Page 249 of 5598
AV
BOSE AUDIO WITH NAVIGATION
AV-101
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K L
M B A
O P
JCNWM4834GB
Revision: 2010 May2011 QX56
Page 250 of 5598
AV-102
< WIRING DIAGRAM >
BOSE AUDIO WITH NAVIGATION
JCNWM4835GB
Revision: 2010 May2011 QX56
Page 251 of 5598
AV
BOSE AUDIO WITH NAVIGATION
AV-103
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K L
M B A
O P
JCNWM4836GB
Revision: 2010 May2011 QX56
Page 252 of 5598
AV-104
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORK FLOW
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work Flow (Multi AV)INFOID:0000000006216237
OVERALL SEQUENCE
Reference 1··· Refer to AV-39, "CONSULT-III Function".
Reference 2··· Refer to AV-57, "
DTC Index".
Reference 3··· Refer to AV-199, "
Symptom Table".
DETAILED FLOW
1.INTERVIEW AND SYMPTOM CONFIRMATION
Check the malfunction symptoms by performing the following items.
Interview the customer to obtain the malfunction information (conditions and environment when the malfunc-
tion occurred).
Check the symptom.
Is the occurred symptom malfunction?
YES >> GO TO 2.
NO >> INSPECTION END
2.DIAGNOSIS WITH CONSULT-III
JSNIA0732GB
Revision: 2010 May2011 QX56
Page 253 of 5598

AV
DIAGNOSIS AND REPAIR WORK FLOWAV-105
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
M B A
O P
1. Connect CONSULT-III and perform a self-diagnosis for “MULTI AV”. Refer to AV-39, "CONSULT-III Func-
tion".
NOTE:
Skip to step 4 of the diagnosis procedur e if “MULTI AV” is not displayed.
2. Check if any DTC is displayed in the self-diagnosis results.
Is DTC displayed?
YES >> GO TO 3.
NO >> GO TO 4.
3.TROUBLE DIAGNOSIS FOR DTC
1. Check the DTC indicated in the self-diagnosis results.
2. Perform the relevant diagnosis referring to the DTC Index. Refer to AV-57, "
DTC Index".
>> GO TO 5.
4.TROUBLE DIAGNOSIS FOR SYMPTOMS
Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to AV-199, "
Symptom
Table".
>> GO TO 5.
5.ERROR PART REPAIR
1. Repair or replace the identified malfunctioning parts.
2. Perform a self-diagnosis for “MULTI AV” with CONSULT-III. NOTE:
Erase the stored self-diagnosis results after repairi ng or replacing the relevant components if any DTC
has been indicated in the self-diagnosis results.
3. Check that the symptom does not occur.
Does the symptom occur?
YES >> GO TO 1.
NO >> INSPECTION END
Revision: 2010 May2011 QX56
Page 254 of 5598
AV-106
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORK FLOW
Work Flow (Camera Assistance Sonar)
INFOID:0000000006216238
OVERALL SEQUENCE
Reference 1··· Refer to AV-47, "CONSULT-III Function".
Reference 2··· Refer to AV-77, "
DTC Index".
Reference 3··· Refer to AV-199, "
Symptom Table".
DETAILED FLOW
1.INTERVIEW AND SYMPTOM CONFIRMATION
Check the malfunction symptoms by performing the following items.
Interview the customer to obtain the malfunction information (conditions and environment when the malfunc-
tion occurred).
Check the symptom.
Is the occurred symptom malfunction?
YES >> GO TO 2.
NO >> INSPECTION END
2.DIAGNOSIS WITH CONSULT-III
1. Connect CONSULT-III and perform a self-diagnosis for “SONAR”. Refer to AV-47, "
CONSULT-III Func-
tion".
NOTE:
Skip to step 4 of the diagnosis procedure if “SONAR” is not displayed.
JSNIA0732GB
Revision: 2010 May2011 QX56
Page 255 of 5598
AV
DIAGNOSIS AND REPAIR WORK FLOWAV-107
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
M B A
O P
2. Check if any DTC is displayed in the self-diagnosis results.
Is DTC displayed?
YES >> GO TO 3.
NO >> GO TO 4.
3.TROUBLE DIAGNOSIS FOR DTC
1. Check the DTC indicated in the self-diagnosis results.
2. Perform the relevant diagnosis referring to the DTC Index. Refer to AV-77, "
DTC Index".
>> GO TO 5.
4.TROUBLE DIAGNOSIS FOR SYMPTOMS
Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to AV-199, "
Symptom
Table".
>> GO TO 5.
5.ERROR PART REPAIR
1. Repair or replace the identified malfunctioning parts.
2. Perform a self-diagnosis fo r “SONAR” with CONSULT-III.
NOTE:
Erase the stored self-diagnosis results after repairi ng or replacing the relevant components if any DTC
has been indicated in the self-diagnosis results.
3. Check that the symptom does not occur.
Does the symptom occur?
YES >> GO TO 1.
NO >> INSPECTION END
Revision: 2010 May2011 QX56
Page 256 of 5598

AV-108
< BASIC INSPECTION >
ADDITIONAL SERVICE WHEN REPLACING (AV CONTROL UNIT)
ADDITIONAL SERVICE WHEN REPLACING (AV CONTROL UNIT)
DescriptionINFOID:0000000006216239
BEFORE REPLACEMENT
When replacing AV control unit, save or print current vehicle specification with CONSULT-III configuration
before replacement.
AFTER REPLACEMENT
CAUTION:
When replacing AV control unit, you must perform “WRITE CONFIGURATION” with CONSULT-III.
Complete the procedure of “WRITE CONFIGURATION” in order.
If you set incorrect “WRITE CONF IGURATION”, incidents might occur.
Configuration is different for each vehicle mode l. Confirm configuration of each vehicle model.
Work ProcedureINFOID:0000000006216240
1.SAVING VEHICLE SPECIFICATION
-CONSULT-III Configuration
Perform “READ CONFIGURATION” to save or prin t current vehicle specification. Refer to AV-109, "
Descrip-
tion".
NOTE:
If “READ CONFIGURATION” can not be used, use the “WRITE CONFIGURATION - Manual selection”.
>> GO TO 2.
2.REPLACE AV CONTROL UNIT
Replace AV control unit. Refer to AV-212, "
Removal and Installation".
>> GO TO 3.
3.WRITING VEHICLE SPECIFICATION
-CONSULT-III Configuration
Perform “WRITE CONFIGURATION - C onfig file” or “WRITE CONFIGURATION - Manual selection” to write
vehicle specification. Refer to AV-109, "
Work Procedure".
>> GO TO 4.
4.OPERATION CHECK
Check that the operation of the AV control unit and camera images (fixed guide lines and predictive course
lines) are normal.
>> WORK END
Revision: 2010 May2011 QX56
