Page 1441 of 5598

INFINITI QX56 2011 Factory Service Manual DAS-476 < DTC/CIRCUIT DIAGNOSIS >[BSW] C1A24 NP RANGE 4.PERFORM TCM SELF-DIAGNOSIS 1. Perform “All DTC Reading”. 2. Check if any DTC is detected in “Sel f Diagnostic Result” of “TRANSMISSI

Page 1442 of 5598

INFINITI QX56 2011 Factory Service Manual DAS C1A39 STEERING ANGLE SENSORDAS-477 < DTC/CIRCUIT DIAGNOSIS > [BSW] C D E F G H I J K L M B N P A C1A39 STEERING ANGLE SENSOR DTC LogicINFOID:0000000006228229 DTC DETECTION LOGIC NOTE: If DTC “C

Page 1443 of 5598

INFINITI QX56 2011 Factory Service Manual DAS-478 < DTC/CIRCUIT DIAGNOSIS >[BSW] C1B50 SIDE RADAR MALFUNCTION C1B50 SIDE RADA R MALFUNCTION DTC LOGICINFOID:0000000006223893 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PERFORM DTC CONFIRM

Page 1444 of 5598

INFINITI QX56 2011 Factory Service Manual DAS C1B51 BSW/BSI INDICATOR SHORT CIRCUITDAS-479 < DTC/CIRCUIT DIAGNOSIS > [BSW] C D E F G H I J K L M B N P A C1B51 BSW/BSI INDICATOR SHORT CIRCUIT DTC LogicINFOID:0000000006223895 DTC DETECTION LOG

Page 1445 of 5598

INFINITI QX56 2011 Factory Service Manual DAS-480 < DTC/CIRCUIT DIAGNOSIS >[BSW] C1B52 BSW/BSI INDI CATOR OPEN CIRCUIT C1B52 BSW/BSI INDICATOR OPEN CIRCUIT DTC LogicINFOID:0000000006223897 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PER

Page 1446 of 5598

INFINITI QX56 2011 Factory Service Manual DAS C1B52 BSW/BSI INDICATOR OPEN CIRCUITDAS-481 < DTC/CIRCUIT DIAGNOSIS > [BSW] C D E F G H I J K L M B N P AIs the inspection result normal? YES >> Replace BSW indicator. NO >> Replace side radar. R

Page 1447 of 5598

INFINITI QX56 2011 Factory Service Manual DAS-482 < DTC/CIRCUIT DIAGNOSIS >[BSW] C1B53 SIDE RADAR RIGHT MALFUNCTION C1B53 SIDE RADAR RIGHT MALFUNCTION DTC LogicINFOID:0000000006223899 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PERFORM

Page 1448 of 5598

INFINITI QX56 2011 Factory Service Manual DAS C1B54 SIDE RADAR LEFT MALFUNCTIONDAS-483 < DTC/CIRCUIT DIAGNOSIS > [BSW] C D E F G H I J K L M B N P A C1B54 SIDE RADAR LEFT MALFUNCTION DTC LogicINFOID:0000000006223901 DTC DETECTION LOGIC DTC C
