Page 5097 of 5598

INFINITI QX56 2011 Factory Service Manual
PREPARATIONTM-9
< PREPARATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Commercial Service ToolINFOID:0000000006226737
*: Always check with the Parts Department for the latest parts informatio

Page 5098 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-10
< SYSTEM DESCRIPTION >[7AT: RE7R01B]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
A/T CONTROL SYSTEM
A/T CONTROL SYSTEM : Co
mponent Parts LocationINFOID:0000000006226738
1. Yaw rate/side

Page 5099 of 5598

INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSTM-11
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
NOTE:
The following components are included in the control valve & TCM (17).
TCM
Input speed sensor 1, 2

COMPONENT PARTSTM-11
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
NOTE:
The following components are included in the control valve & TCM (17).
TCM
Input speed sensor 1, 2
A/T fluid temperature sensor
Transmission range switch
Direct clutch solenoid valve
High and low reverse clutch solenoid valve
Input clutch solenoid valve
Front brake solenoid valve
Low brake solenoid valve
Anti-interlock solenoid valve
2346 brake solenoid valve
Line pressure solenoid valve
Torque converter clutch solenoid valve
A/T CONTROL SYSTEM : Component DescriptionINFOID:0000000006226739
Name Function
TCM TM-12, "
A/T CONTROL SYSTEM : TCM"
Transmission range switchTM-12, "A/T CONTROL SYSTEM : Transmission Range Switch"
Output speed sensor TM-12, "A/T CONTROL SYSTEM : Output Speed Sensor"
Input speed sensor 1
TM-12, "A/T CONTROL SYSTEM : Input Speed Sensor"Input speed sensor 2
A/T fluid temperature sensorTM-12, "
A/T CONTROL SYSTEM : A/T Fluid Temperature Sensor"
Input clutch solenoid valve TM-12, "A/T CONTROL SYSTEM : Input Clutch Solenoid Valve"
Front brake solenoid valve TM-12, "A/T CONTROL SYSTEM : Front Brake Solenoid Valve"
Direct clutch solenoid valveTM-12, "A/T CONTROL SYSTEM : Direct Clutch Solenoid Valve"
High and low reverse clutch solenoid valveTM-13, "A/T CONTROL SYSTEM : High and Low Reverse Clutch Solenoid Valve"
Low brake solenoid valve TM-13, "A/T CONTROL SYSTEM : Low Brake Solenoid Valve"
Anti-interlock solenoid valve TM-13, "A/T CONTROL SYSTEM : Anti-interlock Solenoid Valve"
2346 brake solenoid valve TM-13, "A/T CONTROL SYSTEM : 2346 Brake Solenoid Valve"
Torque converter clutch solenoid valveTM-13, "A/T CONTROL SYSTEM : Torque Converter Clutch Solenoid Valve"
Line pressure solenoid valve TM-13, "A/T CONTROL SYSTEM : Line Pressure Solenoid Valve"
Accelerator pedal position sensor TM-13, "A/T CONTROL SYSTEM : Accelerator Pedal Position Sensor"
Manual mode switch TM-13, "A/T CONTROL SYSTEM : Manual Mode Switch"
Tow mode switch TM-14, "A/T CONTROL SYSTEM : Tow Mode Switch"
A/T CHECK indicator lampTM-14, "A/T CONTROL SYSTEM : A/T CHECK Indicator Lamp"
Tow mode indicator lamp* TM-14, "A/T CONTROL SYSTEM : Tow Mode Indicator Lamp"
Selector lever position indicator TM-14, "A/T CONTROL SYSTEM : Selector Lever Position Indicator"
Stop lamp switch BRC-15, "Stop Lamp Switch"
Yaw rate/side G sensorBRC-15, "Yaw Rate/Side/Decel G sensor"
Starter relay STR-6, "System Description"
ECMEC-35, "ENGINE CONTROL SYSTEM : System Description"
BCM BCS-6, "BODY CONTROL SYSTEM : System Description"
Combination meter MWI-9, "METER SYSTEM : System Description"
ABS actuator and electric unit (control unit) BRC-16, "System Description"
Revision: 2010 May2011 QX56

