INFINITI QX56 2011 Factory Service Manual
CCS-18
< SYSTEM DESCRIPTION >[ICC]
SYSTEM
When the SET/COAST switch is pushed under the following condi-
tions, the system cannot be set. A warning chime will sound and
the set speed indicator and

CCS-18
< SYSTEM DESCRIPTION >[ICC]
SYSTEM
When the SET/COAST switch is pushed under the following condi-
tions, the system cannot be set. A warning chime will sound and
the set speed indicator and own vehicle indicator will blink.
- When the SNOW mode switch is ON (To use the ICC system, turn
OFF the SNOW mode switch, push the MAIN switch to turn OFF
the ICC system and reset the ICC system by pushing the MAIN
switch again.)
- When the 4WD shift switch is not AUTO position. (To use the ICC
system, shift the AUTO position, push the MAIN switch to turn OFF
the ICC system and reset the ICC system by pushing the MAIN
switch again.)
- When the VDC is OFF. (To use the ICC system, turn ON the VDC system, push the MAIN switch to turn OFF the I CC system and reset the ICC system by pushing the MAIN
switch again.)
- When ABS or VDC (including the TCS) operates.
- When driving into a strong light (i.e., sunlight).
- When the wheel is slipping. (To use the ICC system, make sure the wheels are no longer spinning, push the
MAIN switch to turn OFF the ICC system and rese t the ICC system by pushing the MAIN switch again.)
Cancel Conditions
1. When CANCEL switch is pressed.
2. When brake pedal is depressed.
3. When the vehicle ahead is not detected below the speed of 24 km/h (15 MPH).
4. When the selector lever is not in the “D” position or manual mode.
5. When the parking brakes are applied.
6. When the system judges the vehicle is at standstill.
7. When the front wiper s are operating at HI.
(If the vehicle is equipped with a rain sensing auto-wi per, the system may cancel when the wipers are set
to AUTO.)
8. When the SNOW mode switch is turned ON.
9. When 4WD shift switch is not AUTO position
10. When ABS or VDC (including the TCS) operates.
11. When the MAIN switch is turned OFF.
12. When a wheel slips.
13. When driving into a strong light (i.e., sunlight).
14. When the VDC is turned OFF.
15. When the system malfunction occurs.
CONVENTIONAL (FIXED SPEED) CR UISE CONTROL MODE FUNCTION
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE FUNCTION : System
JPOIA0223ZZ
Revision: 2010 May2011 QX56

Page 754 of 5598

INFINITI QX56 2011 Factory Service Manual
CCS
SYSTEMCCS-19
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
DescriptionINFOID:0000000006224271
SYSTEM DIAGRAM
FUNCTION DESCRIPTION
This mode allows driving at a speed between 40 to 1

Page 755 of 5598

INFINITI QX56 2011 Factory Service Manual
CCS-20
< SYSTEM DESCRIPTION >[ICC]
SYSTEM
In the conventional (fixed speed) cruise control mode,
a warning chime does not sound to warn driver if own
vehicle are too close to the vehicle ahead, as n

CCS-20
< SYSTEM DESCRIPTION >[ICC]
SYSTEM
In the conventional (fixed speed) cruise control mode,
a warning chime does not sound to warn driver if own
vehicle are too close to the vehicle ahead, as neither the presence of the vehicle ahead nor the vehicle-to-
vehicle distance is detected.
OPERATION DESCRIPTION
To turn ON the conventional (fixed speed) cruise cont rol mode, push and hold the MAIN switch for longer than
approximately 1.5 seconds when ICC system is OFF.
When pushing the MAIN switch ON, the ICC system display and the MAIN switch indicator are displayed on
the information display.
After hold the MAIN switch ON for longer than approxim ately 1.5 seconds, the ICC system display goes out.
The MAIN switch indicator stays lit and brings the system to standby state.
NOTE:
To turn on the vehicle-to-vehicle distance control mode again, turn OFF the system and quickly push (less
than 1.5 seconds) the MAIN switch.
When the DCA system is ON, the conventional (fixed speed) cruise control mode cannot be turned on even
though the MAIN switch is pushed and held.
To turn ON the conventional (fixed speed) cruise control mode, turn OFF the DCA system. Refer to DAS-68,
"System Description".
ADAS control unit performs the control as per the following:
Set Condition
When the system is under a standby state and the vehi cle speed is between approximately 40 km/h (25 MPH)
and 144 km/h (90 MPH), pushing the SET/COAST switch will start system control.
If the system is canceled by conditions 1-6 below, the sy stem will resume control at the last set cruising speed
by pushing the RESUME/ACCELERATE switch.
Cancel conditions1. When CANCEL switch is pressed.
2. When brake pedal depressed.
3. When the vehicle speed falls below approximately 32 km/h (20 MPH).
4. When the vehicle slows down more than 13 km/h (8 MPH) below the set speed.
5. When the selector lever is not in the “D” position or manual mode.
6. When the parking brakes are applied.
7. When the MAIN switch is turned OFF.
8. When VDC (including the TCS) operates.
9. When a wheel slips.
10. When the system malfunction occurs.
Constant
speed Comparing the set vehicle speed with the current vehicle speed, transmits the command to ECM via CAN communication
to reach the set vehicle speed, and controls the electronic throttle control actuator.
Revision: 2010 May2011 QX56

Page 756 of 5598

INFINITI QX56 2011 Factory Service Manual
CCS
OPERATIONCCS-21
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
OPERATION
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE FUNCTION
VEHICLE-TO-VEHICLE DISTANCE CONT ROL MODE FUNCTION : Switch

