SEC-50
< BASIC INSPECTION >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS AND REPAIR WORK FLOW
2. Reconnect parts or connectors disconnected during Diagnostic Procedure again after repair and replace-
ment.
3. Check DTC. If DTC is detected, erase it.
>> GO TO 9.
9.FINAL CHECK
When DTC is detected in step 2, perform DTC CONFIRMATION PROCEDURE again, and then check that the
malfunction is repaired securely.
When symptom is described by the customer, refer to c onfirmed symptom in step 3 or 4, and check that the
symptom is not detected.
Does the symptom reappear?
YES (DTC is detected)>>GO TO 7.
YES (Symptom remains)>>GO TO 6.
NO >> INSPECTION END
Revision: 2010 May2011 QX56
Page 4658 of 5598
![INFINITI QX56 2011 Factory Service Manual
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNITSEC-51
< BASIC INSPECTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ECM
ECM : Des INFINITI QX56 2011 Factory Service Manual
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNITSEC-51
< BASIC INSPECTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ECM
ECM : Des](/manual-img/42/57033/w960_57033-4657.png)
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNITSEC-51
< BASIC INSPECTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ECM
ECM : DescriptionINFOID:0000000006226197
Performing the following procedure can automatically activate recommunication of ECM and BCM, but only
when the ECM is replaced with a new one*.
*: New one means a virgin ECM that has never been energized on-board.
(In this step, initialization procedur e by CONSULT-III is not necessary)
NOTE:
When registering new Key IDs or replacing the ECM th at is not brand new, refer to CONSULT-III Oper-
ation Manual NATS-IVIS/NVIS.
If multiple keys are attached to the key hold er, separate them before beginning work.
Distinguish keys with unregistered key IDs from those with registered IDs.
ECM : Work ProcedureINFOID:0000000006226198
1.PERFORM ECM RECOMMUNICATING FUNCTION
1. Install ECM.
2. Contact backside of registered Intelligent key* to push-button ignition switch, then turn power supply posi-
tion to ON.
*: To perform this step, use the key that is used before performing ECM replacement.
3. Maintain power supply position in t he ON position for at least 5 seconds.
4. Turn power supply position to OFF.
5. Check that the engine starts.
>> GO TO 2.
2.PERFORM ADDITIONAL SERVICE WHEN REPLACING ECM
Perform EC-143, "
Work Procedure".
>> END
BCM
BCM : DescriptionINFOID:0000000006397657
BEFORE REPLACEMENT
When replacing BCM, save or print current vehicle specification with CONSULT-III configuration before
replacement.
NOTE:
If “READ CONFIGURATION” can not be used, use the “WRITE CONFIGURATION - Manual selection” after
replacing BCM.
AFTER REPLACEMENT
CAUTION:
When replacing BCM, you must perform “W RITE CONFIGURATION” with CONSULT-III.
- Complete the procedure of “WRITE CONFIGURATION” in order.
- If you set incorrect “WRITE CONF IGURATION”, incidents might occur.
- Configuration is different for each vehicle model. Confirm conf iguration of each vehicle model.
When replacing BCM, perform the system initialization (NATS).
BCM : Work ProcedureINFOID:0000000006397658
1.SAVING VEHICLE SPECIFICATION
CONSULT-III Configuration
Perform “READ CONFIGURATION” to save or prin t current vehicle specification. Refer to BCS-67, "
CONFIG-
URATION (BCM) : Description".
NOTE:
Revision: 2010 May2011 QX56
Page 4659 of 5598
SEC-52
< BASIC INSPECTION >[WITH INTELLIGENT KEY SYSTEM]
ADDITIONAL SERVICE WHEN
REPLACING CONTROL UNIT
If “READ CONFIGURATION” can not be used, use the “WRITE CONFIGURATION - Manual selection” after
replacing BCM.
>> GO TO 2.
2.REPLACE BCM
Replace BCM. Refer to BCS-81, "
Removal and Installation".
>> GO TO 3.
3.WRITING VEHICLE SPECIFICATION
CONSULT-III Configuration
Perform “WRITE CONFIGURATION - Config file” or “W RITE CONFIGURATION - Manual selection” to write
vehicle specification. Refer to BCS-69, "
CONFIGURATION (BCM) : Configuration list".
>> GO TO 4.
