COMPONENT PARTSEC-25
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OEngine Coolant Temperature SensorINFOID:0000000006217669
The engine coolant temperature (ECT
) sensor is used to detect the
engine coolant temperature. The sensor modifies a voltage signal
from the ECM. The modified signal returns to the ECM as the engine
coolant temperature input. The sens or uses a thermistor which is
sensitive to the change in temperature. The electrical resistance of
the thermistor decreases as temperature increases.
*: These data are reference values and are measured between ECM terminals.
Engine Oil Temperature SensorINFOID:0000000006217670
The engine oil temperature sensor is used to detect the engine oil
temperature. The sensor modifies a voltage signal from the ECM.
The modified signal returns to the ECM as the engine oil tempera-
ture input. The sensor uses a ther mistor which is sensitive to the
change in temperature. The electrical resistance of the thermistor
decreases as temperature increases.
*: These data are reference values and are measured between ECM terminals. 1. Valve 2. Armature 3. Magnet Loop Element
4. Fan speed sensor 5. Coil 6. Silicon oil
SEF594K
Engine coolant temperature
[° C ( °F)] Voltage* (V) Resistance (k
Ω)
− 10 (14) 4.4 7.0 - 11.4
20 (68) 3.5 2.35 - 2.73
50 (122) 2.2 0.68 - 1.00
90 (194) 0.9 0.236 - 0.260
SEF012P
SEF594K
Engine oil temperature [° C ( °F)] Voltage* (V) Resistance (k
Ω)
–10 (14) 4.4 7.0 - 11.4 20 (68) 3.5 2.35 - 2.73
50 (122) 2.2 0.68 - 1.00
90 (194) 0.9 0.236 - 0.260
110 (230) 0.6 0.143 - 0.153
SEF012P
Revision: 2010 May2011 QX56
Page 2050 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-26
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
EVAP Control System Pressure Sensor
INFOID:0000000006256476
The EVAP control system pressure s ensor detects pressure in the
purge line. The sens INFINITI QX56 2011 Factory Service Manual
EC-26
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
EVAP Control System Pressure Sensor
INFOID:0000000006256476
The EVAP control system pressure s ensor detects pressure in the
purge line. The sens](/manual-img/42/57033/w960_57033-2049.png)
EC-26
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
EVAP Control System Pressure Sensor
INFOID:0000000006256476
The EVAP control system pressure s ensor detects pressure in the
purge line. The sensor output voltage to the ECM increases as pres-
sure increases.
EVAP Canister Vent Control ValveINFOID:0000000006256477
The EVAP canister vent control valve is located on the EVAP canis-
ter and is used to seal the canister vent.
This solenoid valve responds to signals from the ECM. When the
ECM sends an ON signal, the coil in the solenoid valve is energized.
A plunger will then move to seal the canister vent. The ability to seal
the vent is necessary for the on board diagnosis of other evaporative
emission control system components.
This solenoid valve is used only for diagnosis, and usually remains
opened.
When the vent is closed, under normal purge conditions, the evapo-
rative emission control system is depressurized and allows “EVAP
Control System” diagnosis.
EVAP Canister Purge Volume Control Solenoid ValveINFOID:0000000006217671
The EVAP canister purge volume control solenoid valve is used to
control the flow rate of fuel vapor from the EVAP canister. The EVAP
canister purge volume control solenoid valve is moved by ON/OFF
pulses from the ECM. The longer the ON pulse, the greater the
amount of fuel vapor that will flow through the valve.
Fuel InjectorINFOID:0000000006217672
For the fuel injector, a high pressure fuel injector is used and this
enables a high-pressure fuel injection at a high voltage within a short
time. The ECM is equipped with an injector driver unit and actuates
the fuel injector at a high volt age (approximately 65 V at the maxi-
mum).
Fuel Level SensorINFOID:0000000006217673
The fuel level sensor is mounted in the fuel level sensor unit.
