31. Remove snap ring (1) from joint connector (A).
32. Push joint connector (A). CAUTION:
Be careful not to damage connector.
33. Remove clips (1) and oil pan mounting bolts ( ).
34. Remove oil pan (2) and oil pan gasket.
35. Remove magnets (1) from oil pan.
36. Disconnect output speed sensor connector (A). CAUTION:
Be careful not to damage connector.
37. Disengage terminal clips ( ).
JPDIA0007ZZ
JPDIA0008ZZ
: Front
JSDIA1591ZZ
JPDIA0009ZZ
JPDIA1104ZZ
Revision: 2010 May2011 QX56
