LAN
LASER BRANCH LINE CIRCUITLAN-93
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
LASER BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006220569
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the ICC s ensor for damage, bend and loose connection (unit side
and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ICC sensor.
2. Check the resistance between the I CC sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ICC sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ICC sensor. Refer to CCS-158, "
ICC SENSOR : Diagno-
sis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the ICC sensor. Refer to CCS-176, "Removal and Installation".
YES (Past error)>>Error was detect ed in the ICC sensor branch line.
NO >> Repair the power supply and the ground circuit.
ICC sensor harness connector Resistance (Ω)
Connector No. Terminal No.
E65 3 6 Approx. 108 – 132
Revision: 2010 May2011 QX56
Page 3514 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-94
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT
CAN COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000006256269
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconn INFINITI QX56 2011 Factory Service Manual
LAN-94
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT
CAN COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000006256269
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconn](/manual-img/42/57033/w960_57033-3513.png)
LAN-94
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT
CAN COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000006256269
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect all the unit connectors on CAN communication circuit.
4. Check terminals and connectors for damage, bend and loose connection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between t he data link connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause.
3.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between the data link connector and the ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Check the harness and repair the root cause.
4.CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance between the ECM terminals.
3. Check the resistance between the IPDM E/R terminals.
Is the measurement value within the specification?
YES >> GO TO 5.
NO >> Replace the ECM and/or the IPDM E/R.
5.CHECK SYMPTOM
Connect all the connectors. Check if the symptoms descri bed in the “Symptom (Results from interview with
customer)” are reproduced.
Data link connector Continuity
Connector No. Terminal No.
M4 6 14 Not existed
Data link connector
GroundContinuity
Connector No. Terminal No.
M4 6 Not existed
14 Not existed
ECM Resistance (Ω)
Te r m i n a l N o .
146 151 Approx. 108 – 132
IPDM E/R Resistance (Ω)
Te r m i n a l N o .
27 26 Approx. 108 – 132
Revision: 2010 May2011 QX56
Page 3515 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
CAN COMMUNICATION CIRCUITLAN-95
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow
the trouble INFINITI QX56 2011 Factory Service Manual
LAN
CAN COMMUNICATION CIRCUITLAN-95
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow
the trouble](/manual-img/42/57033/w960_57033-3514.png)
LAN
CAN COMMUNICATION CIRCUITLAN-95
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow
the trouble diagnosis procedure when past error is
detected.
6.CHECK UNIT REPRODUCTION
Perform the reproduction test as per the following procedure for each unit.
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Disconnect one of the unit connectors of CAN communication circuit.
NOTE:
ECM and IPDM E/R have a termination circuit. Check other units first.
4. Connect the battery cable to the negative terminal. Check if the symptoms described in the “Symptom
(Results from interview with customer)” are reproduced.
NOTE:
Although unit-related error symptoms occur, do not confuse them with other symptoms.
Inspection result
Reproduced>>Connect the connector. Check other units as per the above procedure.
Non-reproduced>>Replace the unit whose connector was disconnected.
Revision: 2010 May2011 QX56
Page 3516 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-96
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT 1
CAN COMMUNICATION CIRCUIT 1
Diagnosis ProcedureINFOID:0000000006220570
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Dis INFINITI QX56 2011 Factory Service Manual
LAN-96
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT 1
CAN COMMUNICATION CIRCUIT 1
Diagnosis ProcedureINFOID:0000000006220570
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Dis](/manual-img/42/57033/w960_57033-3515.png)
LAN-96
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT 1
CAN COMMUNICATION CIRCUIT 1
Diagnosis ProcedureINFOID:0000000006220570
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect all the unit connectors on CAN communication circuit 1. NOTE:
For identification of CAN communication circuit 1, CAN communication circuit 2, and ITS communication
circuit, refer to LAN-57, "
System Diagram".
4. Check terminals and connectors for damage, bend and loose connection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between t he data link connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause.
3.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between the data link connector and the ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Check the harness and repair the root cause.
4.CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance between the ECM terminals.
3. Check the resistance between the IPDM E/R terminals.
Is the measurement value within the specification?
YES >> GO TO 5.
NO >> Replace the ECM and/or the IPDM E/R.
Data link connector Continuity
Connector No. Terminal No.
M4 6 14 Not existed
Data link connector
GroundContinuity
Connector No. Terminal No.
M4 6 Not existed
14 Not existed
ECM Resistance (Ω)
Te r m i n a l N o .
146 151 Approx. 108 – 132
IPDM E/R Resistance (Ω)
Te r m i n a l N o .
27 26 Approx. 108 – 132
Revision: 2010 May2011 QX56
Page 3517 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
CAN COMMUNICATION CIRCUIT 1LAN-97
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
5.CHECK SYMPTOM
Connect all the connectors. Check if the symptoms descr ibed in the “Symptom (Res INFINITI QX56 2011 Factory Service Manual
LAN
CAN COMMUNICATION CIRCUIT 1LAN-97
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
5.CHECK SYMPTOM
Connect all the connectors. Check if the symptoms descr ibed in the “Symptom (Res](/manual-img/42/57033/w960_57033-3516.png)
LAN
CAN COMMUNICATION CIRCUIT 1LAN-97
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
5.CHECK SYMPTOM
Connect all the connectors. Check if the symptoms descr ibed in the “Symptom (Results from interview with
customer)” are reproduced.
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow the trouble diagnosis procedure when past error is
detected.
6.CHECK UNIT REPRODUCTION
Perform the reproduction test as per the following procedure for each unit.
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Disconnect one of the unit connectors of CAN communication circuit 1.
NOTE:
ECM and IPDM E/R have a termination circuit. Check other units first.