Page 5100 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-12
< SYSTEM DESCRIPTION >[7AT: RE7R01B]
COMPONENT PARTS
A/T CONTROL SYSTEM : TCM
INFOID:0000000006226740
The TCM consists of a microcomputer and connectors for signal input and output and for p

TM-12
< SYSTEM DESCRIPTION >[7AT: RE7R01B]
COMPONENT PARTS
A/T CONTROL SYSTEM : TCM
INFOID:0000000006226740
The TCM consists of a microcomputer and connectors for signal input and output and for power supply. The
TCM controls the A/T.
The TCM is integral with the control valve assembly and built into the A/T assembly.
A/T CONTROL SYSTEM : Tr ansmission Range SwitchINFOID:0000000006226741
The transmission range switch incorpor ates four contact switches. Each contact switch transmits an ON/
OFF signal to the TCM.
The TCM judges a select lever position from a comb ination of ON/OFF signals transmitted from each con-
tact switch.
A/T CONTROL SYSTEM : Input Speed SensorINFOID:0000000006226742
The input speed sensor detects input shaft rpm (revolutions per minute). It is located on the input side of the A/
T. Monitors revolution of sensor 1 and sensor 2 for non-standard conditions.
A/T CONTROL SYSTEM : Output Speed SensorINFOID:0000000006226743
The output speed sensor detects the revolution of t he parking gear and emits a pulse signal. The pulse signal
is transmitted to the TCM which converts it into vehicle speed.
A/T CONTROL SYSTEM : A/T Fluid Temperature SensorINFOID:0000000006226744
The A/T fluid temperature sensor detects the A/T fluid temperature and transmits a signal to the TCM.
A/T CONTROL SYSTEM : Input Clutch Solenoid ValveINFOID:0000000006226745
The Input clutch solenoid valve is controlled by the TCM in response to signals transmitted from the trans-
mission range switch, output speed sensor and accelerato r pedal position sensor. Gears will then be shifted
to the optimum position.
The Input clutch solenoid valve controls the input cl utch control valve in response to a signal transmitted
from the TCM.
A/T CONTROL SYSTEM : Front Brake Solenoid ValveINFOID:0000000006226746
The front brake solenoid valve is controlled by the TC M in response to signals transmitted from the transmis-
sion range switch, output speed sensor and accelerator pedal position sensor. Gears will then be shifted to
the optimum position.
The front brake solenoid valve controls the front brak e control valve in response to a signal transmitted from
the TCM.
A/T CONTROL SYSTEM : Direc t Clutch Solenoid ValveINFOID:0000000006226747
The direct clutch solenoid valve is controlled by t he TCM in response to signals transmitted from the trans-
mission range switch, output speed sensor and accelerato r pedal position sensor. Gears will then be shifted
to the optimum position.
The direct clutch solenoid valve controls the direct clutch control valve in response to a signal transmitted
from the TCM.
Select lever position Transmission range switch
SW1 SW2 SW3 SW4
POFFOFFOFFOFF
RONOFFOFFON
NONONOFFOFF
D and M ONONONON
Revision: 2010 May2011 QX56

Page 5101 of 5598

INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSTM-13
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
A/T CONTROL SYSTEM : High and Lo w Reverse Clutch Solenoid ValveINFOID:0000000006226748
The high and low r