4.INITIALIZE BCM (NATS)
Perform BCM initialization. (NATS)
>> WORK END
Revision: 2010 May2011 QX56
Page 4660 of 5598
![INFINITI QX56 2011 Factory Service Manual
P1610 LOCK MODESEC-53
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
DTC/CIRCUIT DIAGNOSIS
P1610 LOCK MODE
DescriptionINFOID:0000000006226201
ECM forcibly s INFINITI QX56 2011 Factory Service Manual
P1610 LOCK MODESEC-53
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
DTC/CIRCUIT DIAGNOSIS
P1610 LOCK MODE
DescriptionINFOID:0000000006226201
ECM forcibly s](/manual-img/42/57033/w960_57033-4659.png)
P1610 LOCK MODESEC-53
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
DTC/CIRCUIT DIAGNOSIS
P1610 LOCK MODE
DescriptionINFOID:0000000006226201
ECM forcibly switches to the mode that inhibits engi ne start, when engine start operation is performed 5 times
or more while communication between ECM and BCM is not normal.
DTC LogicINFOID:0000000006226202
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” mode of “ENGINE” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-53, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226203
1.CHECK ENGINE START FUNCTION
1. Check that DTC except fo r DTC P1610 is not detected.
If detected, erase the DTC after fixing.
2. Turn ignition switch OFF.
3. Contact the registered Intelligent Key backside to push-button ignition switch and wait 5 seconds.
4. Turn ignition switch ON.
5. Turn ignition switch OFF and wait 5 seconds.
6. Repeat steps 3 and 5 twice (a total of 3 times).
7. Check that engine can start.
>> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible causeP1610 LOCK MODE When ECM detects a communication malfunction between
ECM and BCM 5 times or more.
—
Revision: 2010 May2011 QX56
Page 4661 of 5598
![INFINITI QX56 2011 Factory Service Manual
SEC-54
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1611 ID DISCORD, IMMU-ECM
P1611 ID DISCORD, IMMU-ECM
DTC LogicINFOID:0000000006226204
DTC DETECTION LOGIC
NOTE:
If DTC P1611 is displa INFINITI QX56 2011 Factory Service Manual
SEC-54
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1611 ID DISCORD, IMMU-ECM
P1611 ID DISCORD, IMMU-ECM
DTC LogicINFOID:0000000006226204
DTC DETECTION LOGIC
NOTE:
If DTC P1611 is displa](/manual-img/42/57033/w960_57033-4660.png)
SEC-54
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1611 ID DISCORD, IMMU-ECM
P1611 ID DISCORD, IMMU-ECM
DTC LogicINFOID:0000000006226204
DTC DETECTION LOGIC
NOTE:
If DTC P1611 is displayed with DTC U1000 (for BC
M), first perform the trouble diagnosis for DTC U1000.
Refer to BCS-70, "
DTC Logic".
If DTC P1611 is displayed with DTC U1010 (for BC M), first perform the trouble diagnosis for DTC U1010.
Refer to BCS-71, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” mode of “ENGINE” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-54, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226205
1.PERFORM INITIALIZATION
Perform initialization of BCM and reregistration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK SELF DIAGNOSTIC RESULT
1. Select “Self Diagnostic Result” m ode of “ENGINE” using CONSULT-III.
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE for DTC P1611. Refer to SEC-54, "
DTC Logic".
Is DTC detected?
YES >> GO TO 3.
NO >> INSPECTION END
3.REPLACE BCM
1. Replace BCM. Refer to BCS-81, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
Can the system be initialized and can the engi ne be started with registered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 4.
4.REPLACE ECM
1. Replace ECM. Refer to EC-535, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”. Refer to EC-143, "
Work Procedure".
>> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1611 ID DISCORD, IMMU-ECM The ID verification results between BCM
and ECM are NG. Harness or connectors
(The CAN communication line is open
or shorted.)
BCM
ECM
Revision: 2010 May2011 QX56
Page 4662 of 5598
![INFINITI QX56 2011 Factory Service Manual
P1612 CHAIN OF ECM-IMMUSEC-55
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
P1612 CHAIN OF ECM-IMMU
DTC LogicINFOID:0000000006226206
DTC DETECTION LOGIC
NO INFINITI QX56 2011 Factory Service Manual
P1612 CHAIN OF ECM-IMMUSEC-55
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
P1612 CHAIN OF ECM-IMMU
DTC LogicINFOID:0000000006226206
DTC DETECTION LOGIC
NO](/manual-img/42/57033/w960_57033-4661.png)
P1612 CHAIN OF ECM-IMMUSEC-55
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
P1612 CHAIN OF ECM-IMMU
DTC LogicINFOID:0000000006226206
DTC DETECTION LOGIC
NOTE:
If DTC P1612 is displayed with DTC U1000 (for BC M), first perform the trouble diagnosis for DTC U1000.
Refer to BCS-70, "
DTC Logic".
If DTC P1612 is displayed with DTC U1010 (for BC M), first perform the trouble diagnosis for DTC U1010.
