EXTERIOR LAMP FUSE ................................ ....85
Diagnosis Procedure ........................................... ....85
HEADLAMP (HI) CIRCUIT .....

EXL-3
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
EXTERIOR LAMP FUSE ................................ ....85
Diagnosis Procedure ........................................... ....85
HEADLAMP (HI) CIRCUIT .................................86
Component Function Check ................................ ....86
Diagnosis Procedure ...............................................86
HEADLAMP (LO) CIRCUIT ................................88
Component Function Check ................................ ....88
Diagnosis Procedure ...............................................88
XENON HEADLAMP ..........................................90
Diagnosis Procedure ........................................... ....90
HEADLAMP LEVELIZER CIRCUIT ...................91
Component Function Check ................................ ....91
Diagnosis Procedure ...............................................91
HEADLAMP AIMING SYSTEM (MANUAL) .......93
Component Inspection ........................................ ....93
FRONT FOG LAMP CIRCUIT ............................94
Component Function Check ................................ ....94
Diagnosis Procedure ...............................................94
PARKING LAMP CIRCUIT ............................. ....96
Component Function Check ................................ ....96
Diagnosis Procedure ...............................................96
FRONT SIDE MARKER LAMP CIRCUIT ...........98
Component Function Check ................................ ....98
Diagnosis Procedure ...............................................98
TURN SIGNAL LAMP CIRCUIT .........................99
Component Function Check ................................ ....99
Diagnosis Procedure ...............................................99
OPTICAL SENSOR ..........................................102
Component Function Check ................................ ..102
Diagnosis Procedure .............................................102
HAZARD SWITCH .......................................... ..105
Component Function Check ................................ ..105
Diagnosis Procedure .............................................105
AFS SWITCH ....................................................107
Component Function Check ................................ ..107
Diagnosis Procedure .............................................107
Component Inspection ..........................................108
TAIL LAMP CIRCUIT .......................................109
BODY SIDE ........................................................... ..109
BODY SIDE : Component Function Check ...........109
BODY SIDE : Diagnosis Procedure ......................109
BACK DOOR SIDE ................................................ ..110
BACK DOOR SIDE : Component Function Check ..110
BACK DOOR SIDE : Diagnosis Procedure ...........111
LICENSE PLATE LAMP CIRCUIT ...................112
Component Function Check ................................ ..112
Diagnosis Procedure .............................................112
SYMPTOM DIAGNOSIS ............................113
EXTERIOR LIGHTING SYSTEM SYMPTOMS .113
Symptom Table ................................................... ..113
NORMAL OPERATING CONDITION .............116
Description .............................................................116
BOTH SIDE HEADLAMPS DO NOT SWITCH
TO HIGH BEAM ..............................................
117
Description .............................................................117
Diagnosis Procedure .............................................117
BOTH SIDE HEADLAMPS (LO) ARE NOT
TURNED ON ...................................................
118
Description ........................................................... ..118
Diagnosis Procedure .............................................118
PARKING, LICENSE PLATE, SIDE MARKER
AND TAIL LAMPS ARE NOT TURNED ON ...
119
Description .............................................................119
Diagnosis Procedure .............................................119
BOTH SIDE FRONT FOG LAMPS ARE NOT
TURNED ON ...................................................
120
Description ........................................................... ..120
Diagnosis Procedure .............................................120
PERIODIC MAINTENANCE ......................121
HEADLAMP AIMING ADJUSTMENT .............121
description ........................................................... ..121
Aiming Adjustment Procedure ...............................122
FRONT FOG LAMP AIMING ADJUSTMENT .123
Description .............................................................123
Aiming Adjustment Procedure ...............................123
REMOVAL AND INSTALLATION .............125
FRONT COMBINATION LAMP ......................125
Exploded View ..................................................... ..125
Removal and Installation .......................................125
Replacement .........................................................126
Disassembly and Assembly ...................................127
FRONT FOG LAMP ........................................128
Exploded View .......................................................128
Removal and Installation .......................................128
Replacement .........................................................128
SIDE TURN SIGNAL LAMP ............................130
Exploded View .......................................................130
Removal and Installation .......................................130
OPTICAL SENSOR .........................................131
Exploded View .......................................................131
Removal and Installation .......................................131
LIGHTING & TURN SIGNAL SWITCH ...........132
Exploded View .......................................................132
Revision: 2010 May2011 QX56

Page 2714 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-4
HAZARD SWITCH ...........................................133
Exploded View ..................................................... ..133
AFS SWITCH ............................................

