Page 2201 of 5598

INFINITI QX56 2011 Factory Service Manual
P0011, P0021 IVT CONTROLEC-177
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0011, P0021 IVT CONTROL
DTC LogicINFOID:0000000006217772
DTC DETECTION LOGIC
NOTE:
If DTC P0011 or P

P0011, P0021 IVT CONTROLEC-177
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0011, P0021 IVT CONTROL
DTC LogicINFOID:0000000006217772
DTC DETECTION LOGIC
NOTE:
If DTC P0011 or P0021 is displayed with DTC P0075
or P0081, first perform the trouble diagnosis for
DTC P0075, P0081. Refer to EC-193, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode with CONSULT-III.
2. Start engine and warm it up to the normal operating temperature.
3. Maintain the following conditions for at least 6 consecutive seconds. Hold the accelerator pedal as steady as possible.
4. Let engine idle for 25 seconds.
5. Check 1st trip DTC. WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-178, "Diagnosis Procedure"
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
WITH CONSULT-III
1. Select “DATA MONITOR” mode with CONSULT-III.
2. Maintain the following conditions for at least 20 consecutive seconds.
DTC No. Trouble diagnosis
(Trouble diagnosis con- tent) Detecting condition Possible cause
P0011 INT/V TIM CONT-B1
[Intake valve timing control
performance (bank 1)]
There is a gap between angle of target
and phase-control angle degree. Crankshaft position sensor
Camshaft position sensor
Intake valve timing control solenoid valve
Accumulation of debris to the signal pick-up
portion of the camshaft
Timing chain installation
Foreign matter caught in the oil groove for in- take valve timing control
P0021
INT/V TIM CONT-B2
[Intake valve timing control
performance (bank 2)]
ENG SPEED Less than 2,000 rpm (A constant rotation is maintained.)
COOLAN TEMP/S More than 70
°C (158 °F)
Selector lever P or N position
ENG SPEED 1,500 - 3,175 rpm (A constant rotation is maintained.)
COOLAN TEMP/S More than 70 °C (158 °F)
Revision: 2010 May2011 QX56

Page 2202 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-178
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0011, P0021 IVT CONTROL
CAUTION:
Always drive at a safe speed.
3. Check 1st trip DTC.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st tri

Page 2203 of 5598

INFINITI QX56 2011 Factory Service Manual
P0011, P0021 IVT CONTROLEC-179
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Accumulation of debris on the signal plate of camshaft front end
Chipping signal plate of camshaf

Page 2204 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-180
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0011, P0021 IVT CONTROL
2. Provide 12 V DC between intake valve timing control solenoid
valve terminals 1 and 2, and then interrupt it. Check that the
plunge

Page 2205 of 5598

INFINITI QX56 2011 Factory Service Manual
P0031, P0032, P0051, P0052 A/F SENSOR 1 HEATER
EC-181
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0031, P0032, P0051, P0052 A/F SENSOR 1 HEATER
DTC LogicINFOID:000000000621777

P0031, P0032, P0051, P0052 A/F SENSOR 1 HEATER
EC-181
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0031, P0032, P0051, P0052 A/F SENSOR 1 HEATER
DTC LogicINFOID:0000000006217775
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 10 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-181, "Diagnosis Procedure".
NG >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217776
1.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect air fuel ratio (A /F) sensor 1 harness connector.
2. Turn ignition switch ON.
3. Check the voltage between A/F sensor 1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
DTC No. Trouble diagnosis
(Trouble diagnosis content) DTC detecting condition Possible cause
P0031 A/F SEN1 HTR (B1)
[A/F sensor 1 heater (bank
1) control circuit low] The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively low voltage signal is sent to ECM
through the A/F sensor 1 heater.) Harness or connectors
(The A/F sensor 1 heater circuit is
open or shorted.)
A/F sensor 1 heater
P0032 A/F SEN1 HTR (B1)
[A/F sensor 1 heater (bank
1) control circuit high] The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively high voltage signal is sent to ECM
through the A/F sensor 1 heater.) Harness or connectors
(The A/F sensor 1 heater circuit is
shorted.)
A/F sensor 1 heater
P0051 A/F SEN1 HTR (B2)
[A/F sensor 1 heater (bank
2) control circuit low] The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively low voltage signal is sent to ECM
through the A/F sensor 1 heater.) Harness or connectors
(The A/F sensor 1 heater circuit is
open or shorted.)
A/F sensor 1 heater
P0052 A/F SEN1 HTR (B2)
[A/F sensor 1 heater (bank
2) control circuit high] The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively high voltage signal is sent to ECM
through the A/F sensor 1 heater.) Harness or connectors
(The A/F sensor 1 heater circuit is
shorted.)
A/F sensor 1 heater
DTC A/F sensor 1
Ground Voltage
Bank Connector Terminal
P0031, P0032 1 F67 5 Ground Battery voltage
P0051, P0052 2 F68 5
Revision: 2010 May2011 QX56

