2011 INFINITI QX56 Factory Service Manual

clutch spark plugs replace seat adjustment sport mode air conditioning key battery

Page 4849 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-56
< DTC/CIRCUIT DIAGNOSIS >
B1033, B1034 CRASH ZONE SENSOR
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4850 of 5598

INFINITI QX56 2011 Factory Service Manual
B1035 CRASH ZONE SENSORSRC-57
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1035 CRASH ZONE SENSOR
DTC LogicINFOID:0000000006219988
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHEC

B1035 CRASH ZONE SENSORSRC-57
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1035 CRASH ZONE SENSOR
DTC LogicINFOID:0000000006219988
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-57, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219989
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE CRASH ZONE SENSOR
1. Replace crash zone sensor. Refer to SR-22, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-57, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-57, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1035 CRASH ZONE SEN
[COMM FAIL] Crash zone sensor is malfunctioning or out of
the specified specification Disconnection of wiring harness
Malfunction in crash zone sensor
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4851 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-58
< DTC/CIRCUIT DIAGNOSIS >
B1035 CRASH ZONE SENSOR
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4852 of 5598

INFINITI QX56 2011 Factory Service Manual
B1036 CRASH ZONE SENSORSRC-59
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1036 CRASH ZONE SENSOR
DTC LogicINFOID:0000000006219990
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHEC

Page 4853 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-60
< DTC/CIRCUIT DIAGNOSIS >
B1037, B1039, B1041 CRASH ZONE SENSOR
B1037, B1039, B1041 CRASH ZONE SENSOR
DTC LogicINFOID:0000000006219992
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SE

Page 4854 of 5598

INFINITI QX56 2011 Factory Service Manual
B1037, B1039, B1041 CRASH ZONE SENSOR
SRC-61
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4855 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-62
< DTC/CIRCUIT DIAGNOSIS >
B1042, B1043, B1044, B1045, B1046, B1047 DIAGNOSIS SENSOR UNIT
B1042, B1043, B1044, B1045, B1046, B1047 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006219994
DTC DE

Page 4856 of 5598

INFINITI QX56 2011 Factory Service Manual
B1049, B1054 DRIVER AIR BAG MODULE
SRC-63
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1049, B1054 DRIVER AIR BAG MODULE
DTC LogicINFOID:0000000006219996
DTC DETECTION LOGIC
DTC CONF