COMPONENT PARTSTM-13
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
A/T CONTROL SYSTEM : High and Lo w Reverse Clutch Solenoid ValveINFOID:0000000006226748
The high and low reverse clutch solenoid valve is controlled by the TCM in response to signals transmitted
from the transmission range switch, output speed sens or and accelerator pedal position sensor. Gears will
then be shifted to the optimum position.
The high and low reverse clutch solenoid valve controls the high and low reverse clutch control valve in response to a signal transmitted from the TCM.
A/T CONTROL SYSTEM : Lo w Brake Solenoid ValveINFOID:0000000006226749
The low brake solenoid valve is controlled by the TC M in response to signals transmitted from the transmis-
sion range switch, output speed sensor and accelerator pedal position sensor. Gears will then be shifted to
the optimum position.
The low brake solenoid valve controls the low brake control valve in response to a signal transmitted from
the TCM.
A/T CONTROL SYSTEM : Anti-interlock Solenoid ValveINFOID:0000000006226750
Anti-interlock solenoid valve prevents the simultaneous activation of the input clutch and the low brake.
The anti-interlock solenoid valve is an ON/OFF type solenoid valve.
A/T CONTROL SYSTEM : 2 346 Brake Solenoid ValveINFOID:0000000006226751
The 2346 brake solenoid valve is controlled by the TC M in response to signals transmitted from the trans-
mission range switch, output speed sensor and accelera tor pedal position sensor. Gears will then be shifted
to the optimum position.
The 2346 brake solenoid valve controls the 2346 brake c ontrol valve in response to a signal transmitted from
the TCM.
A/T CONTROL SYSTEM : Torque Co nverter Clutch Solenoid ValveINFOID:0000000006226752
The torque converter clutch solenoid va lve is activated, with the gear in D2, D3, D4, D5, D6, D7, M2, M3, M4,
M5, M6 and M7 by the TCM in response to signals tr ansmitted from the output speed sensor and accelerator
pedal position sensor. Torque converter clut ch piston operation will then be controlled.
A/T CONTROL SYSTEM : Line Pressure Solenoid ValveINFOID:0000000006226753
The line pressure solenoid valve regulates the oil pum p discharge pressure to suit the driving condition in
response to a signal transmitted from the TCM.
A/T CONTROL SYSTEM : Accele rator Pedal Position SensorINFOID:0000000006226754
The accelerator pedal position sensor is installed on the upper end of the accelerator pedal assembly.
The accelerator pedal position sensor detects the accelerator position.
The accelerator pedal position sensor transform the a ccelerator pedal position into output voltage, and emit
the voltage signal to the ECM. Then, the TCM receives accelerator pedal position signal from the ECM via
CAN communication.
A/T CONTROL SYSTEM : Manual Mode SwitchINFOID:0000000006226755
The manual mode switch [mode select switch and position se lect switch (shift-up/shift-down)] is installed in
the A/T shift selector assembly.
The mode select switch detects the position (the main shift gate side or manual shift gate side) of the selec-
tor lever and transmits a manual mode signal or a not manual mode signal to the combination meter. Then,
the TCM receives a manual mode signal or non-manual mode signal from the combination meter.
The position select switch (shift-up) detects that the se lector lever is shifted to the shift-up side of the manual
shift gate and transmits a manual mode shift up signal to the combination meter. Then, the TCM receives a
manual mode shift up signal from the combination meter.
The position select switch (shift-down) detects that the selector lever is shifted to the shift-down side of the
manual shift gate and transmits a manual mode shift down signal to the combination meter. Then, the TCM
receives a manual mode shift down signal from the combination meter.
Revision: 2010 May2011 QX56

Page 5102 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-14
< SYSTEM DESCRIPTION >[7AT: RE7R01B]
COMPONENT PARTS
A/T CONTROL SYSTEM : Tow Mode Switch
INFOID:0000000006226756
Tow mode switch is integrated in to
Tow mode switch is integrated in to SN

Page 5103 of 5598

INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSTM-15
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
A/T SHIFT LOCK SYSTEM : Component Parts LocationINFOID:0000000006226760
A/T SHIFT LOCK SYSTEM : Component D

Page 5104 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-16
< SYSTEM DESCRIPTION >[7AT: RE7R01B]
STRUCTURE AND OPERATION
STRUCTURE AND OPERATION
TRANSMISSION
TRANSMISSION : Cross-Sectional ViewINFOID:0000000006226762
2WD MODELS
4WD MODELS
1. Low brake 2
