Page 3369 of 5598

INT-20
< REMOVAL AND INSTALLATION >
BODY SIDE TRIM
BODY SIDE WELT
BODY SIDE WELT : Removal and InstallationINFOID:0000000006220248
CAUTION:
Never damage the body.
REMOVAL
Front body side welt
1. Remove front kicking plate inner and rear kicking plate inner. Refer to INT-20, "KICKING PLATE INNER :
Removal and Installation".
2. Remove dash side finisher. Refer to INT-18, "
DASH SIDE FINISHER : Removal and Installation".
3. Slide front seat assembly to the frontmost position.
4. Remove center pillar lower garnish. Refer to INT-22, "
CENTER PILLAR LOWER GARNISH : Removal
and Installation".
5. Remove front body side welt.
Rear body side welt
1. Remove front kicking plate inner and rear kicking plate inner. Refer to INT-20, "KICKING PLATE INNER :
Removal and Installation".
2. Slide front seat assembly to the frontmost position.
3. Remove center pillar lower garnish. Refer to INT-22, "
CENTER PILLAR LOWER GARNISH : Removal
and Installation".
4. Remove luggage side lower finisher. Refer to INT-36, "
LUGGAGE SIDE LOWER FINISHER : Removal
and Installation".
5. Remove rear body side welt.
INSTALLATION
Install in the reverse order of removal.
KICKING PLATE INNER
KICKING PLATE INNER : Removal and InstallationINFOID:0000000006220249
CAUTION:
When removing, always use a remover tool that is made of plastic.
Never damage the body.
REMOVAL
Front kicking plate inner
Disengage front kicking plate inner fixing pawls and metal clips using
a remover tool (A) as shown by the arrow in the figure, and then
remove front kicking plate inner.
CAUTION:
Apply protective tape (B) to the body panel to protect from dam-
age.
Rear kicking plate inner
1. Disengage rear kicking plate inner fixing pawls using a re mover tool (A) as shown by the arrow in the fig-
ure, and then remove rear kicking plate inner (1).
CAUTION:
: Pawl
: Metal clip
JMJIA4021ZZ
Revision: 2010 May2011 QX56
Page 3370 of 5598

BODY SIDE TRIMINT-21
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
Apply protective tape (B) to the body panel to protect from damage.
2. Remove rear side bracket.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
Visually check the pawls and metal clips for defo rmation and damage during installation. Replace
with new ones if necessary.
When installing front ki cking plate inner and rear kicking plat e inner, check that pawls and metal
clips are securely fitted in body panel holes, and press them in.
KICKING PLATE OUTER
KICKING PLATE OUTER : Removal and InstallationINFOID:0000000006220250
CAUTION:
When removing, always use a remover tool that is made of plastic.
Never damage the body.
REMOVAL
Front kicking plate outer
Disengage front kicking plate outer fixing pawls using a remover tool
(A) as shown by the arrow in the figure, and then remove front kick-
ing plate outer (1).
CAUTION:
Apply protective tape (B) to the body panel to protect from dam-
age.
Rear kicking plate outer
Disengage rear kicking plate outer fixing pawls using a remover tool
(A) as shown by the arrow in the figure, and then remove rear kick-
ing plate outer (1).
CAUTION:
Apply protective tape (B) to the body panel to protect from dam-
age.
INSTALLATION
Note the following items, and then install in the reverse order of removal.
: Pawl
JMJIA4023ZZ
: Pawl
JMJIA4022ZZ
: Pawl
JMJIA4024ZZ
Revision: 2010 May2011 QX56
Page 3371 of 5598

INT-22
< REMOVAL AND INSTALLATION >
BODY SIDE TRIM
CAUTION:
Visually check the pawls for deformation and damage during installation. Replace with new ones if
necessary.
When installing front kicking pl ate outer and rear kicking plate outer, check that pawls are securely
fitted in body panel ho les, and press them in.
CENTER PILLAR LOWER GARNISH
CENTER PILLAR LOWER GARNISH : Removal and InstallationINFOID:0000000006220251
CAUTION:
Never damage the body.
REMOVAL
1. Remove front kicking plate inner and rear kicking plate inner. Refer to INT-20, "KICKING PLATE INNER :
Removal and Installation".
2. Slide front seat assembly to the frontmost position.
3. Remove seat belt outer anchor. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
4. Disengage center pillar lower garnish fixing clips.
5. Remove center pillar lower garnish according to the order of the arrows shown in the figure.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
Visually check the clips for deformation and dama ge during installation. Replace with new ones if
necessary.
When installing center pillar lowe r garnish, check that clips are secu rely fitted in body panel holes,
and press them in.
CENTER PILLAR UPPER GARNISH
CENTER PILLAR UPPER GARNISH : Removal and InstallationINFOID:0000000006220252
CAUTION:
When removing, always use a remover tool that is made of plastic.
Never damage the body.
REMOVAL
1. Remove front kicking plate inner and rear kicking plate inner. Refer to INT-20, "KICKING PLATE INNER :
Removal and Installation".
2. Slide front seat assembly to the frontmost position.
3. Remove center pillar lower garnish. Refer to INT-22, "
CENTER PILLAR LOWER GARNISH : Removal
and Installation".
: Clip
JMJIA4025ZZ
Revision: 2010 May2011 QX56
Page 3372 of 5598

