreases.
When the temperature control dial is turned, DUAL switch indicator turns ON.
NOTE:
When front air conditioning system is in the OFF position, set temperature can be selected only while
front air conditioning system state (when MODE switch is pressed) is indicated on the display.
Upper ventilator switch Turns the upper ventilator control (switch indicator) between ON
⇔ OFF each time while front blower
fan is activated.
NOTE:
When front air conditioning system is in the OFF position and air outlet is DEF position, upper ven- tilator control cannot be activated.
When front air conditioning system is in the OFF position, upper ventilator control can be selected
only while front air conditioning system state (when MODE switch is pressed) is indicated on the
display.
JMIIA0719GB
Revision: 2010 May2011 QX56

Page 3139 of 5598

INFINITI QX56 2011 Factory Service Manual
OPERATIONHAC-33
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Switch Operation
1. AUTO switch 2. Temperature control dial (Driver
side)3. MODE switch
4. OFF s

OPERATIONHAC-33
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Switch Operation
1. AUTO switch 2. Temperature control dial (Driver
side)3. MODE switch
4. OFF switch 5. A/C switch 6. Upper ventilator switch
7. Temperature control dial (passenger side) 8. DUAL switch 9. REC switch
10. FRE switch 11. Fan switch 12. DEF switch
JMIIA0822ZZ
AUTO switch Turns the switch indicator lamp and "AUTO" indicator on the display ON, and then front air condition-
ing system becomes the following state.
Air inlet: Automatic control
Air outlet: Automatic control
Blower fan: Automatic control
Compressor: ON
A/C switch Turns the compressor control (switch indicator) between ON
⇔ OFF each time while front blower fan
is activated.
NOTE:
When front blower fan is OFF, the compressor control cannot be activated.
When the compressor control (switch indicator) is in the OFF position, air inlet is fresh air intake (FRE).
Defroster (DEF) switch Turns DEF mode (switch indicator) between ON
⇔ OFF each time.
When DEF switch is pressed while front air conditioning system is in the ON position.
When DEF mode is turned ON, front air conditioning system becomes the following state.
- Air inlet: Fresh air intake
- Air outlet: DEF
- Blower fan: Automatic control (If fan speed other than AUTO is selected before pressing DEF switch, fan speed is manual control.)
- Compressor: ON
When DEF mode is turned OFF, front air conditioning system state returns to the previous state
before DEF mode is selected. But, the following state is continued.
- Air inlet: Fresh air intake
- Compressor: ON
When DEF switch is pressed while front air conditioning system is in the OFF position.
When DEF mode is turned ON, front air conditioning system becomes the following state.
- Air inlet: Fresh air intake
- Air outlet: DEF
- Blower fan: Automatic control
- Compressor: ON
When DEF mode is turned OFF, entire front air conditioning system is set to auto mode.
NOTE:
When DEF mode turns ON while front air conditioning system is in automatic control (“AUTO” is indi-
cated), automatic control is released (“AUTO” turns OFF).
Revision: 2010 May2011 QX56

Page 3140 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-34
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
OPERATION
DUAL switch Turns left and right ventilation temperature separately control (switch indicator) between ON
⇔
OFF each time.
W

HAC-34
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
OPERATION
DUAL switch Turns left and right ventilation temperature separately control (switch indicator) between ON
⇔
OFF each time.
When DUAL switch indicator is ON, the driver side and passenger side temperatures can each be set independently.
When DUAL switch indicator is OFF, the driver side outlet and setting temperature is applied to both
sides.
Left and right ventilation temperature separately control is cancelled by turning the DEF mode ON.
NOTE:
When front air conditioning system is in the OFF position, left and right ventilation temperature sepa-
rately control can be selected only while front air conditioning system state (when MODE switch is
pressed) is indicated on the display.
Fan switch (UP/DOWN) Blower fan speed is manually controlled with these switches. Seven speeds are available for manual
control (as shown on the display screen)
NOTE:
When fan switch is pressed while front air conditioning system is in OFF, front air conditioning sys-
tem is activated. (Compressor control state returns to the previous state before front air condition-
ing system OFF.)
When fan switch is pressed while front air conditioning system is in automatic control (“AUTO” is
indicated), automatic control is released (“AUTO” turns OFF).
FRE switch Air inlet is selected to fresh air intake (FRE) by pressing this switch.
- FRE indicator: ON
- REC indicator: OFF
When FRE indicator is ON, pressing the FRE switch for approximately 1.5 seconds or more, and
then the FRE and REC switch indicators blink twice and the system is switched to the automatic
control.
NOTE:
When front air conditioning system is in the OFF position, air inlet can be selected.
MODE switch Selects air outlet sequentially from VENT
⇒ B/L ⇒ FOOT ⇒ D/F ⇒ VENT each time.
NOTE:
When front air conditioning system is in the OFF position, air outlet can be selected.
When MODE switch is pressed while front air conditioning system is in automatic control (“AUTO” is indicated), automatic control is released (“AUTO” turns OFF).
OFF switch Turns front air conditioning system OFF.
When front air conditioning system turns OFF, air inlet and air outlet become the automatic control.
REC switch Air inlet is selected to fresh air intake (REC) by pressing this switch.
- REC indicator: ON
- FRE indicator: OFF
When REC indicator is ON, pressing the REC switch for approximately 1.5 seconds or more, and
then the FRE and REC switch indicators blink twice and the system is switched to the automatic
control.
NOTE:
When front air conditioning system is in the OFF position, air inlet can be selected.
When MODE switch and DEF switch is in the D/F or DEF position, air inlet cannot be selected to recirculation (REC).
Temperature control dial
(driver side) Selects set temperature within a range between 18.0
°C (60 °F) – 32.0 °C (90 °F) at a rate of 0.5 °C
(1.0 °F) each time the dial is rotated.
- Clockwise rotation: Set temperature increases.
- Counterclockwise rotation: Set temperature decreases.
NOTE:
When front air conditioning system is in the OFF position, set temperature can be selected only while
front air conditioning system state (when MODE switch is pressed) is indicated on the display.
Revision: 2010 May2011 QX56