PBIB3370E
PBIB1263E
JMBIA0069ZZ
JSBIA0287ZZ
Revision: 2010 May2011 QX56
Page 2051 of 5598
![INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEC-27
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
The sensor detects a fuel level in the fuel tank and tr
ansmits a signal to the combination meter. The combina-
ti INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEC-27
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
The sensor detects a fuel level in the fuel tank and tr
ansmits a signal to the combination meter. The combina-
ti](/manual-img/42/57033/w960_57033-2050.png)
COMPONENT PARTSEC-27
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
The sensor detects a fuel level in the fuel tank and tr
ansmits a signal to the combination meter. The combina-
tion meter sends the fuel level sensor signal to the ECM via the CAN communication line.
It consists of two parts, one is mechanical float and the ot her is variable resistor. Fuel level sensor output volt-
age changes depending on the movement of the fuel mechanical float.
Fuel Pump Control ModuleINFOID:0000000006217674
The fuel pump control module (FPCM) controls the discharging vol-
ume of the fuel pump by transmitt ing the FPCM control signals (Low/
Mid/High) depending on driving conditions.
Fuel Rail Pressure SensorINFOID:0000000006217675
The fuel rail pressure (FRP) sensor is placed to the fuel rail and
measures fuel pressure in the fuel rail. The sensor transmits voltage
signal to the ECM. As the pressure increases, the voltage rises. The
ECM controls the fuel pressure in the fuel rail by operating high pres-
sure fuel pump. The ECM uses the signal from fuel rail pressure sen-
sor as a feedback signal.
Fuel Tank Temperature SensorINFOID:0000000006217676
The fuel tank temperature sensor is used to detect the fuel tempera-
ture inside the fuel tank. The sensor modifies a voltage signal from
the ECM. The modified signal returns to the ECM as the fuel temper-
ature input. The sensor uses a ther mistor which is sensitive to the
change in temperature. The electrical resistance of the thermistor
decreases as temperature increases.
*: These data are reference values and are measured between ECM terminals.
Heated Oxygen Sensor 2INFOID:0000000006217677
DESCRIPTION
NNBIB0006ZZ
JSBIA0291ZZ
Fuel temperature [ °C ( °F)] Voltage* (V) Resistance (k Ω)
20 (68) 3.5 2.3 - 2.7
50 (122) 2.2 0.79 - 0.90
SEF012P
Revision: 2010 May2011 QX56
Page 2052 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-28
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
The heated oxygen sensor 2, after three way catalyst (manifold),
monitors the oxygen level in the exhaust gas on each bank.
Even if switching char INFINITI QX56 2011 Factory Service Manual
EC-28
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
The heated oxygen sensor 2, after three way catalyst (manifold),
monitors the oxygen level in the exhaust gas on each bank.
Even if switching char](/manual-img/42/57033/w960_57033-2051.png)
EC-28
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
The heated oxygen sensor 2, after three way catalyst (manifold),
monitors the oxygen level in the exhaust gas on each bank.
Even if switching characteristics of
the air fuel ratio (A/F) sensor 1
are shifted, the air fuel ratio is c ontrolled to stoichiometric, by the sig-
nal from the heated oxygen sensor 2.
This sensor is made of ceramic zirconia. The zirconia generates volt-
age from approximately 1 V in richer conditions to 0 V in leaner con-
ditions.
Under normal conditions the heated ox ygen sensor 2 is not used for
engine control operation.
HEATED OXYGEN SENSOR 2 HEATER
Heated oxygen sensor 2 heater is integrated in the sensor.
The ECM performs ON/OFF control of the heated oxy gen sensor 2 heater corresponding to the engine speed,
amount of intake air and engine coolant temperature.
High Pressure Fuel PumpINFOID:0000000006217678
The high pressure fuel pump is installed at the front of the engine bank 2 side and activated by the camshaft.
ECM controls the high pressure fuel pump control sol enoid valve built into the high pressure fuel pump and
adjusts the amount of discharge by changing the suction timing of the low pressure fuel.
Operating Description
SEF327R
Engine speed Heated oxygen sensor 2 heater
Above 3,600 rpm OFF
Below 3,600 rpm after the following conditions are met.