Page 757 of 5598

INFINITI QX56 2011 Factory Service Manual
CCS-22
< SYSTEM DESCRIPTION >[ICC]
OPERATION
SYSTEM CONTROL CONDITION DISPLAY
Quickly push (less than 1.5 seconds) and release the MAIN switch ON.
The MAIN switch indicator (cruise indicator), set di

Page 758 of 5598

INFINITI QX56 2011 Factory Service Manual
CCS
OPERATIONCCS-23
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
NOTE:
The display of the DCA system is given priority when the DCA system is ON in a standby mode. (The set vehi-
cle s

CCS
OPERATIONCCS-23
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
NOTE:
The display of the DCA system is given priority when the DCA system is ON in a standby mode. (The set vehi-
cle speed indicator, set distance indicator, and own vehicle indicator are not displayed).
APPROACH WARNING DISPLAY
If own vehicle comes closer to a vehicle ahead due to rapi d deceleration of that vehicle or if another vehicle
cuts in, the system warns the driver with the chim e and ICC system display. Decelerate by depressing the
brake pedal to maintain a safe vehicle distance if:
The chime sounds.
The vehicle ahead detection indicator and set distance indicator blink.
The warning chime may not sound in some cases when there is a short distance between vehicles. Some
examples are:
When the vehicles are traveling at the same s peed and the distance between vehicles is not changing.
When the vehicle ahead is traveling faster and the distance between vehicles is increasing.
When a vehicle cuts in at near own vehicle.
The warning chime will not sound when own vehicle approac hes vehicles that are parked or moving slowly.
The warning chime will not sound when the accele rator pedal is depressed, overriding the system.
The approach warning chime may sound and the system disp lay may blink when the ICC sensor detects some
reflectors which are fitted on vehicles in other lanes or on the side of the road.
This may cause the ICC system to dec elerate or accelerate the vehicle.
The ICC sensor may detect these reflectors when the vehicle is driven on winding roads, hilly roads or when
entering or exiting a curve.
The ICC sensor may also detect reflectors on narrow roads or in road construction zones.
In these cases driver will have to manually control the proper distance ahead of own vehicle.
Also, the sensor sensitivity can be affected by vehicle operation (steering maneuver or driving position in the
lane) or traffic or vehicle condition (for example, if a vehicle is being driven with some damage).
Control mode With a vehicle
aheadSet vehicle distance (Long)
Set vehicle distance (Middle)
Set vehicle distance (Short)
When the vehicle speed exceeds the set speed
Condition Display on ICC system display
JSOIA0297ZZ
JSOIA0298ZZ
JSOIA0299ZZ
JSOIA0300ZZ
Revision: 2010 May2011 QX56

Page 759 of 5598

INFINITI QX56 2011 Factory Service Manual
CCS-24
< SYSTEM DESCRIPTION >[ICC]
OPERATION
WARNING LAMP AND AUTOMATIC CANCELLATION DISPLAY
NOTE:
Condition Display on ICC system display
When own vehicle comes closer to the vehicle ahead and it is

CCS-24
< SYSTEM DESCRIPTION >[ICC]
OPERATION
WARNING LAMP AND AUTOMATIC CANCELLATION DISPLAY
NOTE:
Condition Display on ICC system display
When own vehicle comes closer to the vehicle ahead and it is judged that the distance be-
tween the vehicles is not sufficient
JSOIA0301ZZ
Condition Description Display on ICC system display
Warning
display When the VDC is turned OFF
When the VDC or ABS (in-
cluding the TCS) operates
When a wheel slips
When the 4WD shift switch is not AUTO
When the SNOW mode switch is turned ON
When driving into a strong light (i.e., sunlight) A chime sounds and the control is automatically
canceled.
NOTE:
When the conditions listed above are no longer
present, turn the system OFF using the MAIN
switch.
Turn the ICC system back on to use the system.
When the sensor window is
dirty, making it impossible to de-
tect a vehicle ahead. A chime sounds and the control is automatically
canceled.
NOTE:
Park the vehicle in a safe place, turn the engine
OFF.
Clean the sensor window with a soft cloth and
then perform the settings again.
When the ICC system is mal-
functioning A chime sounds and the control is automatically
canceled.
NOTE:
Turn the engine OFF and restart engine. If there
is no malfunction, it is possible to set the system.
Automatic
cancella-
tion display When brake pedal is de-
pressed
When CANCEL switch is pressed
When a vehicle ahead is not
detected below the speed of
24 km/h (15 MPH)
When the system judges the
vehicle is at standstill
When the selector lever is not in “D” position or manual
mode
When the front wipers are op- erating at HI
(If the vehicle is equipped
with a rain sensing auto-wip-
er, the system may cancel
when the wipers are set to
AUTO)
When the parking brake are
applied A chime sounds and the control is automatically
canceled.
NOTE:
The system will be in a standby, after the control
is automatically canceled.
A chime sounds when the control is automati-
cally canceled, except when brake pedal is de-
pressed or when CANCEL switch is pressed.
JSOIA0302ZZ
JSOIA0303ZZ
JSOIA0304ZZ
JSOIA0292ZZ
Revision: 2010 May2011 QX56

Page 760 of 5598

INFINITI QX56 2011 Factory Service Manual
CCS
OPERATIONCCS-25
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
When the ICC system is automatically canceled, the cancellation condition can be displayed on “WORK SUP-
PORT” of C
