INFINITI QX56 2011 Factory Service Manual
SRC-96
< DTC/CIRCUIT DIAGNOSIS >
B1088 SEAT BELT PRE-TENSIONER LH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4890 of 5598

INFINITI QX56 2011 Factory Service Manual
B1089 SEAT BELT PRE-TENSIONER LH
SRC-97
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1089 SEAT BELT PRE-TENSIONER LH
DTC LogicINFOID:0000000006220032
DTC DETECTION LOGIC
DTC CONFIRMAT

B1089 SEAT BELT PRE-TENSIONER LH
SRC-97
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1089 SEAT BELT PRE-TENSIONER LH
DTC LogicINFOID:0000000006220032
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-97, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220033
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE SEAT BELT PRE-TENSIONER
1. Replace seat belt pre-tensioner LH. Refer to SR-28, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-97, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-97, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1089 PRE-TEN FRONT LH
[SHORT] Seat belt pre-tensioner LH circuits are
shorted to each other Disconnection of wiring harness and short
Malfunction in seat belt pre-tensioner LH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4891 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-98
< DTC/CIRCUIT DIAGNOSIS >
B1089 SEAT BELT PRE-TENSIONER LH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4892 of 5598

INFINITI QX56 2011 Factory Service Manual
B1090, B1091, B1092, B1093, B1094, B1095 DIAGNOSIS SENSOR UNIT
SRC-99
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1090, B1091, B1092, B1093, B1094, B1095 DIAGNOSIS SENSOR UNIT
DTC L

Page 4893 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-100
< DTC/CIRCUIT DIAGNOSIS >
B1106, B1107, B1108, B1109, B1110, B1111 DIAGNOSIS SENSOR UNIT
B1106, B1107, B1108, B1109, B1110, B1111 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006220036
DTC D

Page 4894 of 5598

INFINITI QX56 2011 Factory Service Manual
B1113, B1114 SATELLITE SENSOR RHSRC-101
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1113, B1114 SATELLITE SENSOR RH
DTC LogicINFOID:0000000006220038
DTC DETECTION LOGIC
DTC CONFIRMATI

B1113, B1114 SATELLITE SENSOR RHSRC-101
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1113, B1114 SATELLITE SENSOR RH
DTC LogicINFOID:0000000006220038
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-101, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220039
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SATELLITE SENSOR
1. Replace front satellite sensor RH. Refer to SR-24, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-101, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-101, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B 111 3
B 111 4 SATELLITE SENS RH
[UNIT FAIL]
Front satellite sensor RH is malfunctioning Disconnection of wiring harness
Malfunction in front satellite sensor RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4895 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-102
< DTC/CIRCUIT DIAGNOSIS >
B1113, B1114 SATELLITE SENSOR RH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4896 of 5598

INFINITI QX56 2011 Factory Service Manual
B1115 SATELLITE SENSOR RHSRC-103
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1115 SATELLITE SENSOR RH
DTC LogicINFOID:0000000006220040
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1

B1115 SATELLITE SENSOR RHSRC-103
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1115 SATELLITE SENSOR RH
DTC LogicINFOID:0000000006220040
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-103, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220041
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SATELLITE SENSOR
1. Replace front satellite sensor RH. Refer to SR-24, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-103, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-103, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B 111 5 SATELLITE SENS RH
[COMM FAIL] Front satellite sensor RH is malfunctioning
or out of the specified specification Disconnection of wiring harness
Malfunction in front satellite sensor RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56
