PWO-26
< DTC/CIRCUIT DIAGNOSIS >[AC 120 V OUTLET]
AC 120 V OUTLET MAIN SWITCH INPUT SIGNAL CIRCUIT
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace AC 120 V outlet main switch.
Terminal Condition Continuity
13 When AC 120 V outlet main switch is ON Existed
When AC 120 V outlet main switch is OFF Not existed
Revision: 2010 May2011 QX56
Page 4186 of 5598
![INFINITI QX56 2011 Factory Service Manual
PWO
AC 120 V POWER OUTPUT CIRCUIT
PWO-27
< DTC/CIRCUIT DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
AC 120 V POWER OUTPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000006257091
1.CHECK HAR INFINITI QX56 2011 Factory Service Manual
PWO
AC 120 V POWER OUTPUT CIRCUIT
PWO-27
< DTC/CIRCUIT DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
AC 120 V POWER OUTPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000006257091
1.CHECK HAR](/manual-img/42/57033/w960_57033-4185.png)
PWO
AC 120 V POWER OUTPUT CIRCUIT
PWO-27
< DTC/CIRCUIT DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
AC 120 V POWER OUTPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000006257091
1.CHECK HARNESS BETWEEN INVERTER UNIT AND AC 120 V OUTLET
1. Turn ignition switch OFF.
2. Disconnect inverter unit connector and AC 120 V outlet connector.
3. Check for continuity between the inverter uni t harness connector and AC 120 V outlet harness connector.
4. Check for continuity between inverter unit harness connector and ground.
5. Check for continuity between inverter unit harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the harnesses or connectors.
2.CHECK INVERTER UNIT OUTPUT SIGNAL
1. Connect inverter unit connector and AC 120 V outlet connector.
2. Turn ignition switch ON.
3. AC 120 V outlet main switch ON. (AC 120 V outlet main switch indicator ON)
4. Check voltage between inverter unit harness connector.
CAUTION:
To measure AC 120 V output signal, al ways use the circuit tester AC range.
Never allow the probes to contact each other.
Is the inspection result normal?
YES >> GO TO 3
NO >> Replace inverter unit.
3.CHECK AC 120 V OUTLET VOLTAGE
1. AC 120 V outlet main switch ON. (AC 120 V outlet main switch indicator ON)
2. Check voltage between AC 120 V outlet.
Inverter unit AC 120 V outlet Continuity
Connector Terminal Connector Terminal
M143 5
M145 1
Existed
12
Inverter unit GroundContinuity
Connector Terminal
M143 5
Not existed
1
Inverter unit Continuity
Connector Terminal
M143 5 1 Not existed
Te r m i n a l s Condition
Vo l ta g e
(Approx.)
(+) (-)
Inverter unit Inverter unit AC 120 V outlet
main switch
Connector Terminal Connector Terminal
M1435M1431 OFF 0 V
ON AC 120 V
Revision: 2010 May2011 QX56
Page 4187 of 5598
PWO-28
< DTC/CIRCUIT DIAGNOSIS >[AC 120 V OUTLET]
AC 120 V POWER OUTPUT CIRCUIT
CAUTION:
To measure AC 120 V output signal, alw
ays use the circuit tester AC range.
Never allow the probes to contact each other.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace AC 120 V outlet.
Te r m i n a l s Condition
Vo l ta g e
(Approx.)
(+) (-)
AC 120 V outlet AC 120 V outlet
main switch
Te r m i n a l
12 OFF 0 V
ON AC 120 V
Revision: 2010 May2011 QX56
Page 4188 of 5598
![INFINITI QX56 2011 Factory Service Manual
PWO
AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
PWO-29
< DTC/CIRCUIT DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
Diagnosis ProcedureINF INFINITI QX56 2011 Factory Service Manual
PWO
AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
PWO-29
< DTC/CIRCUIT DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
Diagnosis ProcedureINF](/manual-img/42/57033/w960_57033-4187.png)
PWO
AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
PWO-29
< DTC/CIRCUIT DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
Diagnosis ProcedureINFOID:0000000006257098
1.CHECK HARNESS BETWEEN IN
VERTER UNIT AND AC 120 V OUTLET MAIN SWITCH
1. Turn ignition switch OFF.
2. Disconnect inverter unit connector and AC 120 V outlet main switch connector.
3. Check continuity between inverter unit harness connector and AC 120 V main switch harness connector.
4. Check continuity between inverter unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the harnesses or connectors.
2.CHECK AC 120 V OUTLET MAIN SWITCH GROUND CIRCUIT
Check continuity between AC 120 V outle t main switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the harnesses or connectors.
3.CHECK AC 120 V OUTLET MAIN SWITCH INDICATOR OUTPUT SIGNAL
1. Connect AC 120 V outlet main switch connector and inverter unit connector.
2. Turn ignition switch ON.
3. AC 120 V outlet main switch ON. (AC 120 V output is normal)
4. Check for voltage between the inverter unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace inverter unit.
4.CHECK AC 120 V OUTLET MAIN SWITCH INDICATOR
1. AC 120 V outlet main switch ON. (AC 120 V output is normal)
2. Check that AC 120 V outlet main switch indicator is illuminated.
Is the inspection result normal?
Inverter unit AC 120 V outlet main switch Continuity
Connector Terminal Connector Terminal
M1437M1445Existed
Inverter unit GroundContinuity
Connector Terminal
M143 7 Not existed
AC 120 V outlet main switch GroundContinuity
Connector Terminal
M144 6 Existed
Te r m i n a l s Condition
Vol tag e
(Approx.)
