Page 2121 of 5598

INFINITI QX56 2011 Factory Service Manual
ECM
EC-97
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Priority Detected items (DTC)
1 U0101 CAN communication line U0113 U1003 CAN communication line
U1001 CAN commun

Page 2122 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-98
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
NOTE:
*: If “P1197” is displayed with other DTC in priority 1, perform trouble diagnosis for “P1197” first.
DTC IndexINFOID:0000000006217733
×

EC-98
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
NOTE:
*: If “P1197” is displayed with other DTC in priority 1, perform trouble diagnosis for “P1197” first.
DTC IndexINFOID:0000000006217733
×
:Applicable —: Not applicable
2 P0031 P0032 P0051 P0052 Air fuel ratio (A/F) sensor 1 heater
P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater
P0075 P0081 Intake valve timing control solenoid valve
P0130 P0131 P0132 P0133 P0150 P0151 P0152 P015 3 P2A00 P2A03 Air fuel ratio (A/F) sensor 1
P0137 P0138 P0139 P0157 P0158 P0159 Heated oxygen sensor 2
P0190 - P0193 FRP sensor
P0441 EVAP control system purge flow monitoring
P0443 P0444 P0445 EVAP canister purge volume control solenoid valve
P0447 P0448 EVAP canister vent control valve
P0451 P0452 P0453 EVAP control system pressure sensor
P0550 Power steering pressure sensor
P0603 ECM power supply
P0710 P0717 P0720 P0729 P0730 P0731 P0732 P0733 P0734 P0735 P0740 P0744 P0745 P0750 P0775 P0780 P0795 P1730 P1734 P2713 P2722 P2731 P2807 A/T related sensors, solenoid valves and switches
P1087 P1088 VVEL system
P1090 P1093 VVEL actuator motor
P1091 VVEL actuat or motor relay
P1217 Engine over temperature (OVERHEAT)
P1650 Starter motor relay 2
P1651 Starter motor relay
P2101 Electric throttle control function
P2118 Throttle control motor
P1805 Brake switch
P2100 P2103 Throttle control motor relay
P2101 Electric throttle control function
3 P0011 P0021 Intake valve timing control P0087, P0088, P0090 FRP control system
P008A Low fuel pressure control system
P008B Low fuel pressure control system
P0171 P0172 P0174 P0175 Fuel injection system function
P0201 - P0208 Injector
P0300 - P0308 Misfire
P0420 P0430 Three way catalyst function
P0456 EVAP control system (VERY SMALL LEAK)
P0506 P0507 Idle speed control system
P050E Cold start control
P0524 Engine oil pressure
P1148 P1168 Closed loop control
P1212 TCS communication line
P1421 Cold start control
P1564 ASCD steering switch / ICC steering switch
P1652 Starter motor system communication
P2119 Electric throttle control actuator
P1564 ASCD steering switch / ICC steering switch
P1568 ICC command value
P1572 ASCD brake switch / ICC brake switch
P1574 ASCD vehicle speed sensor / ICC vehicle speed sensor
Priority Detected items (DTC)
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL
Reference
page
CONSULT-III
GST*
2ECM*3
U0101 0101 LOST COMM (TCM) — 1 ×EC-171
U0113 0113 CAN COMM CIRCUIT — 1 ×EC-173
U1001
1001*4CAN COMM CIRCUIT — 1 or 2 — EC-172
U1003 1003 CAN COMM CIRCUIT — 2 — EC-173
Revision: 2010 May2011 QX56

Page 2123 of 5598

INFINITI QX56 2011 Factory Service Manual
ECM
EC-99
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OU1024 1024 VVEL CAN COMM CIRCUIT — 1
×EC-175
P0000 0000 NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED. —�

Page 2124 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-100
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
P0139 0139 HO2S2 (B1)
×2×EC-257
P0150 0150 A/F SENSOR1 (B2) ×2×EC-228
P0151 0151 A/F SENSOR1 (B2) — 2 ×EC-232
P0152 0152 A/F SENSOR1 (B2) — 2

Page 2125 of 5598

INFINITI QX56 2011 Factory Service Manual
ECM
EC-101
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OP0327 0327 KNOCK SEN/CIRC-B1 — 2 —
EC-297
P0328 0328 KNOCK SEN/CIRC-B1 — 2 —
P0332 0332 KNOCK SEN/CIRC-B2 —