4. Connect the battery cable to the negative terminal. Check if the symptoms described in the “Symptom
(Results from interview with customer)” are reproduced.
NOTE:
Although unit-related error symptoms occur, do not confuse them with other symptoms.
Inspection result
Reproduced>>Connect the connector. Check other units as per the above procedure.
Non-reproduced>>Replace the unit whose connector was disconnected.
Revision: 2010 May2011 QX56
Page 3518 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-98
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT 2
CAN COMMUNICATION CIRCUIT 2
Diagnosis ProcedureINFOID:0000000006220571
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Dis INFINITI QX56 2011 Factory Service Manual
LAN-98
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT 2
CAN COMMUNICATION CIRCUIT 2
Diagnosis ProcedureINFOID:0000000006220571
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Dis](/manual-img/42/57033/w960_57033-3517.png)
LAN-98
< DTC/CIRCUIT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT 2
CAN COMMUNICATION CIRCUIT 2
Diagnosis ProcedureINFOID:0000000006220571
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect all the unit connectors on CAN communication circuit 2. NOTE:
For identification of CAN communication circuit 1, CAN communication circuit 2, and ITS communication
circuit, refer to LAN-57, "
System Diagram".
4. Check terminals and connectors for damage, bend and loose connection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between t he data link connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause.
3.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between the data link connector and the ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Check the harness and repair the root cause.
4.CHECK CAN GATEWAY TERMINATION CIRCUIT
1. Remove the CAN gateway.
2. Check the resistance between the CAN gateway terminals.
Is the measurement value within the specification?
YES >> GO TO 5.
NO >> Replace the CAN gateway.
5.CHECK SYMPTOM
Connect all the connectors. Check if the symptoms descri bed in the “Symptom (Results from interview with
customer)” are reproduced.
Inspection result
Reproduced>>GO TO 6.
Data link connector Continuity
Connector No. Terminal No.
M4 13 12 Not existed
Data link connector
GroundContinuity
Connector No. Terminal No.
M4 13 Not existed
12 Not existed
CAN gateway
Resistance (Ω)
Te r m i n a l N o .
4 10 Approx. 108 – 132
6 12 Approx. 108 – 132
Revision: 2010 May2011 QX56
Page 3519 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
CAN COMMUNICATION CIRCUIT 2LAN-99
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
Non-reproduced>>Start the diagnosis again. Follow
the trouble diagnosis procedure when past error INFINITI QX56 2011 Factory Service Manual
LAN
CAN COMMUNICATION CIRCUIT 2LAN-99
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
Non-reproduced>>Start the diagnosis again. Follow
the trouble diagnosis procedure when past error](/manual-img/42/57033/w960_57033-3518.png)
LAN
CAN COMMUNICATION CIRCUIT 2LAN-99
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
Non-reproduced>>Start the diagnosis again. Follow
the trouble diagnosis procedure when past error is
detected.
6.CHECK UNIT REPRODUCTION
Perform the reproduction test as per the following procedure for each unit.
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Disconnect one of the unit connectors of CAN communication circuit 2. NOTE:
CAN gateway has two termination circuits. Check other units first.
4. Connect the battery cable to the negative terminal. Check if the symptoms described in the “Symptom
(Results from interview with customer)” are reproduced.
NOTE:
Although unit-related error symptoms occur, do not confuse them with other symptoms.
Inspection result
Reproduced>>Connect the connector. Check other units as per the above procedure.
Non-reproduced>>Replace the unit whose connector was disconnected.
Revision: 2010 May2011 QX56
Page 3520 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-100
< DTC/CIRCUIT DIAGNOSIS >[CAN]
ITS COMMUNICATION CIRCUIT
ITS COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000006220572
1.CHECK CAN DIAGNOSIS
Check the CAN diagnosis results from CONSU INFINITI QX56 2011 Factory Service Manual
LAN-100
< DTC/CIRCUIT DIAGNOSIS >[CAN]
ITS COMMUNICATION CIRCUIT
ITS COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000006220572
1.CHECK CAN DIAGNOSIS
Check the CAN diagnosis results from CONSU](/manual-img/42/57033/w960_57033-3519.png)
LAN-100
< DTC/CIRCUIT DIAGNOSIS >[CAN]
ITS COMMUNICATION CIRCUIT
ITS COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000006220572
1.CHECK CAN DIAGNOSIS
Check the CAN diagnosis results from CONSULT-III to see that the CAN communication circuit 1 and CAN
communication circuit 2 have no malfunction.
NOTE:
For identification of CAN communication circuit 1, CAN communication circuit 2, and ITS communication cir-
cuit, refer to LAN-57, "
System Diagram".
Are the CAN communication 1 and CAN communication 2 circuits normal?
YES >> GO TO 2.
NO >> Check and repair CAN communication circuit 1 and/or CAN communication circuit 2.
2.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors fo r damage, bend and loose connection (unit side and con-
nector side).
- ADAS control unit
- Harness connector B63
- Harness connector B239
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the terminal and connector.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
- ADAS control unit
- ICC sensor
2. Check the continuity between the ADAS control unit harness connector and the ICC sensor harness con-
nector.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair the ADAS control unit branch line. (ITS communication circuit). Refer to LAN-57, "
System
Diagram".
4.CHECK HARNESS CONTINUITY (SHORT CIRCUIT)
1. Disconnect the following harness connectors.
- Side radar RH
- Side radar LH
- Lane camera unit
- Accelerator pedal actuator
2. Check the continuity between the ADAS control unit harness connector terminals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Check the harness and repair the root cause.
ADAS control unit harness connector ICC sensor harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
B61 7
E65 3 Existed
86Existed
ADAS control unit harness connector Continuity
Connector No. Terminal No.
B61 7 8 Not existed
Revision: 2010 May2011 QX56