Page 2206 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-182
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0031, P0032, P0051, P00
52 A/F SENSOR 1 HEATER
2.DETECT MALFUNCTIONING PART
Check the following.
20 A fuse (No. 43)
Harness for open or short between A/F

Page 2207 of 5598

INFINITI QX56 2011 Factory Service Manual
P0031, P0032, P0051, P0052 A/F SENSOR 1 HEATER
EC-183
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OIs the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE

Page 2208 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-184
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0037, P0038, P0057,
P0058 HO2S2 HEATER
P0037, P0038, P0057, P0058 HO2S2 HEATER
DTC LogicINFOID:0000000006217778
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDU

EC-184
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0037, P0038, P0057,
P0058 HO2S2 HEATER
P0037, P0038, P0057, P0058 HO2S2 HEATER
DTC LogicINFOID:0000000006217778
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to the normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and keep the engine speed between 3,500 and 4,000 rpm for at least 1 minute under no load.
6. Let engine idle for 1 minute.
7. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-184, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217779
1.CHECK HEATED OXYGEN SENSOR 2 (HO2S2) POWER SUPPLY CIRCUIT
1. Disconnect heated oxygen sensor 2 (HO2S2) harness connector.
2. Turn ignition switch ON.
3. Check the voltage between HO2S2 harness connector and ground.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0037 HO2S2 HTR (B1)
[Heated oxygen sensor 2
heater (bank 1) control cir-
cuit low] The current amperage in the heated oxygen sensor
2 heater circuit is out of the normal range.
(An excessively low voltage signal is sent to ECM
through the heated oxygen sensor 2 heater.) Harness or connectors
(The heated oxygen sensor 2 heater
circuit is open or shorted.)
Heated oxygen sensor 2 heater
P0038 HO2S2 HTR (B1)
[Heated oxygen sensor 2
heater (bank 1) control cir-
cuit high] The current amperage in the heated oxygen sensor
2 heater circuit is out of the normal range.
(An excessively high voltage signal is sent to ECM
through the heated oxygen sensor 2 heater.) Harness or connectors
(The heated oxygen sensor 2 heater
circuit is shorted.)
Heated oxygen sensor 2 heater
P0057 HO2S2 HTR (B2)
[Heated oxygen sensor 2
heater (bank 2) control cir-
cuit low] The current amperage in the heated oxygen sensor
2 heater circuit is out of the normal range.
(An excessively low voltage signal is sent to ECM
through the heated oxygen sensor 2 heater.) Harness or connectors
(The heated oxygen sensor 2 heater
circuit is open or shorted.)
Heated oxygen sensor 2 heater
P0058 HO2S2 HTR (B2)
[Heated oxygen sensor 2
heater (bank 2) control cir-
cuit high] The current amperage in the heated oxygen sensor
2 heater circuit is out of the normal range.
(An excessively high voltage signal is sent to ECM
through the heated oxygen sensor 2 heater.) Harness or connectors
(The heated oxygen sensor 2 heater
circuit is shorted.)
Heated oxygen sensor 2 heater
Revision: 2010 May2011 QX56