ECM
EC-101
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OP0327 0327 KNOCK SEN/CIRC-B1 — 2 —
EC-297
P0328 0328 KNOCK SEN/CIRC-B1 — 2 —
P0332 0332 KNOCK SEN/CIRC-B2 — 2 —
P0333 0333 KNOCK SEN/CIRC-B2 — 2 —
P0335 0335 CKP SEN/CIRCUIT — 2×EC-299
P0340 0340 CMP SEN/CIRC-B1 — 2 ×
EC-303
P0345 0345 CMP SEN/CIRC-B2 — 2 ×
P0420 0420 TW CATALYST SYS-B1 ×2 ×
EC-307
P0430 0430 TW CATALYST SYS-B2 ×2 ×
P0441 0441 EVAP PURG FLOW/MON ×2 ×EC-312
P0443 0443 PURG VOLUME CONT/V — 2 ×EC-317
P0444 0444 PURG VOLUME CONT/V — 2 ×
EC-322
P0445 0445 PURG VOLUME CONT/V — 2 ×
P0447 0447 VENT CONTROL VALVE — 2 ×EC-325
P0448 0448 VENT CONTROL VALVE — 2 ×EC-329
P0451 0451 EVAP SYS PRES SEN — 2 ×EC-333
P0452 0452 EVAP SYS PRES SEN — 2 ×EC-336
P0453 0453 EVAP SYS PRES SEN — 2 ×EC-341
P0456 0456 EVAP VERY SML LEAK
×*82 ×EC-346
P0460 0460 FUEL LEV SEN SLOSH — 2 ×EC-352
P0461 0461 FUEL LEVEL SENSOR — 2 ×EC-353
P0462 0462 FUEL LEVL SEN/CIRC — 2 ×EC-355
P0463 0463 FUEL LEVL SEN/CIRC — 2 ×EC-355
P0500 0500
VEH SPEED SEN/CIRC*5—2 ×EC-356
P0506 0506 ISC SYSTEM — 2 ×EC-358
P0507 0507 ISC SYSTEM — 2 ×EC-360
P050E 050E COLD START CONTROL — 2 ×EC-362
P0524 0524 ENGINE OIL PRESSURE — 2 ×EC-364
P0527 0527 COOLING FAN SPD SEN — 2 — EC-367
P0550 0550 PW ST P SEN/CIRC — 2 —EC-371
P0603 0603 ECM BACK UP/CIRCUIT — 2×EC-374
P0605 0605 ECM — 1 or 2 × or — EC-376
P0607 0607 ECM — 1 ×EC-378
P0611 0611 FIC MODULE — 2 ×EC-379
P062B 062B ECM — 2 × or — EC-380
P0643 0643 SENSOR POWER/CIRC — 1 ×EC-381
P0705 0705 T/M RANGE SENSOR A — 2 ×TM-106
P0710 0710
FLUID TEMP SENSOR*7—2 ×TM-107
P0717 0717 INPUT SPEED SENSOR A — 2 ×TM-109
P0720 0720
OUTPUT SPEED SENSOR*5—2 ×TM-110
P0729 0729
6GR INCORRECT RATIO*7—2 ×TM-114
P0730 0730 INCORRECT GR RATIO — 2 ×TM-116
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL Reference
page
CONSULT-III
GST*
2ECM*3
Revision: 2010 May2011 QX56

Page 2126 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-102
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
P0731 0731
1GR INCORRECT RATIO*7—2 ×TM-118
P0732 0732
2GR INCORRECT RATIO*7—2 ×TM-120
P0733 0733
3GR INCORRECT RATIO*7—2 ×TM-122
P0734 0734
4

Page 2127 of 5598

INFINITI QX56 2011 Factory Service Manual
ECM
EC-103
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: 1st trip DTC No. is
the same as DTC No.
P1572 1572 ASCD BRAKE SW — 1 —
EC-438
(with ASCD)
EC-443
(with ICC)

Page 2128 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-104
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSA

EC-104
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
*5: When the fail safe operations for both self-diagnoses occur, the MIL illuminates.
*6: When the ECM is in the mode that displays SRT status, MIL may blink. For the details, refer to “How to Display SRT Status”.
*7: When erasing this DTC, al ways use CONSULT-III or GST.
*8: SRT code will not be set if the self-diagnostic result is NG.
Test Value and Test LimitINFOID:0000000006217734
The following is the information specified in Service $06 of ISO 15031-5.
The test value is a parameter used to determine whether a system/circuit diagnostic test is OK or NG while
being monitored by the ECM during self-diagnosis. The test limit is a reference value which is specified as the
maximum or minimum value and is compared with the test value being monitored.
These data (test value and test limit) are specified by On Board Monitor ID (OBDMID), Test ID (TID), Unit and
Scaling ID and can be displayed on the GST screen.
The items of the test value and test limit will be di splayed with GST screen which items are provided by the
ECM. (e.g., if bank 2 is not applied on this v ehicle, only the items of bank 1 are displayed)
ItemOBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
HO2S 01H
Air fuel ratio (A/F) sensor 1
(Bank 1) P0131 83H 0BH
Minimum sensor output voltage for test
cycle
P0131 84H 0BH Maximum sensor output voltage for test
cycle
P0130 85H 0BH Minimum sensor output voltage for test
cycle
P0130 86H 0BH Maximum sensor output voltage for test
cycle
P0133 87H 04H Response rate: Response ratio (Lean to
Rich)
P0133 88H 04H Response rate: Response ratio (Rich to
Lean)
P2A00 89H 84H The amount of shift in air fuel ratio
P2A00 8AH 84H The amount of shift in air fuel ratio P0130 8BH 0BH Difference in sensor output voltage
P0133 8CH 83H Response gain at the limited frequency
02H Heated oxygen sensor 2
(Bank 1) P0138 07H 0CH
Minimum sensor output voltage for test
cycle
P0137 08H 0CH Maximum sensor output voltage for test
cycle
P0138 80H 0CH Sensor output voltage
P0139 81H 0CH Difference in sensor output voltage
03H Heated oxygen sensor 3
(Bank 1) P0143 07H 0CH
Minimum sensor output voltage for test
cycle
P0144 08H 0CH Maximum sensor output voltage for test
cycle
P0146 80H 0CH Sensor output voltage
P0145 81H 0CH Difference in sensor output voltage
Revision: 2010 May2011 QX56
