INSTALLATION
Note the following, and install in the reverse order of removal.
When installing control cable (1) to A/T shift selector assembly (2), check that control cable is fully pressed in with the ribbed (A) sur-
face facing upward.
Refer to the followings when installing the selector lever knob to
the A/T shift selector assembly.
1. Install the lock pin to the selector lever knob.
2. Insert the shift lever knob into the shift lever until it clicks. CAUTION:
Install it straight, and n ever tap or apply any shock to
install it.
Never press selector button.
Inspection and AdjustmentINFOID:0000000006226893
INSPECTION AFTER INSTALLATION
Check A/T position after adjusting A/T position. Refer to TM-101, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust A/T position. Refer to TM-101, "Adjustment".
JPDIA0609ZZ
Revision: 2010 May2011 QX56
Page 5266 of 5598
TM-178
< REMOVAL AND INSTALLATION >[7AT: RE7R01B]
CONTROL CABLE
CONTROL CABLE
Exploded ViewINFOID:0000000006226894
Removal and InstallationINFOID:0000000006226895
REMOVAL
1. Remove center console assembly . Refer to
IP-25, "Removal and Installation".
2. Remove cluster lid C cover and instrument center finisher LH. Refer to IP-14, "
Removal and Installation".
3. Shift selector lever in “P” position.
4. Remove control cable from A/T shift selector assembly.
5. Remove control cable from manual lever and control cable mounting bracket.
1. Control cable 2. A/T shift selector assembly 3. Lock plate
4. Manual lever 5. Washer 6. Lock plate
7. Bracket 8. A/T assembly
A. Retainer
Refer to GI-4, "
Components" for symbols in the figure.
JSDIA1589GB
Revision: 2010 May2011 QX56
Page 5267 of 5598
![INFINITI QX56 2011 Factory Service Manual
CONTROL CABLETM-179
< REMOVAL AND INSTALLATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
6. Remove retainer mounting bolts ( ) according to the following procedure.
a. Separate propeller shaft INFINITI QX56 2011 Factory Service Manual
CONTROL CABLETM-179
< REMOVAL AND INSTALLATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
6. Remove retainer mounting bolts ( ) according to the following procedure.
a. Separate propeller shaft](/manual-img/42/57033/w960_57033-5266.png)
CONTROL CABLETM-179
< REMOVAL AND INSTALLATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
6. Remove retainer mounting bolts ( ) according to the following procedure.
a. Separate propeller shaft assembly (front). Refer to DLN-129,
"Removal and Installation". (For 4WD models)
b. Disconnect heated oxygen sensor 2 connectors (bank 1 and bank 2). Refer to EX-5, "
Exploded View".
c. Remove exhaust front tube (RH and LH). Refer to EX-5,
"Exploded View".
d. Remove heat plates above three way catalyst (RH and LH).
e. Remove control cable mounting bracket from A/T assembly.
f. Remove retainer mounting bolts from dash panel.
7. Remove control cable from the vehicle.
INSTALLATION
Note the following, and install in the reverse order of removal.
When installing control cable (1) to A/T shift selector assembly (2),
check that control cable is fully pressed in with the ribbed (A) surface
facing upward.
Inspection and AdjustmentINFOID:0000000006226896
INSPECTION AFTER INSTALLATION
Check A/T position after adjusting A/T position. Refer to TM-101, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust A/T position. Refer to TM-101, "Adjustment".
JSDIA1677ZZ
JPDIA0609ZZ
Revision: 2010 May2011 QX56
Page 5268 of 5598
TM-180
< REMOVAL AND INSTALLATION >[7AT: RE7R01B]
SELECTOR LEVER POSITION INDICATOR
SELECTOR LEVER POSITION INDICATOR
Removal and InstallationINFOID:0000000006226897
REMOVAL
1. Remove console finisher assembly. Refer to
IP-25, "Removal and Installation".
2. Remove insert finisher (1).
3. Remove selector lever position indicator (2).
INSTALLATION
Install in the reverse order of removal.
