Page 2481 of 5598

INFINITI QX56 2011 Factory Service Manual
P1805 BRAKE SWITCHEC-457
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
YES >> INSPECTION END
NO >> Replace stop lamp switch. Refer to
BR-20, "
Removal and Installation".
Revisio

Page 2482 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-458
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2100, P2103 THROTTLE
CONTROL MOTOR RELAY
P2100, P2103 THROTTLE CONTROL MOTOR RELAY
DTC LogicINFOID:0000000006217960
DTC DETECTION LOGIC
DTC CONFIRMATION PRO

EC-458
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2100, P2103 THROTTLE
CONTROL MOTOR RELAY
P2100, P2103 THROTTLE CONTROL MOTOR RELAY
DTC LogicINFOID:0000000006217960
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 8 V or more at idle.
Which DTC is detected?
P2100 >> GO TO 2.
P2103 >> GO TO 3.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P2100
1. Turn ignition switch ON and wait at least 2 seconds.
2. Start engine and let it idle for 5 seconds.
3. Check DTC.
Is DTC detected?
YES >> Go to EC-458, "Diagnosis Procedure".
NO >> INSPECTION END
3.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P2103
1. Turn ignition switch ON and wait at least 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-458, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217961
1.CHECK THROTTLE CONTROL MOTO R RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect IPDM E/R harness connector E15.
4. Check the continuity between IPDM E/ R harness connector and ECM harness connector.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P2100 ETC MOT PWR-B1
[Throttle contro
l motor relay
circuit open (bank 1)] ECM detects that the voltage of power
source for throttle
control motor is ex-
cessively low. Harness or connectors
(Throttle control motor relay circuit is open)
Throttle control motor relay
P2103 ETC MOT PWR
(Throttle contro
l motor relay
circuit short) ECM detects that the throttle control
motor relay is stuck ON. Harness or connectors
(Throttle control motor re lay circuit is shorted)
Throttle control motor relay
IPDM E/R ECM Continuity
Connector Terminal Connector Terminal
E15 60 E80 123 Existed
Revision: 2010 May2011 QX56

Page 2483 of 5598

INFINITI QX56 2011 Factory Service Manual
P2100, P2103 THROTTLE CONTROL MOTOR RELAY
EC-459
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Harness for open

Page 2484 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-460
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2101 ELECTRIC THROTTLE CONTROL FUNCTION
P2101 ELECTRIC THROTTL
E CONTROL FUNCTION
DescriptionINFOID:0000000006217962
Electric throttle control actuator consi

EC-460
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2101 ELECTRIC THROTTLE CONTROL FUNCTION
P2101 ELECTRIC THROTTL
E CONTROL FUNCTION
DescriptionINFOID:0000000006217962
Electric throttle control actuator consists of th rottle control motor, throttle position sensor, etc.
The throttle control motor is operated by the ECM and it opens and closes the throttle valve.
The current opening angle of the throttle valve is detected by the throttle position sensor and it provides feed-
back to the ECM. ECM controls the throttle valve openi ng angle in response to driving condition via the throttle
control motor.
DTC LogicINFOID:0000000006217963
DTC DETECTION LOGIC
NOTE:
If DTC P2101 is displayed with DTC P2100, first pe rform the trouble diagnosis for DTC P2100. Refer
to EC-458, "
DTC Logic".
If DTC P2101 is displayed with DTC P2119, first pe rform the trouble diagnosis for DTC P2119. Refer
to EC-466, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 2 seconds.
2. Start engine and let it idle for 5 seconds.
3. Check DTC.
Is DTC detected?
YES >> Go to EC-460, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217964
1.CHECK THROTTLE CONTROL MOTOR RELAY INPUT SIGNAL CIRCUIT-I
1. Check the voltage between ECM harness connector and ground under the following conditions.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 2.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2101 Electric throttle control
performance Electric throttle control function does not
operate properly. Harness or connectors
(Throttle control motor circuit is open or shorted)
Electric throttle control actuator
ECM Ground Condition Voltage
Connector Terminal
E80 173 Ground Ignition switch:
OFF
Approx. 0 V
Ignition switch:
ON Battery voltage
Revision: 2010 May2011 QX56

Page 2485 of 5598

INFINITI QX56 2011 Factory Service Manual
P2101 ELECTRIC THROTTLE CONTROL FUNCTIONEC-461
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2.CHECK THROTTLE CONTROL MOTO
R RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OF

Page 2486 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-462
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2101 ELECTRIC THROTTLE CONTROL FUNCTION
2. Disconnect electric throttle control actuator harness connector.
3. Disconnect ECM harness connector.
4. Check the

Page 2487 of 5598

INFINITI QX56 2011 Factory Service Manual
P2101 ELECTRIC THROTTLE CONTROL FUNCTIONEC-463
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control act

Page 2488 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-464
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2118 THROTTLE CONTROL MOTOR
P2118 THROTTLE CONTROL MOTOR
DTC LogicINFOID:0000000006217967
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If
