Page 2817 of 5598

INFINITI QX56 2011 Factory Service Manual
AFS SWITCHEXL-107
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
AFS SWITCH
Component Function CheckINFOID:0000000006213973
1.CHECK AFS SWITCH SIGNAL BY CONSULT-III
CONSULT-

Page 2818 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-108
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
AFS SWITCH
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK AFS SWITCH
Refer to EXL-108, "
Component Inspection

Page 2819 of 5598

INFINITI QX56 2011 Factory Service Manual
TAIL LAMP CIRCUITEXL-109
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
TAIL LAMP CIRCUIT
BODY SIDE
BODY SIDE : Component Function CheckINFOID:0000000006213976
1.CHECK TAIL

Page 2820 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-110
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
TAIL LAMP CIRCUIT
- Tail lamp (back door side)
- License plate lamp
3. Check continuity between IPDM E/R harness connec
tor and rear combination lamp har

Page 2821 of 5598

INFINITI QX56 2011 Factory Service Manual
TAIL LAMP CIRCUITEXL-111
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> Tail lamp (back door side) circuit is normal.
NO >> Refer to

Page 2822 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-112
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
LICENSE PLATE LAMP CIRCUIT
LICENSE PLATE LAMP CIRCUIT
Component Function CheckINFOID:0000000006213978
1.CHECK TAIL LAMP OPERATION
Check that the tail lam

Page 2823 of 5598

INFINITI QX56 2011 Factory Service Manual
EXTERIOR LIGHTING SYSTEM SYMPTOMSEXL-113
< SYMPTOM DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
SYMPTOM DIAGNOSIS
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Symptom TableINFOID:0000000006213980

Page 2824 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-114
< SYMPTOM DIAGNOSIS >[XENON TYPE]
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Each lamp is not turned ON/OFF with lighting switch
AUTO. Combination switch
Harness between combination
switch and BC

EXL-114
< SYMPTOM DIAGNOSIS >[XENON TYPE]
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Each lamp is not turned ON/OFF with lighting switch
AUTO. Combination switch
Harness between combination
switch and BCM
BCM Combination switch
Refer to
BCS-80, "
Symptom Table".
Optical sensor
Harness between optical sen- sor and BCM
BCM Optical sensor
Refer to
EXL-102, "
Component
Function Check".
Front fog lamp is not
turned ON. One side
Front fog lamp bulb
Harness between IPDM E/R
and front fog lamp
Front fog lamp
IPDM E/R Front fog lamp circuit
Refer to
EXL-94, "
Component
Function Check".
Both sides Symptom diagnosis
“BOTH SIDE FRONT FOG LAMPS ARE NOT TURNED ON”
Refer to
EXL-120, "
Diagnosis Procedure".
Parking lamp is not turned ON. Parking lamp bulb
Harness between IPDM E/R
and front combination lamp
Front combination lamp
IPDM E/R Parking lamp
circuit
Refer to EXL-96, "
Component
Function Check".
Front side marker lamp is not turned ON. Front side marker lamp bulb
Harness between IPDM E/R
and front combination lamp
Front combination lamp
IPDM E/R Front side marker lamp circuit
Refer to
EXL-98, "
Component
Function Check".
Tail lamp or rear side
marker lamp is not turned
ON. Body side
Harness between IPDM E/R
and rear combination lamp
Rear combination lamp Tail lamp circuit (body side)
Refer to
EXL-109, "
BODY SIDE :
Component Function Check".
Back door side Harness between IPDM E/R
and tail lamp (back door side)
Tail lamp (back door side) Tail lamp circuit (back door side)
Refer to
EXL-110, "
BACK DOOR
SIDE : Component Function
Check".
License plate lamp is not turned ON. License plate lamp bulb
Harness between IPDM E/R
and license plate lamp
License plate lamp License plate lamp circuit
Refer to
EXL-112, "
Component
Function Check".
Tail lamp, rear side marker lamp and license plate
lamp are not turned ON. Fuse
Harness between IPDM E/R
and rear combination lamp (LH)
IPDM E/R Tail lamp circuit (body side)
Refer to
EXL-109, "
BODY SIDE :
Component Function Check".
Parking lamp, side marker lamp, tail lamp and li- cense plate lamp are not turned ON.
Parking lamp, side marker lamp, tail lamp and li- cense plate lamp are not turned OFF.
(Each illumination is turned ON/OFF.) Symptom diagnosis
“PARKING, LICENSE PLATE, SIDE MARKER LAMP AND TAIL LAMPS
ARE NOT TURNED ON”
Refer to
EXL-119, "
Diagnosis Procedure".
Tail lamp indicator is not turned ON.
(Parking, side marker lamp and tail lamps are turned
ON.) Combination meter Combination meter
Data monitor “LIGHT IND”
BCM (HEAD LAMP) Active test “TAIL LAMP”
Turn signal lamp does not
blink. Indicator lamp is nor-
mal.
(Applicable side per-
forms the high flasher
activation.)
Harness between BCM and
each turn signal lamp
Turn signal lamp bulb Turn signal lamp circuit
Refer to
EXL-99, "
Component
Function Check".
Indicator lamp is includ-
ed. Combination switch
Harness between combination
switch and BCM
BCM Combination switch
Refer to
BCS-80, "
Symptom Table".
Symptom Possible cause Inspection item
Revision: 2010 May2011 QX56