Page 3141 of 5598

INFINITI QX56 2011 Factory Service Manual
OPERATIONHAC-35
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR AUTOMATIC AIR CONDITIONING SYSTEM
REAR AUTOMATIC AIR CONDITIONING SY STEM : Switch Name and

Page 3142 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-36
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
OPERATION
Without ACCS (advanced
climate control system)
Switch Operation
REAR CONTROLLER OPERATION
Controller (Rear A/C Control)
JMIIA0824Z

HAC-36
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
OPERATION
Without ACCS (advanced
climate control system)
Switch Operation
REAR CONTROLLER OPERATION
Controller (Rear A/C Control)
JMIIA0824ZZ
1. AUTO switch 2. Temperature control dial (Driver
side)3. MODE switch
4. REAR switch 5. OFF switch 6. Fan switch
AUTO switch Turns the switch indicator lamp and "AUTO" indicator on the front display ON, and then rear air con-
ditioning system becomes the following state.
Air outlet: Automatic control
Blower fan: Automatic control
Compressor: ON
Fan switch (UP/DOWN) Blower fan speed is manually controlled with these switches. Seven speeds are available for manual
control (as shown on the display screen)
NOTE:
When fan switch is pressed while air conditioning system is in automatic control (“AUTO” is indicated),
automatic control is rele
ased (“AUTO” turns OFF).
MODE switch Selects air outlet sequentially from VENT
⇒ B/L ⇒ FOOT ⇒ VENT each time.
NOTE:
When MODE switch is pressed while air conditioning system is in automatic control (“AUTO” is indi-
cated), automatic control is released (“AUTO” turns OFF).
OFF switch Turns rear air conditioning system OFF. (When rear control mode is ON)
When rear air conditioning system turns OFF, air outlet become the automatic control.
REAR switch Turns the switch indicator lamp and rear control mode on the front display ON, and then rear air
conditioning system becomes the following state.
- Air outlet: Automatic control
- Blower fan: Automatic control
- Compressor: ON
Rear control mode is released when switch is pressed again (rear air conditioning system operates continuously).
Temperature control dial
(driver side) Selects set temperature within a range between 18.0
°C (60 °F) – 32.0 °C (90 °F) at a rate of 0.5 °C
(1.0 °F) each time the dial is rotated.
- Clockwise rotation: Set temperature increases.
- Counterclockwise rotation: Set temperature decreases.
Revision: 2010 May2011 QX56

Page 3143 of 5598

INFINITI QX56 2011 Factory Service Manual
OPERATIONHAC-37
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Switch Operation
ACCS (ADVANCED CLIMATE CONTROL SYSTEM)
ACCS (ADVANCED CLIMATE CONTROL SY
STEM) :

Page 3144 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-38
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
OPERATION
- When air flow is small
- When air flow is large
Controller (Preset Switch)
JMIIA0410ZZ
JMIIA0411ZZ
1. Auto intake switch
Switch n

Load next 8 pages

Page: < prev 1-10 ... 3105-3112 3113-3120 3121-3128 3129-3136 3137-3144 3145-3152 3153-3160 3161-3168 3169-3176 ... 5600 next >

bluetooth service interval diagnostic menu oil night vision oil reset