EXL-4
HAZARD SWITCH ...........................................133
Exploded View ..................................................... ..133
AFS SWITCH ...................................................134
Exploded View ..................................................... ..134
Removal and Installation .......................................134
AFS CONTROL UNIT ......................................135
Exploded View ..................................................... ..135
Removal and Installation .......................................135
HEIGHT SENSOR ............................................136
Exploded View ..................................................... ..136
Removal and Installation .......................................136
REAR COMBINATION LAMP .........................138
Exploded View ..................................................... ..138
Removal and Installation .......................................138
HIGH-MOUNTED STOP LAMP .......................140
Exploded View ..................................................... .140
Removal and Installation .......................................140
BACK-UP LAMP ............................................ ..141
Exploded View ..................................................... .141
Removal and Installation .......................................141
Replacement .........................................................142
LICENSE PLATE LAMP ...................................143
Exploded View ..................................................... .143
Removal and Installation .......................................143
Replacement .........................................................143
SERVICE DATA AND SPECIFICATIONS
(SDS) ........ .................................................
145
SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................. ..
145
Bulb Specifications ............................................... .145
Revision: 2010 May2011 QX56

Page 2715 of 5598

INFINITI QX56 2011 Factory Service Manual
PRECAUTIONSEXL-5
< PRECAUTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFO

PRECAUTIONSEXL-5
< PRECAUTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006450052
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Revision: 2010 May2011 QX56

Page 2716 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-6
< SYSTEM DESCRIPTION >[XENON TYPE]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
EXTERIOR LIGHTING SYSTEM
EXTERIOR LIGHTING SYSTEM : Component Parts LocationINFOID:0000000006213887
JMLIA11

Page 2717 of 5598

INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEXL-7
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*1: With headlamp aiming control system (manual) models
*2: With AFS system models
EXTERIOR LIGHTING SYSTEM

COMPONENT PARTSEXL-7
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*1: With headlamp aiming control system (manual) models
*2: With AFS system models
EXTERIOR LIGHTING SYSTEM : Component DescriptionINFOID:0000000006213888
1. Combination meter 2. BCM
Refer to BCS-4, "
BODY CONTROL
SYSTEM : Compon ent Parts Loca-
tion"
3. Optical sensor
4. IPDM E/R Refer to PCS-4, "
Component Parts
Location"
5. ECM
Refer to EC-16, "
Component Parts
Location"
6. Parking lamp
7. Front turn signal lamp 8. Front fog lamp 9. Headlamp
10. Front side marker lamp 11. Combination switch 12. Headlamp aiming switch*
1
13. Front door switch (driver side) 14.
Steering angle sensor*2
Refer to BRC-10, "Component Parts
Location"
15. License plate lamp
16. Tail lamp 17. Rear turn signal lamp 18. Rear side marker lamp
19. Hazard switch 20. Side turn signal lamp 21. Headlamp swivel actuator
22. Headlamp aiming motor 23. AFS switch*
224.Rear height sensor*2
25.AFS control unit*226.Front height sensor*2
A. Front combination lamp (back) B. View with instrument driver lower
panel (LH)C. Rear suspension member (RH)
D. View with instrument lower cover E. Front suspension arm (RH)
Part Description
BCM Controls the exterior lighting system.
ECM*
1Transmits engine speed signal to AFS control unit. (via CAN communication)
TCM*
1Transmits Shift position signal to AFS control unit. (via CAN communication)
IPDM E/R Controls the integrated relay, and supplies voltage to the load according to the request
from BCM (via CAN communication).
AFS control unit*
1AFS control unit judges the vehicle condition from each signal. AFS control unit con-
trols AFS function and the headlamp aiming.
Combination meter Outputs the vehicle speed signal (8-pulse) to AFS control unit.
Blinks the turn signal indicator lamp and outputs the turn signal operating sound with
integrated buzzer according to the request from BCM (via CAN communication).
Turns the tail lamp indicator lamp and high beam indicator lamp ON according to the
request from BCM (via CAN communication).
Turns the AFS OFF indicator lamp ON/OFF /blinking according to the request from
AFS control unit (via CAN communication).
Headlamp assembly Xenon bulb Refer to
EXL-8, "
FRONT COMBINATION LAMP : Xenon Headlamp".
HID control unit Refer to EXL-9, "
FRONT COMBINATION LAMP : HID control unit".
High beam solenoid Refer to EXL-9, "
FRONT COMBINATION LAMP : High Beam Solenoid".
Aiming motor Refer to EXL-9, "
FRONT COMBINATION LAMP : Aiming Motor".
Swivel actuator*
1Refer to EXL-9, "FRONT COMBINATION LAMP : Swivel Actuator".
Height sensor*
1
The height sensor is installed to the front suspension member and rear suspension member.
The height sensor detects the suspension arm displacement as the vehicle height change.
The height sensor transmits the height sensor signal to AFS control unit.
NOTE:
The sensor angle of the unloaded vehicle position is the reference value.
Optical sensor Optical sensor converts the outside brightness (lux) to voltage and transmits the opti-
cal sensor signal to BCM.
Revision: 2010 May2011 QX56