Engine: After warming up
Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at idle for 1 minute under no load ON
JSBIA0285GB
Revision: 2010 May2011 QX56
Page 2053 of 5598
![INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEC-29
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Operating Chart
ICC Brake Switch & Stop Lamp SwitchINFOID:0000000006217679
Stop lamp switch and ICC brake switch a INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEC-29
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Operating Chart
ICC Brake Switch & Stop Lamp SwitchINFOID:0000000006217679
Stop lamp switch and ICC brake switch a](/manual-img/42/57033/w960_57033-2052.png)
COMPONENT PARTSEC-29
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Operating Chart
ICC Brake Switch & Stop Lamp SwitchINFOID:0000000006217679
Stop lamp switch and ICC brake switch are installed to brake pedal bracket.
When the brake pedal is depressed, I
CC brake switch is turned OFF and stop lamp switch is turned ON.
ECM detects the state of the brake pedal by those two types of input (ON/OFF signal).
ECM transmits ICC brake switch signal to ADAS control unit via CAN communication line.
ICC Steering SwitchINFOID:0000000006217680
ICC steering switch has variant values of electrical resistance for each button. ECM reads voltage variation of
switch, and determines which button is operated.
ECM transmits ICC steering switch signal to ADAS control unit via CAN communication line.
Ignition Coil With Power TransistorINFOID:0000000006217681
The ignition signal from the ECM is sent to and amplified by the
power transistor. The power transistor turns ON and OFF the ignition
coil primary circuit. This ON/OFF operation induces the proper high
voltage in the coil secondary circuit.
Intake Valve Timing Control Solenoid ValveINFOID:0000000006217682
Intake valve timing control solenoid valve is activated by ON/OFF
pulse duty (ratio) signals from the ECM.
The intake valve timing control solenoid valve changes the oil
amount and direction of flow through intake valve timing control unit
or stops oil flow.
The longer pulse width advances valve angle.
The shorter pulse width retards valve angle.
When ON and OFF pulse widths become equal, the solenoid valve
stops oil pressure flow to fix the intake valve angle at the control
position.
JSBIA0286GB
PBID0206J
PBIB1842E
Revision: 2010 May2011 QX56
Page 2054 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-30
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
Knock Sensor
INFOID:0000000006217683
The knock sensor is attached to t he cylinder block. It senses engine
knocking using a piezoelectric element. INFINITI QX56 2011 Factory Service Manual
EC-30
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
Knock Sensor
INFOID:0000000006217683
The knock sensor is attached to t he cylinder block. It senses engine
knocking using a piezoelectric element.](/manual-img/42/57033/w960_57033-2053.png)
EC-30
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
Knock Sensor
INFOID:0000000006217683
The knock sensor is attached to t he cylinder block. It senses engine
knocking using a piezoelectric element. A knocking vibration from
the cylinder block is sensed as vibrational pressure. This pressure is
converted into a voltage signal and sent to the ECM.
Low Fuel Pressure SensorINFOID:0000000006217684
The low fuel pressure sensor is installed to low fuel pressure piping
and measures the low fuel pressu re. The sensor transmits voltage
signal to the ECM. As the pressure increases, the voltage rises.
Low Pressure Fuel PumpINFOID:0000000006217685
The low pressure fuel pump is integrated with a fuel pressure regula-
tor and a fuel filter. This pump is build into the fuel tank.
ECM controls the low pressure fuel pump via FPCM.
Malfunction Indicator Lamp (MIL)INFOID:0000000006217686
The Malfunction Indicator Lamp (MIL) is located on the combination
meter.
The MIL will illuminate when the ignition switch is turned ON without
the engine running. This is a bulb check.
When the engine is started, the MIL should turn off. If the MIL
remains illuminated, the on board diagnostic system has detected an
engine system malfunction.
For details, refer to EC-51, "
Diagnosis Description".
JSBIA0284ZZ
JSBIA0292ZZ
JPBIA3235ZZ
SEF217U
Revision: 2010 May2011 QX56
Page 2055 of 5598
![INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEC-31
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Manifold Absolute Pressure SensorINFOID:0000000006217687
The manifold absolute pressure (MAP) sensor is installed INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEC-31
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Manifold Absolute Pressure SensorINFOID:0000000006217687
The manifold absolute pressure (MAP) sensor is installed](/manual-img/42/57033/w960_57033-2054.png)
COMPONENT PARTSEC-31
< SYSTEM DESCRIPTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Manifold Absolute Pressure SensorINFOID:0000000006217687
The manifold absolute pressure (MAP) sensor is installed on the
intake manifold collector. Detects intake manifold pressure, and
transmits a voltage signal to the ECM.