: Screw
JSDIA1646ZZ
Revision: 2010 May2011 QX56
Page 5269 of 5598
TOW MODE SWITCHTM-181
< REMOVAL AND INSTALLATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
TOW MODE SWITCH
Removal and InstallationINFOID:0000000006226898
NOTE:
Tow mode switch is integrated in to SNOW MODE/T OW MODE/VDC OFF switch assembly (2WD models) or
4WD switch assembly (4WD models).
REMOVAL
1. Remove console finisher assembly from center console assembly. Refer to IP-25, "Removal and Installa-
tion".
2. Disconnect SNOW MODE/TOW MODE /VDC OFF switch assembly (2WD models) or 4WD switch
assembly (4WD models) harness connector.
3. Press SNOW MODE/TOW MODE/VDC OFF switch a ssembly (2WD models) or 4WD switch assembly
(4WD models) fixing pawls, and remove SNOW MO DE/TOW MODE/VDC OFF switch assembly (2WD
models) or 4WD switch assembly (4WD models) from console finisher assembly.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56
Page 5270 of 5598
TM-182
< REMOVAL AND INSTALLATION >[7AT: RE7R01B]
CONTROL VALVE & TCM
CONTROL VALVE & TCM
Exploded ViewINFOID:0000000006226899
Removal and InstallationINFOID:0000000006226900
REMOVAL
1. Drain ATF through drain plug.
1. A/T 2. Snap ring 3. Control valve & TCM
4. Oil pan gasket 5. Oil pan 6. Clip
7. Oil pan mounting bolt 8. Overflow plug 9. Drain plug
10. Drain plug gasket 11. Magnet 12. Clip
13. Joint connector
Refer to
GI-4, "
Components" for symbols in the figure.
JSDIA1755GB
Revision: 2010 May2011 QX56
Page 5271 of 5598
CONTROL VALVE & TCMTM-183
< REMOVAL AND INSTALLATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
2. Remove clips (1).
3. Remove oil pan (2) and oil pan gasket.
4. Remove magnets (1) from oil pan.
5. Remove snap ring (1) from joint connector (2).
6. Push joint connector (1).
7. Disconnect output speed sensor connector (A). CAUTION:
Be careful not to damage connector.
8. Disengage terminal clip ( ).
: Vehicle front
: Oil pan mounting bolt
JSDIA1591ZZ
JPDIA0009ZZ
JSDIA1756ZZ
JSDIA1757ZZ
JPDIA1104ZZ
Revision: 2010 May2011 QX56
Page 5272 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-184
< REMOVAL AND INSTALLATION >[7AT: RE7R01B]
CONTROL VALVE & TCM
9. Remove bolts and clip (1) from the control valve & TCM.
*: Reamer bolt
10. Remove the control valve & TCM from transmission ca INFINITI QX56 2011 Factory Service Manual
TM-184
< REMOVAL AND INSTALLATION >[7AT: RE7R01B]
CONTROL VALVE & TCM
9. Remove bolts and clip (1) from the control valve & TCM.
*: Reamer bolt
10. Remove the control valve & TCM from transmission ca](/manual-img/42/57033/w960_57033-5271.png)
TM-184
< REMOVAL AND INSTALLATION >[7AT: RE7R01B]
CONTROL VALVE & TCM
9. Remove bolts and clip (1) from the control valve & TCM.
*: Reamer bolt
10. Remove the control valve & TCM from transmission case.
CAUTION:
When removing, be careful wi th the manual valve (1) notch
and manual plate (2) height. Remove it vertically.
11. Remove joint connector (1) from the control valve & TCM using a flat-bladed screwdriver (A).
12. Disconnect TCM connector (A). CAUTION:
Be careful not to damage connector.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
Be careful not to damage connector when installing any connector.
Never reuse joint connector.
Apply ATF to O-ring of joint connector.
Never reuse drain plug and drain plug gasket. In addition, install new drain plug and drain plug gas-
ket after adjustment of A/T fluid filling.
Refer to the following when installing the control valve & TCM to transmission case.
: Vehicle front
Bolt symbol Length mm (in) Number of bolts A 43 (1.69) 3
B 40 (1.57) 2
C 54 (2.13) 6
D 50 (1.97) 2
E* 50 (1.97) 1
JPDIA1105ZZ
JPDIA0012ZZ
JSDIA1718ZZ
JSDIA1813ZZ