(+) (–)
Inverter unit
GroundAC 120 V out-
let main
switch
Connector Terminal
M143 7 OFF 0 V
ON 5.2 V
Revision: 2010 May2011 QX56
Page 4189 of 5598
PWO-30
< DTC/CIRCUIT DIAGNOSIS >[AC 120 V OUTLET]
AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
YES >> INSPECTION END
NO >> Replace AC 120 V outlet main switch.
Revision: 2010 May2011 QX56
Page 4190 of 5598
![INFINITI QX56 2011 Factory Service Manual
PWO
NO OUTPUT FROM AC 120 V OUTLETPWO-31
< SYMPTOM DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYMPTOM DIAGNOSIS
NO OUTPUT FROM AC 120 V OUTLET
Diagnosis ProcedureINFOID:0000000006257 INFINITI QX56 2011 Factory Service Manual
PWO
NO OUTPUT FROM AC 120 V OUTLETPWO-31
< SYMPTOM DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYMPTOM DIAGNOSIS
NO OUTPUT FROM AC 120 V OUTLET
Diagnosis ProcedureINFOID:0000000006257](/manual-img/42/57033/w960_57033-4189.png)
PWO
NO OUTPUT FROM AC 120 V OUTLETPWO-31
< SYMPTOM DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYMPTOM DIAGNOSIS
NO OUTPUT FROM AC 120 V OUTLET
Diagnosis ProcedureINFOID:0000000006257108
1.CHECK FAIL-SAFE ACTIVATION
Check if the symptom is caused by a fail-safe operation. Refer to PWO-17, "
Fail-safe".
Is fail-safe operating?
YES >> Repair the part causing fail-safe operation.
NO >> GO TO 2.
2.CHECK INVERTER UNIT POWER SUPPLY CIRCUIT
Check inverter unit power supply circuit. Refer to PWO-23, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK AC 120 V OUTLET MAIN SWITCH POWER SUPPLY CIRCUIT
Check AC 120 V outlet main switch power supply circuit. Refer to PWO-24, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK AC 120 V OUTLET MAIN SWITCH INPUT SIGNAL CIRCUIT
Check AC 120 V outlet main switch input signal circuit. Refer to PWO-25, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INVERTER UNIT POWER OUTPUT CIRCUIT
Check inverter unit power output circuit. Refer to PWO-27, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: 2010 May2011 QX56
Page 4191 of 5598
![INFINITI QX56 2011 Factory Service Manual
PWO-32
< SYMPTOM DIAGNOSIS >[AC 120 V OUTLET]
AC 120 V OUTLET MAIN SWITCH INDICATOR DOES NOT TURN ON
AC 120 V OUTLET MAIN SWITCH
INDICATOR DOES NOT TURN ON
Diagnosis ProcedureINFOID:0000000006257110 INFINITI QX56 2011 Factory Service Manual
PWO-32
< SYMPTOM DIAGNOSIS >[AC 120 V OUTLET]
AC 120 V OUTLET MAIN SWITCH INDICATOR DOES NOT TURN ON
AC 120 V OUTLET MAIN SWITCH
INDICATOR DOES NOT TURN ON
Diagnosis ProcedureINFOID:0000000006257110](/manual-img/42/57033/w960_57033-4190.png)
PWO-32
< SYMPTOM DIAGNOSIS >[AC 120 V OUTLET]
AC 120 V OUTLET MAIN SWITCH INDICATOR DOES NOT TURN ON
AC 120 V OUTLET MAIN SWITCH
INDICATOR DOES NOT TURN ON
Diagnosis ProcedureINFOID:0000000006257110
1.CHECK FAIL-SAFE ACTIVATION
Check if the symptom is caused by a fail-safe operation. Refer to PWO-17, "
Fail-safe".
Is fail-safe operating?
YES >> Repair the part causing fail-safe operation.
NO >> GO TO 2.
2.CHECK INVERTER UNIT POWER SUPPLY CIRCUIT
Check inverter unit power supply circuit. Refer to PWO-23, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK AC 120 V OUTLET MAIN SWITCH POWER SUPPLY CIRCUIT
Check AC 120 V outlet main switch power supply circuit. Refer to PWO-24, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK AC 120 V OUTLET MAIN SWITCH INPUT SIGNAL CIRCUIT
Check AC 120 V outlet main switch input signal circuit. Refer to PWO-25, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK AC 120 V OUTLET MAIN SWITCH INDICATOR CIRCUIT
Check AC 120 V outlet main switch indicator circuit. Refer to PWO-29, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: 2010 May2011 QX56
Page 4192 of 5598
PWO
NORMAL OPERATING CONDITIONPWO-33
< SYMPTOM DIAGNOSIS > [AC 120 V OUTLET]
C
D
E
F
G H
I
J
K L
B A
O P
N
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000006257122
Because of modified sine wave output, the AC 120 V out
let may not operate normally for electric appliance of
which electric power consumption is 150 W or less.
Electric appliances requiring a large amount of electr ic power consumption at startup (e.g. CRT-based TV,
power tool)
Measuring instruments for data requiring accuracy (e.g. medical equipment, measuring instrument)
Microprocessor-controlled appliances (e.g. microprocessor-controlled blanket)
Noise may be caused in radio or TV, depending on an electric appliance.
Revision: 2010 May2011 QX56