The sensor uses a silicon diaphragm which is sensitive to the
change in pressure. As the pressu
re increases, the voltage rises.
Mass Air Flow Sensor (With Intake Air Temperature Sensor)INFOID:0000000006217688
MASS AIR FLOW SENSOR
The mass air flow (MAF) sensor (1) is placed in the stream of intake
air. It measures the intake flow ra te by measuring a part of the entire
intake flow. The mass air flow sens or controls the temperature of the
hot wire to a certain amount. The heat generated by the hot wire is
reduced as the intake air flows around it. The greater air flow, the
greater the heat loss.
Therefore, the electric current supplied to hot wire is changed to
maintain the temperature of the hot wire as air flow increases. The
ECM detects the air flow by means of this current change.
INTAKE AIR TEMPERATURE SENSOR
The intake air temperature (IAT) sensor is built-into t he mass air flow sensor. The sensor detects intake air
temperature and transmits a signal to the ECM.
The temperature sensing unit uses a thermistor which is sensitive to the change in temperature. Electrical
resistance of the thermistor decreases in response to the rise in temperature.
*: These data are reference values and are measured between ECM terminals.
Power Steering Pressure (PSP) SensorINFOID:0000000006217689
Power steering pressure (PSP) sensor is installed to the power steering high-pressure tube and detects a
power steering load.
This sensor is a potentiometer which transforms the power steering load into output voltage, and emits the
voltage signal to the ECM. The ECM controls the electric throttle control actuator and adjusts the throttle valve
opening angle to increase the engine speed and adjusts the idle speed for the increased load.
JMBIA0877ZZ
PBIA9559J
Intake air temperature
[° C ( °F)] Voltage* (V) Resistance (k
Ω)
25 (77) 3.3 1.94 - 2.06
80 (176) 1.2 0.293 - 0.349
SEF012P
Revision: 2010 May2011 QX56
Page 2056 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-32
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
Refrigerant Pressure Sensor
INFOID:0000000006217690
The refrigerant pressure sensor is installed at the c ondenser of the air conditioner system. INFINITI QX56 2011 Factory Service Manual
EC-32
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
Refrigerant Pressure Sensor
INFOID:0000000006217690
The refrigerant pressure sensor is installed at the c ondenser of the air conditioner system.](/manual-img/42/57033/w960_57033-2055.png)
EC-32
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
Refrigerant Pressure Sensor
INFOID:0000000006217690
The refrigerant pressure sensor is installed at the c ondenser of the air conditioner system. The sensor uses an
electrostatic volume pressure transducer to convert refrigerant pressure to voltage. The voltage signal is sent
to ECM, and ECM controls cooling fan system.
VVEL Actuator MotorINFOID:0000000006217691
The VVEL actuator motor rotates the control shaft acco rding to the control signal from the VVEL control mod-
ule. The VVEL control module judges whether the VVEL actuator motor controls the angle properly by the
VVEL control shaft position sensor signal.
VVEL Actuator Motor RelayINFOID:0000000006217692
Power supply for the VVEL actuator motor is provided to the VVEL control module via VVEL actuator motor
relay. VVEL actuator motor relay is ON/OFF controll ed by the VVEL control module. In addition, when the
VVEL actuator motor relay cannot be controlled by the VVEL control module for some reason, it ON/OFF con-
trolled by ECM.
VVEL Control ModuleINFOID:0000000006217693
The VVEL control module consists of a microcomputer and connec-
tors for signal input and output and for power supply. The VVEL con-
trol module controls VVEL system.
VVEL Control Shaft Position SensorINFOID:0000000006217694
VVEL control shaft position sensor detects the control shaft position
angle.
A magnet is installed to the tip of the control shaft.
The magnetic field changes as the control shaft rotates. This
changes output voltage of the VVEL control shaft position sensor.
VVEL control module detects the actual position angle through the
voltage change and sends the signal to ECM.
PBIB2657E
JMBIA0879ZZ
JSBIA0466ZZ
Revision: 2010 May2011 QX56
