EXHAUST GAS/OUTS IDE ODOR SENSOR
Removal and InstallationINFOID:0000000006276007
REMOVAL
1. Remove bumper molding. Refer to EXT-13, "Removal and Installation".
2. Remove bolt, and then remove exhaust gas/outside odor sensor.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56
Page 3258 of 5598
HAC-152
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONING]
DOOR MOTOR
DOOR MOTOR
Exploded ViewINFOID:0000000006276008
Front A/C unit
Rear A/C unit
JMIIA0645ZZ
1. A/C unit assembly 2. Upper ventilator door lever 3. Upper ventilator door link
4. Upper ventilator door motor 5. Air mix door motor LH 6. Air mix door adaptor B
7. Air mix door adaptor A 8. Intake door motor 9. Intake door motor lever
10. Intake door lever 11. Blower unit assembly 12. Foot door lever
13. Foot door link 14. Air mix door motor RH 15. Air mix door adaptor
16. Mode door motor 17. Mode door motor lever 18. Mode door motor bracket
19. Main link 20. Ventilator door link 21 Ventilator door lever
22. Defroster lever
JMIIA0646ZZ
Revision: 2010 May2011 QX56
Page 3259 of 5598
![INFINITI QX56 2011 Factory Service Manual
DOOR MOTORHAC-153
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
MODE DOOR MOTOR
MODE DOOR MOTOR : Re moval and InstallationINFOID:0000000006276009
REMOVA INFINITI QX56 2011 Factory Service Manual
DOOR MOTORHAC-153
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
MODE DOOR MOTOR
MODE DOOR MOTOR : Re moval and InstallationINFOID:0000000006276009
REMOVA](/manual-img/42/57033/w960_57033-3258.png)
DOOR MOTORHAC-153
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
MODE DOOR MOTOR
MODE DOOR MOTOR : Re moval and InstallationINFOID:0000000006276009
REMOVAL
1. Remove instrument lower panel RH. Refer to IP-14, "Removal and Installation".
2. Remove power steering control unit bracket.
3. Remove fixing screws (A), and then remove mode door motor (1).
4. Disconnect mode door motor connector.
INSTALLATION
Install in the reverse order of removal.
AIR MIX DOOR MOTOR
AIR MIX DOOR MOTOR : Re moval and InstallationINFOID:0000000006276010
REMOVAL
Driver side
1. Remove automatic drive position control unit. Refer to ADP-136, "Removal and Installation".
2. Remove fixing screws (A), and then remove air door motor LH (1).
3. Disconnect air mix door motor connector.
Passenger side
1. Remove heater core. Refer to HA-44, "HEATER CORE : Removal and Installation".
2. Remove fixing screws, and then remove air mix door motor RH.
INSTALLATION
Install in the reverse order of removal.
INTAKE DOOR MOTOR
INTAKE DOOR MOTOR : Re moval and InstallationINFOID:0000000006276011
REMOVAL
1. Remove blower unit assembly. Refer to VTL-15, "Removal and Installation".
2. Remove fixing screws, and then remove intake door motor.
1. Rear A/C unit assembly 2. Rear mode door lever 2 3. Rear mode door lever 1
4. Rear mode door motor 5. Rear air mix door motor
JMIIA0790ZZ
JMIIA0788ZZ
Revision: 2010 May2011 QX56
Page 3260 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-154
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONING]
DOOR MOTOR
3. Disconnect intake door motor connector.
INSTALLATION
Install in the reverse order of removal.
UPPER VENTILATOR DOOR MOT INFINITI QX56 2011 Factory Service Manual
HAC-154
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONING]
DOOR MOTOR
3. Disconnect intake door motor connector.
INSTALLATION
Install in the reverse order of removal.
UPPER VENTILATOR DOOR MOT](/manual-img/42/57033/w960_57033-3259.png)
HAC-154
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONING]
DOOR MOTOR
3. Disconnect intake door motor connector.
INSTALLATION
Install in the reverse order of removal.
UPPER VENTILATOR DOOR MOTOR
UPPER VENTILATOR DOOR MOTO
R : Removal and InstallationINFOID:0000000006276012
REMOVAL
1. Remove automatic drive position control unit. Refer to ADP-136, "Removal and Installation".
2. Remove fixing screws (A), and then remove intake door motor (1).
3. Disconnect intake door motor connector.
INSTALLATION
Install in the reverse order of removal.
REAR MODE DOOR MOTOR
REAR MODE DOOR MOTOR : Removal and InstallationINFOID:0000000006276013
REMOVAL
1. Remove luggage side lower finisher RH. Refer to INT-36, "LUGGAGE SIDE LOWER FINISHER :
Removal and Installation".
2. Remove fixing screws, and then remove rear mode door motor.
INSTALLATION
Install in the reverse order of removal.
REAR AIR MIX DOOR MOTOR
REAR AIR MIX DOOR MOTOR : Removal and InstallationINFOID:0000000006276014
REMOVAL
1. Remove rear A/C unit assembly. Refer to HA-47, "REAR A/C UNIT ASSEMBLY : Removal and Installa-
tion".
2. Remove fixing screws, and then remove air mix door motor.
INSTALLATION
Install in the reverse order of removal.
JMIIA0789ZZ
Revision: 2010 May2011 QX56
Page 3261 of 5598
IONIZER
HAC-155
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
IONIZER
Exploded ViewINFOID:0000000006276015
Refer to HA-41, "Exploded View".
Removal and InstallationINFOID:0000000006276016
Removal
1. Remove instrument lower panel LH. Refer to IP-14, "Removal and Installation".
2. Remove mounting screws, and then remove ionizer from A/C unit assembly. CAUTION:
Never tough the surface (ceramic part) of th e ionizer. It is the discharge electrode.
3. Disconnect ionizer harness connector.
INSTALLATION
Note the following item, install in the reverse order of removal.
CAUTION:
If there is dirt, use a clean clot h and clean the discharge electrode (ceramic part) of the ionizer.
Revision: 2010 May2011 QX56
Page 3262 of 5598
HRN-1
DRIVER CONTROLS
C
DE
F
G H
I
J
K
M
SECTION HRN
A
B
HRN
N
O P
CONTENTS
HORN
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
WIRING DIAGRAM .......................................3
HORN .................................................................3
Wiring Diagram .................................................... .....3
REMOVAL AND INSTALLATION ................6
HORN .................................................................6
Exploded View ..................................................... .....6
Removal and Installation ..........................................6
Revision: 2010 May2011 QX56
Page 3263 of 5598

HRN-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006220273
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Revision: 2010 May2011 QX56
Page 3264 of 5598
HORN
HRN-3
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K
M A
B
HRN
N
O P
WIRING DIAGRAM
HORN
Wiring DiagramINFOID:0000000006220274