Refer to BCS-71, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” mode of “ENGINE” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-55, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226207
1.REPLACE BCM
1. Replace BCM. Refer to BCS-81, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
Can the system be initialized and can the engine be started with registered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ECM
1. Replace ECM. Refer to EC-535, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”. Refer to EC-143, "
Work Procedure".
>> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1612 CHAIN OF ECM-IMMU Inactive communication between ECM
and BCM Harness or connectors
(The CAN communication line is open or
shorted.)
BCM
ECM
Revision: 2010 May2011 QX56
Page 4663 of 5598
![INFINITI QX56 2011 Factory Service Manual
SEC-56
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1614 CHAIN OF IMMU-KEY
P1614 CHAIN OF IMMU-KEY
DTC LogicINFOID:0000000006226208
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM INFINITI QX56 2011 Factory Service Manual
SEC-56
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1614 CHAIN OF IMMU-KEY
P1614 CHAIN OF IMMU-KEY
DTC LogicINFOID:0000000006226208
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM](/manual-img/42/57033/w960_57033-4662.png)
SEC-56
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1614 CHAIN OF IMMU-KEY
P1614 CHAIN OF IMMU-KEY
DTC LogicINFOID:0000000006226208
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE 1
1. Contact Intelligent Key backside to push-button ignition switch.
2. Check DTC in “Self Diagnostic Result” mode of “ENGINE” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-56, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE 2
1. Press the push-button ignition switch.
2. Check DTC in “Self Diagnostic Result” mode of “ENGINE” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-56, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226209
1.CHECK FUSE
1. Turn ignition switch OFF.
2. Check that the following fuse in IPDM E/R is not blown.
Is the fuse fusing?
YES >> Replace the blown fuse after repairing the cause of blowing.
NO >> GO TO 2.
2.CHECK NATS ANTENNA AMP. POWER SUPPLY
1. Disconnect NATS antenna amp. connector.
2. Check voltage between NATS antenna amp. harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK NATS ANTENNA AMP. POWER SUPPLY CIRCUIT
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R har ness connector and NATS antenna amp. connector.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1614 CHAIN OF IMMU-KEY Inactive communication between NATS
antenna amp. and BCM Harness or connectors
(NATS antenna amp. circuit is open or
shorted.)
NATS antenna amp.
IPDM E/R
Signal name Fuse No.
Battery power supply 43
(+) (–)Voltage (V)
(Approx.)
NATS antenna amp.
Connector Terminal M26 1 Ground Battery voltage
Revision: 2010 May2011 QX56
Page 4664 of 5598
![INFINITI QX56 2011 Factory Service Manual
P1614 CHAIN OF IMMU-KEYSEC-57
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3. Check continuity between IPDM E/R harness connector and ground.
Is the inspe INFINITI QX56 2011 Factory Service Manual
P1614 CHAIN OF IMMU-KEYSEC-57
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3. Check continuity between IPDM E/R harness connector and ground.
Is the inspe](/manual-img/42/57033/w960_57033-4663.png)
P1614 CHAIN OF IMMU-KEYSEC-57
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK NATS ANTENNA AMP. OUTPUT SIGNAL 1
1. Connect NATS antenna amp. connector.
2. Disconnect BCM connector.
3. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK NATS ANTENNA AMP. OUTPUT SIGNAL CIRCUIT 1
1. Disconnect NATS antenna amp. connector.
2. Check continuity between BCM harness connector and NATS antenna amp. connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace NATS antenna amp. Refer to SEC-155, "Removal and Installation".
NO >> Repair or replace harness.
6.CHECK NATS ANTENNA AMP. COMMUNICATION SIGNAL 1
1. Connect BCM connector.
2. Check voltage between BCM harness connector and ground using analog tester.
Is the inspection result normal?
IPDM E/R NATS antenna amp. Continuity
Connector Terminal Connector Terminal
E14 42 M26 1 Existed
IPDM E/R GroundContinuity
Connector Terminal
E14 42 Not existed
(+) (–)Voltage (V)
(Approx.)
BCM
Connector Terminal M68 21 Ground 12
BCM NATS antenna amp. Continuity
Connector Terminal Connector Terminal
M6821M26 2Existed
BCM GroundContinuity
Connector Terminal
M68 21 Not existed
(+) (–) Condition Voltage (V)
(Approx.)
BCM
Connector Terminal
M68 21 Ground Contact Intelligent Key backside to
push-button ignition switch, then turn
ignition switch ON.Just after pressing push-button ignition
switch, pointer of analog tester should
move.
Revision: 2010 May2011 QX56
