VIN REGISTRATION
DescriptionINFOID:0000000006217744
VIN Registration is an operation to register VIN in
ECM. It m

Page 2170 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-146
< BASIC INSPECTION >[VK56VD]
ACCELERATOR PEDAL RELEASED POSITION LEARNING
ACCELERATOR PEDAL REL
EASED POSITION LEARNING
DescriptionINFOID:0000000006217746
Accelerator Pedal Released Position L

Page 2171 of 5598

INFINITI QX56 2011 Factory Service Manual
THROTTLE VALVE CLOSED POSITION LEARNINGEC-147
< BASIC INSPECTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
THROTTLE VALVE CLOSED
POSITION LEARNING
DescriptionINFOID:0000000006217748
Throttle Valve

Page 2172 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-148
< BASIC INSPECTION >[VK56VD]
IDLE AIR VOLUME LEARNING
IDLE AIR VOLUME LEARNING
DescriptionINFOID:0000000006217750
Idle Air Volume Learning is a function of ECM to learn
the idle air volume th

EC-148
< BASIC INSPECTION >[VK56VD]
IDLE AIR VOLUME LEARNING
IDLE AIR VOLUME LEARNING
DescriptionINFOID:0000000006217750
Idle Air Volume Learning is a function of ECM to learn
the idle air volume that keeps engine idle speed within
the specific range. It must be perfo rmed under the following conditions:
Each time the electric throttle control actuator or ECM is replaced.
Idle speed or ignition timing is out of the specification.
Work ProcedureINFOID:0000000006217751
1.PRECONDITIONING
Check that all of the following conditions are satisfied.
Learning will be cancelled if any of the follo wing conditions are missed for even a moment.
Battery voltage: More than 12.9 V (At idle)
Engine coolant temperature: 70 - 105 °C (158 - 221 °F)
Selector lever position: P or N
Electric load switch: OFF
(Air conditioner, headlamp, rear window defogger)
On vehicles equipped with daytime light systems, if the parking brake is applied before the engine is
started the headlamp will not illuminate.
Steering wheel: Neutral (Straight-ahead position)
Vehicle speed: Stopped
Transmission: Warmed-up
- With CONSULT-III: Drive vehicle until “ATF TEMP 2” in “DATA MONITOR” mode of “A/T” system indicates
less than 0.9 V.
- Without CONSULT-III: Drive vehicle for 10 minutes.
Will CONSULT-III be used?
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM IDLE AIR VOLUME LEARNING
WITH CONSULT-III
1. Perform Accelerator Pedal Released Position Learning. Refer to EC-146, "
Work Procedure".
2. Perform Throttle Valve Closed Position Learning. EC-147, "
Work Procedure".
3. Start engine and warm it up to normal operating temperature.
4. Select “IDLE AIR VOL LEARN” in “WORK SUPPORT” mode.
5. Touch “START” and wait 20 seconds.
Is
“CMPLT” displayed on CONSULT-III screen?
YES >> GO TO 4.
NO >> GO TO 5.
3.PERFORM IDLE AIR VOLUME LEARNING
WITHOUT CONSULT-III
NOTE:
It is better to count the ti me accurately with a clock.
It is impossible to switch the di agnostic mode when an accelerator pedal position sensor circuit has
a malfunction.
1. Perform Accelerator Pedal Released Position Learning. Refer to EC-146, "
Work Procedure".
2. Perform Throttle Valve Closed Position Learning. EC-147, "
Work Procedure".
3. Start engine and warm it up to normal operating temperature.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Confirm that accelerator pedal is fully releas ed, turn ignition switch ON and wait 3 seconds.
6. Repeat the following procedure quickly 5 times within 5 seconds.
- Fully depress the accelerator pedal.
- Fully release the accelerator pedal.
7. Wait 7 seconds, fully depress the accelerator pedal for approx. 20 seconds until the MIL stops blinking
and turns ON.
8. Fully release the accelerator pedal within 3 seconds after the MIL turns ON.
Revision: 2010 May2011 QX56

