TRANSMISSION ASSEMBLYTM-249
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
25. Install needle bearing (1) to rear extension (2WD) or adapter case (4WD).
CAUTION:
Check the direction of needle bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
26. Install rear extension assembly (2WD) or adapter ca se assembly (4WD) according to the following proce-
dures.
a. 2WD
i. Install seal rings (1) to output shaft.
ii. Install parking gear (1) to output shaft (2).
iii. Install output shaft in transmission case. CAUTION:
Be careful not to mistake front for rear because both sides
looks similar. (Thinner end is front side.)
SCIA6179J
JPDIA0030ZZ
JPDIA0029ZZ
SCIA5030E
Revision: 2010 May2011 QX56
Page 5338 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-250
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
iv. Install bearing race to output shaft.
v. Apply recommended sealant (Genuine Anaerobic Liquid Gasket
or equivalent. Ref INFINITI QX56 2011 Factory Service Manual
TM-250
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
iv. Install bearing race to output shaft.
v. Apply recommended sealant (Genuine Anaerobic Liquid Gasket
or equivalent. Ref](/manual-img/42/57033/w960_57033-5337.png)
TM-250
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
iv. Install bearing race to output shaft.
v. Apply recommended sealant (Genuine Anaerobic Liquid Gasket
or equivalent. Refer to GI-22, "
Recommended Chemical Prod-
ucts and Sealants".) to rear extension assembly as shown in the
figure.
CAUTION:
Completely remove all moisture, oil and old sealant, etc.
from the transmission case and rear extension assembly
mounting surfaces.
vi. Install rear extension assembly to transmission case. CAUTION:
Insert the tip of parking rod between the parking pawl and
the parking actuator support when assembling the rear
extension assembly.
vii. Tighten rear extension assembly bolts to the specified torque.
SCIA5245E
Sealant starting
point and end-
point (A) : Start and finish
point shall be in
the center of two bolts.
Overlap width of
sealant starting
point and end-
point (B) : 3 – 5 mm (0.12 – 0.20 in)
Sealant width (C) : 1.0 – 2.0 mm (0.04 – 0.08 in)
Sealant height (C) : 0.4 – 1.0 mm (0.016 – 0.04 in)
JSDIA1855ZZ
SCIA5029E
1: Bracket
A: Bolt
B : Self-sealing bolt
JSDIA1845ZZ
Revision: 2010 May2011 QX56
Page 5339 of 5598
TRANSMISSION ASSEMBLYTM-251
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
b. 4WD
i. Install seal rings (1) to output shaft.
ii. Install parking gear (1) to output shaft (2).
iii. Install output shaft in transmission case. CAUTION:
Be careful not to mistake front for rear because both sides
looks similar. (Thinner end is front side.)
iv. Install bearing race to output shaft.
JPDIA0030ZZ
JPDIA0029ZZ
SCIA5030E
SCIA5245E
Revision: 2010 May2011 QX56
Page 5340 of 5598
TM-252
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
v. Install gasket onto transmission case.
CAUTION:
Completely remove all moisture, oil and old gasket, etc.from the transmission case and adapter case assembly
mounting surfaces.
Never reuse gasket.
vi. Install adapter case assembly to transmission case. CAUTION:
Insert the tip of parking rod between the parking pawl and
the parking actuator support when assembling the adapter
case assembly.
vii. Tighten adapter case assembly bolts to the specified torque.
27. Install needle bearing in drum support. CAUTION:
Check the direction of need le bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
SCIA5231E
SCIA5186E
1: Bracket
A: Bolt
B : Self-sealing bolt
JPDIA1155ZZ
SCIA5198E
Revision: 2010 May2011 QX56
Page 5341 of 5598
TRANSMISSION ASSEMBLYTM-253
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
28. Install direct clutch assembly in reverse brake. CAUTION:
Make sure that drum support edge surface and direct clutch
inner boss edge surface come to almost same place.
29. Install high and low reverse clutch assembly in direct clutch.
30. Align the drive plate using a flat-bladed screwdriver.
31. Install high and low reverse clutch hub, mid sun gear assembly, and rear sun gear assembly as a unit.
CAUTION:
SCIA5019E
SCIA2306E
SCIA3169E
SCIA5018E
Revision: 2010 May2011 QX56
Page 5342 of 5598
TM-254
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
Make sure that portion “A” of
high and low reverse clutch
drum protrudes approximately 2 mm (0.08 in) beyond por-
tion “B” of rear sun gear.
32. Install needle bearing in rear carrier assembly. CAUTION:
Check the direction of need le bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
33. Install bearing race in rear carrier assembly. CAUTION:
Check the direction of need le bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
34. Install rear carrier assembly in direct clutch drum.
35. Install needle bearing (rear side) to mid carrier assembly. CAUTION:
Check the direction of need le bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
SCIA3130E
SCIA2803E
SCIA5175E
SCIA2462E
SCIA2804E
Revision: 2010 May2011 QX56
Page 5343 of 5598
TRANSMISSION ASSEMBLYTM-255
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
36. Install needle bearing (front side) to mid carrier assembly. CAUTION:
Check the direction of needle bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
37. Install mid carrier assembly in rear carrier assembly.
38. Install seal rings (1) to input clutch assembly.
39. Install needle bearing (1) to front carrier assembly. CAUTION:
Check the direction of needle bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
SCIA2805E
SCIA5017E
JPDIA1121ZZ
JPDIA1120ZZ
Revision: 2010 May2011 QX56
Page 5344 of 5598
TM-256
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
40. Install input clutch assembly (with front carrier assembly and
rear internal gear) (1) to transmission case.
CAUTION:
Check that the needle bearing (2) is securely positioned. If
the needle bearing position is misaligned, adjust it to the
specified position.
41. Install 1st one-way clutch (1) to front brake hub (with under drive carrier) (2).
42. Check operation of 1st one-way clutch.
a. Hold 1st one-way clutch.
b. Check front brake hub for correct locking and unlocking direc- tions.
CAUTION:
If not shown in figure, check installati on direction of 1st one-way clutch.
43. Install under drive carrier (with 1st one-way clutch) (1) to trans- mission case.
JSDIA1714ZZ
: Unlocked
: Locked
JSDIA1713ZZ
JSDIA1715ZZ
Revision: 2010 May2011 QX56