Page 2718 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-8
< SYSTEM DESCRIPTION >[XENON TYPE]
COMPONENT PARTS
*1: With AFS system models
*
2: With headlamp aiming control system (manual) models
FRONT COMBINATION LAMP
FRONT COMBINATION LAMP : Xenon Head

EXL-8
< SYSTEM DESCRIPTION >[XENON TYPE]
COMPONENT PARTS
*1: With AFS system models
*
2: With headlamp aiming control system (manual) models
FRONT COMBINATION LAMP
FRONT COMBINATION LAMP : Xenon HeadlampINFOID:0000000006213889
OUTLINE
The lamp light source is by the arch discharge by
applying high voltage into the xenon gas-filled bulb instead
of the halogen bulb filament.
Sight becomes more natural and brighter because the amount of light are gained adequately and the color of
light is sunshine-like white.
The xenon bulb drops the amount of light, repeats blinking, and illuminates in red if the bulb reaches the ser-
vice life.
ILLUMINATION PRINCIPLE
1. Discharging starts in high voltage pulse between bulb elec- trodes.
2. Xenon gas is activated by curr ent between electrodes. Pale light
is emitted.
3. The luminous tube (bulb) temperature elevates. Evaporated halide is activated by discharge. The color of light changes into
white.
NOTE:
Brightness and the color of light may change slightly immediately after the headlamp turned ON until the xenon bulb becomes sta-
ble. This is not malfunction.
Illumination time lag may occur between right and left. This is not
malfunction.
PRECAUTIONS FOR TROUBLE DIAGNOSIS
Representative malfunction examples are; "Light does not turn ON", "Light blinks", and "Brightness is inade-
quate." The cause often be the xenon bulb. Such malf unctions, however, are occurred occasionally by HID
control unit malfunction or lamp case malfunction. S pecify the malfunctioning part with diagnosis procedure.
WARNING:
Never touch the harness, HID control unit, the inside and metal part of lamp when turning the head-
lamp ON or operating the lighting switch.
Never work with wet hands.
CAUTION:
Never perform HID control unit circuit diagnosis with a circuit tester or an equivalent.
Temporarily install the headlamps on the vehicle. Co nnect the battery to the connector (vehicle side)
when checking ON/OFF status.
Disconnect the battery negative terminal before di sconnecting the lamp socket connector or the har-
ness connector.
Check for fusing of the fusible link(s), open around connector, short, disconnection if the symptom
is caused by electric error.
NOTE:
Turn the switch OFF once before turni ng ON, if the ON/OFF is inoperative.
The xenon bulb drops the amount of light, repeats blinking, and illuminates in red if the bulb reaches the ser-
vice life.
Steering angle sensor*1Transmits steering angle sensor signal to AFS control unit. (via CAN communication)
Combination switch
(Lighting & turn signal switch) Refer to
BCS-7, "
COMBINATION SWITCH READING SYSTEM : System Descrip-
tion".
Door switch Inputs the door switch signal to BCM.
AFS switch*
1 Inputs the AFS switch signal to AFS control unit.
AFS switch is integrated in triple switch.
Headlamp aiming switch*
2Outputs the aiming motor drive signal to aiming motor.
Hazard switch Inputs the hazard switch signal to BCM. Part Description
JPLIA0421GB
Revision: 2010 May2011 QX56

Page 2719 of 5598

INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSEXL-9
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
FRONT COMBINATION LAMP : HID control unitINFOID:0000000006213890
Headlamp (LO) circuit is connected to HID c

Page 2720 of 5598

INFINITI QX56 2011 Factory Service Manual
EXL-10
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
SYSTEM
HEADLAMP SYSTEM
HEADLAMP SYSTEM : System DiagramINFOID:0000000006213894
HEADLAMP SYSTEM : System DescriptionINFOID:0000000006213895
OUTLINE
Hea
