INFINITI QX56 2011 Factory Service Manual WCS COMPONENT PARTSWCS-5 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O P Combination MeterINFOID:0000000006222539 The buzzer (1) for the warning chime system is integrated in the combination mete

Page 5410 of 5598

INFINITI QX56 2011 Factory Service Manual WCS-6 < SYSTEM DESCRIPTION > SYSTEM SYSTEM WARNING CHIME SYSTEM WARNING CHIME SYSTEM : System DiagramINFOID:0000000006222683 WARNING CHIME SYSTEM : System DescriptionINFOID:0000000006222684 COMBINATI

Page 5411 of 5598

INFINITI QX56 2011 Factory Service Manual WCS SYSTEMWCS-7 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O P WARNING CHIME SYSTEM : Fail-SafeINFOID:0000000006369726 FA I L - S A F E The combination meter activates the fail-safe contro l if

Page 5412 of 5598

INFINITI QX56 2011 Factory Service Manual WCS-8 < SYSTEM DESCRIPTION > SYSTEM LIGHT REMINDER WARNING CHIME LIGHT REMINDER WARNING CHIME : System DiagramINFOID:0000000006222543 LIGHT REMINDER WARNING CHIME : System DescriptionINFOID:000000000

Page 5413 of 5598

INFINITI QX56 2011 Factory Service Manual WCS SYSTEMWCS-9 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O P Warning is canceled if any of t he following conditions is fulfilled. SIGNAL PATH 1. BCM requires warning chime output to combinati

Page 5414 of 5598

INFINITI QX56 2011 Factory Service Manual WCS-10 < SYSTEM DESCRIPTION > SYSTEM FRONT FOG LIGHT REMINDER WARNING CHIME : System Diagram INFOID:0000000006222545 FRONT FOG LIGHT REMINDER WARNING CHIME : System DescriptionINFOID:0000000006222546

Page 5415 of 5598

INFINITI QX56 2011 Factory Service Manual WCS SYSTEMWCS-11 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O P SEAT BELT WARNING CHIME : System DiagramINFOID:0000000006222685 SEAT BELT WARNING CHIME : System DescriptionINFOID:000000000622268

Page 5416 of 5598

INFINITI QX56 2011 Factory Service Manual WCS-12 < SYSTEM DESCRIPTION > SYSTEM TIMING CHART SOUND SPECIFICATION PARKING BRAKE RELEASE WARNING CHIME PARKING BRAKE RELEASE WARNING CHIME : System DiagramINFOID:0000000006222547 PARKING BRAKE REL
