Page 3049 of 5598

INFINITI QX56 2011 Factory Service Manual GW-20 < REMOVAL AND INSTALLATION > FRONT DOOR GLASS 13. Remove front door lower sash mounting bolt and pull it out of front door panel. INSTALLATION Install in the reverse order of removal. Inspectio

Page 3050 of 5598

INFINITI QX56 2011 Factory Service Manual FRONT REGULATORGW-21 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P FRONT REGULATOR Exploded ViewINFOID:0000000006220825 Removal and InstallationINFOID:0000000006220826 REMOVAL 1. Remov

Page 3051 of 5598

INFINITI QX56 2011 Factory Service Manual GW-22 < REMOVAL AND INSTALLATION > FRONT REGULATOR Inspection and Adjustment INFOID:0000000006220828 SYSTEM INITIALIZATION Initialize the system if any of the following work has been done. Refer to

Page 3052 of 5598

INFINITI QX56 2011 Factory Service Manual REAR DOOR GLASSGW-23 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P REAR DOOR GLASS Exploded ViewINFOID:0000000006220829 Removal and InstallationINFOID:0000000006220830 REMOVAL 1. Remov

Page 3053 of 5598

INFINITI QX56 2011 Factory Service Manual GW-24 < REMOVAL AND INSTALLATION > REAR DOOR GLASS 8. Operate the power window switch to raise or lower the door win-dow until the glass mounting bolts can be seen. 9. Remove the rear door glass moun

Page 3054 of 5598

INFINITI QX56 2011 Factory Service Manual REAR DOOR GLASSGW-25 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P 19. Slide partition glass toward the vehicle and remove it as shown in the figure. INSTALLATION Install in the revers

Page 3055 of 5598

INFINITI QX56 2011 Factory Service Manual GW-26 < REMOVAL AND INSTALLATION > REAR REGULATOR REAR REGULATOR Exploded ViewINFOID:0000000006220832 Removal and InstallationINFOID:0000000006220833 REMOVAL 1. Remove rear door finisher. Refer to IN

Page 3056 of 5598

INFINITI QX56 2011 Factory Service Manual REAR REGULATORGW-27 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B GW N O P 8. Operate the power window switch to raise or lower the door win- dow until the glass mounting bolts can be seen. 9.
