TERMINAL LAYOUT
PHYSICAL VALUES
SLCT LVR POSI Selector lever in “N
INFINITI QX56 2011 Factory Service Manual
TCM
TM-73
< ECU DIAGNOSIS INFORMATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
*: Not mounted but always display as OFF.
TERMINAL LAYOUT
PHYSICAL VALUES
SLCT LVR POSI Selector lever in “N](/manual-img/42/57033/w960_57033-5160.png)
TCM
TM-73
< ECU DIAGNOSIS INFORMATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
*: Not mounted but always display as OFF.
TERMINAL LAYOUT
PHYSICAL VALUES
SLCT LVR POSI Selector lever in “N
” and “P” positions N/P
Selector lever in “R” position R
Selector lever in “D” and “DS” positions D
Selector lever in “M” position: 7GR
Selector lever in “M” position: 6GR 6
Selector lever in “M” position: 5GR 5
Selector lever in “M” position: 4GR 4
Selector lever in “M” position: 3GR 3
Selector lever in “M” position: 2GR 2
Selector lever in “M” position: 1GR 1
GEAR During driving 1st, 2nd, 3rd, 4th, 5th, 6th, 7th
NEXT GR POSI During driving 1st, 2nd, 3rd, 4th, 5th, 6th, 7th
SHIFT MODE Driving with the D position 0 or 3
Driving with the manual mode 4 or 8
D/C PARTS At 1GR - 2GR shift control FAIL
Other than the above NOTFAIL
FR/B PARTS At control fixed to 1GR FAIL
Other than the above NOTFAIL
2346/B PARTS At control fixed to 1GR FAIL
Other than the above NOTFAIL
2346B/DC PARTS At 2GR - 3GR - 4GR
shift control FAIL
Other than the above NOTFAIL
N IDLE STATUS Idle neutral is active ON
Other than the above OFF
Item name Condition Value / Status (Approx.)
SCIA1658E
Te r m i n a l
(Wire color) Description
Condition Value (Approx.)
+ −Signal name Input/
Output
1
(V) Ground Power supply Input Ignition switch ON Battery voltage
Ignition switch OFF 0 V
2
(P) Ground Power supply
(Memory back-up) Input Always Battery voltage