Page 2173 of 5598

INFINITI QX56 2011 Factory Service Manual
IDLE AIR VOLUME LEARNINGEC-149
< BASIC INSPECTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
9. Start engine and let it idle.
10. Wait 20 seconds.
>> GO TO 4.
4.CHECK IDLE SPEED AND IGNITION TIMING
R

Page 2174 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-150
< BASIC INSPECTION >[VK56VD]
VVEL CONTROL SHAFT POSI
TION SENSOR ADJUSTMENT
VVEL CONTROL SHAFT POSITI ON SENSOR ADJUSTMENT
DescriptionINFOID:0000000006217752
VVEL control shaft position sensor

EC-150
< BASIC INSPECTION >[VK56VD]
VVEL CONTROL SHAFT POSI
TION SENSOR ADJUSTMENT
VVEL CONTROL SHAFT POSITI ON SENSOR ADJUSTMENT
DescriptionINFOID:0000000006217752
VVEL control shaft position sensor adjustment is an operat ion to adjust the initial position of the VVEL control
shaft position sensor.
It must be performed each time VVEL ladder assembly is replaced.
CAUTION:
It must be performed only on the replaced bank side.
It must not be performed except when VVEL la dder assembly is replaced. If by any chance the
adjustment is performed, replace VVEL ladder assembly.
Work ProcedureINFOID:0000000006217753
1.START
Will CONSULT-III be used?
Will CONSULT-III be used?
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM VVEL CONTROL SHAFT POSITION SENSOR ADJUSTMENT
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “VVEL POS SEN ADJ PREP” in “WORK SUPPORT” mode with CONSULT-III.
3. Touch “Start” and wait a few seconds.
4. Check that “CMPLT” is displayed on CONSULT-III screen.
5. Select “VVEL POSITION SEN-B1” or “VVEL POSI TION SEN-B2” in “DATA MONITOR” mode with CON-
SULT-III.
6. Loosen the VVEL control shaft position sensor mounting bolts
(1).
7. Turn the VVEL control shaft position sensor (2) clockwise and counterclockwise while monitoring the output voltage of “VVEL
POSITION SEN-B1” or “VVEL POSITION SEN-B2” and adjust
the output voltage to be within the standard value.
8. Tighten the VVEL control shaft position sensor mounting bolts.
9. Reconfirm that the output voltage of “VVEL POSITI ON SEN-B1” or “VVEL POSITION SEN-B2” is within
the standard value.
NOTE:
If it varies from the standard value after the m ounting bolts are tightened, perform steps 6 to 8 again.
10. Turn ignition switch OFF and wait at least 10 seconds.
11. Start engine and warm it up to normal operating temperature.
12. Turn ignition switch OFF and wait at least 10 seconds.
13. Perform idle air volume learning. Refer to EC-148, "
Work Procedure".
>> INSPECTION END
3.PERFORM VVEL CONTROL SHAFT POSITION SENSOR ADJUSTMENT
WITHOUT CONSULT-III
1. Disconnect VVEL control shaft position sensor harness connector.
2. Remove VVEL actuator motor relay.
3. Turn ignition switch ON, wait at least 5 seconds and then turn it OFF. Voltage: 500
± 48 mV
: 7.0 Nm (0.71 kg-m, 62 in-lb)
Voltage: 500 ± 48 mV
JSBIA0533ZZ
Revision: 2010 May2011 QX56

Page 2175 of 5598

INFINITI QX56 2011 Factory Service Manual
VVEL CONTROL SHAFT POSITION SENSOR ADJUSTMENT
EC-151
< BASIC INSPECTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Reconnect all harness connectors disconnected.
5. Install VVEL actuator motor rel

Page 2176 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-152
< BASIC INSPECTION >[VK56VD]
MIXTURE RATIO SELF-LEARNING VALUE CLEAR
MIXTURE RATIO SELF-LEARNING VALUE CLEAR
DescriptionINFOID:0000000006217754
This describes how to erase the mixture ratio se