BODY SIDE TRIMINT-23
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
4. Disengage center pillar upper garnish lower side fixing clip using a remover tool (A).
5. Pull center pillar upper garnish (1) from inside passenger room, disengage center pillar upper garnish upper side fixing pawl as shown in the following figur e, and then remove center pillar upper garnish from
center pillar panel (2).
CAUTION:
Be careful not to apply excessive force when remo ving center pillar upper garnish. Otherwise,
pawl may be damaged and fragments may drop in panel holes on body.
6. Remove assist grip mounting bolts, and then remove assist grip.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
Replace center pillar upper garnish with a new part after removal. Never reuse center pillar upper
garnish.
Visually check the clip and pawl for deformation an d damage during installation. Replace with new
ones if necessary.
When installing center pill ar upper garnish, check that clip and pawl are securely fitted in body panel
holes, and press them in.
: Clip
: Pawl
JMJIA4026ZZ
JMJIA1176ZZ
Revision: 2010 May2011 QX56
Page 3373 of 5598
INT-24
< REMOVAL AND INSTALLATION >
FLOOR TRIM
FLOOR TRIM
Exploded ViewINFOID:0000000006220253
FOR SECOND BENCH SEAT
JMJIA4007ZZ
1. Front floor carpet 2. Carpet hook 3. Fixing clip
4. Footrest 5. Front floor spacer front 6. Front floor spacer rear
7. Floor hook 8. Rear floor carpet 9. Dual lock fastener: Pawl
: Vehicle front
Revision: 2010 May2011 QX56
Page 3374 of 5598

FLOOR TRIMINT-25
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
FOR SECOND CAPTAIN SEAT
FRONT FLOOR CARPET
FRONT FLOOR CARPET : Re moval and InstallationINFOID:0000000006220254
REMOVAL
1. Remove front seat assembly (driver and passenger). Refer to SE-112, "Removal and Installation".
2. Remove second seat assembly (LH and RH). Refer to SE-125, "
Removal and Installation".
3. Remove floor grille (LH and RH). Refer to VTL-12, "
REAR FLOOR GRILLE : Removal and Installation".
4. Remove front kicking plate inner and rear kicking plate inner (LH and RH). Refer to INT-20, "
KICKING
PLATE INNER : Removal and Installation".
5. Remove dash side finisher (LH and RH). Refer to INT-18, "
DASH SIDE FINISHER : Removal and Installa-
tion".
6. Remove center pillar lower garnish (LH and RH). Refer to INT-22, "
CENTER PILLAR LOWER GARNISH :
Removal and Installation".
7. Remove instrument lower panel LH. Refer to IP-14, "
Removal and Installation".
8. Remove center console assembly. Refer to IP-25, "
Removal and Installation".
9. Remove adjusting nut and front cable mounting bolts and nuts, and then remove front cable. Refer to TM-
176, "Removal and Installation".
JMJIA4008ZZ
1. Front floor carpet 2. Carpet hook 3. Fixing clip
4. Footrest 5. Front floor spacer front 6. Front floor spacer rear
7. Floor hook 8. Rear floor carpet 9. Dual lock fastener
: Pawl
: Vehicle front
Revision: 2010 May2011 QX56
Page 3375 of 5598
INT-26
< REMOVAL AND INSTALLATION >
FLOOR TRIM
10. Remove the following parts after removing the center console assembly. Remove ground bolt (G).
Disconnect floor harness connectors (A) and (E).
Disconnect yaw rate/side/decel G sensor harness connector (C). Refer to BRC-138, "
Exploded View".
Disconnect diagnosis sensor unit harness connector (D). Refer to SR-26, "
Exploded View".
Remove floor harness clamps (B) and (F).
11. Remove A/T shift selector assembly mounting bolts. Refer to TM-176, "
Removal and Installation".
12. Remove floor duct 1 (LH and RH). Refer to VTL-11, "
FLOOR DUCT 1 : Removal and Installation".
13. Disconnect drain hose (1) and remove instrument stay mounting nuts (A), and then remove instrument stay (2) (LH and RH).
14. Disengage front floor carpet from front floor carpet fixing clips (A).
JMJIA4226ZZ
JMJIA4225ZZ
JMJIA1560ZZ
Revision: 2010 May2011 QX56
Page 3376 of 5598

FLOOR TRIMINT-27
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
15. Peel off dual lock fastener between front floor carpet and rear floor carpet, and then remove front floor car-
pet.
INSTALLATION
Install in the reverse order of removal.
REAR FLOOR CARPET
REAR FLOOR CARPET : Removal and InstallationINFOID:0000000006220255
REMOVAL
1. Remove third seat assembly. Refer to SE-138, "Removal and Installation".
2. Remove luggage floor rear board. Refer to INT-34, "
LUGGAGE FLOOR REAR BOARD : Removal and
Installation".
3. Remove luggage rear plate. Refer to INT-35, "
LUGGAGE REAR PLATE : Removal and Installation".
4. Remove luggage floor bracket. Refer to INT-33, "
Exploded View".
5. Remove luggage side lower finisher. Refer to INT-36, "
LUGGAGE SIDE LOWER FINISHER : Removal
and Installation".
6. Disengage clip of each floor hook (1) using a remover tool (A), and then remove each floor hook.
7. Peel off dual lock fastener between front floor carpet and rear floor carpet, and then remove rear floor car-
pet.
INSTALLATION
Install in the reverse order of removal.
: Clip
JMJIA0092GB
Revision: 2010 May2011 QX56
