Page 4753 of 5598

INFINITI QX56 2011 Factory Service Manual
SEC-146
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
SECURITY INDICATOR LAMP
SECURITY INDICATOR LAMP
Component Function CheckINFOID:0000000006226312
1.CHECK FUNCTION
1. Perform “THEFT IND

Page 4754 of 5598

INFINITI QX56 2011 Factory Service Manual
SECURITY INDICATOR LAMPSEC-147
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3. Check continuity between combination meter harness connector and ground.
Is

Page 4755 of 5598

INFINITI QX56 2011 Factory Service Manual
SEC-148
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
ENGINE DOES NOT START WHEN INTELLI
GENT KEY IS INSIDE OF VEHICLE
SYMPTOM DIAGNOSIS
ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INSIDE OF V

Page 4756 of 5598

INFINITI QX56 2011 Factory Service Manual
STEERING DOES NOT LOCKSEC-149
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
STEERING DOES NOT LOCK
DescriptionINFOID:0000000006226325
Steering does not lock wh

Page 4757 of 5598

INFINITI QX56 2011 Factory Service Manual
SEC-150
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
SECURITY INDICATOR LAMP DO
ES NOT TURN ON OR BLINK
SECURITY INDICATOR LAMP DOES NOT TURN ON OR BLINK
DescriptionINFOID:0000000006226327
Secu

Page 4758 of 5598

INFINITI QX56 2011 Factory Service Manual
VEHICLE SECURITY SYSTEM CANNOT BE SET
SEC-151
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY S YSTEM CANNOT BE SET
INTELLIGENT KEY
INTELLIGENT

VEHICLE SECURITY SYSTEM CANNOT BE SET
SEC-151
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY S YSTEM CANNOT BE SET
INTELLIGENT KEY
INTELLIGENT KEY : DescriptionINFOID:0000000006226329
Armed phase is not activated when door is locked using Intelligent Key.
NOTE:
Check that vehicle is under the condition shown in “C onditions of vehicle” before starting diagnosis, and check
each symptom.
CONDITION OF VEHICLE (OPERATING CONDITION)
Confirm the setting of “SECUTIRY ALARM SET” is ON in “WORK SUPPORT” mode of “THEFT ALM” of
“BCM” using CONSULT-III.
INTELLIGENT KEY : Diagnosis ProcedureINFOID:0000000006226330
1.CHECK INTELLIGENT KEY SYSTEM (REMOTE KEYLESS ENTRY FUNCTION)
Lock/unlock door with Intelligent Key.
Refer to DLK-19, "
DOOR LOCK FUNCTION : System Description".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check Intelligent Key system (remote keyless entry function). Refer to DLK-175, "
Diagnosis Pro-
cedure".
2.CHECK HOOD SWITCH
Check hood swiwtch.
Refer to SEC-141, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace hood switch.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> GO TO 1.
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH : DescriptionINFOID:0000000006226331
Armed phase is not activated when door is locked using door request switch.
NOTE:
Check that vehicle is under the condition shown in “C onditions of vehicle” before starting diagnosis, and check
each symptom.
CONDITION OF VEHICLE (OPERATING CONDITION)
Confirm the setting of “SECURITY ALARM SET” is ON in “WORK SUPPORT” mode of “THEFT ALM” of
“BCM” using CONSULT-III.
DOOR REQUEST SWITCH : Diagnosis ProcedureINFOID:0000000006226332
1.CHECK INTELLIGENT KEY SYS TEM (DOOR LOCK FUNCTION)
Lock/unlock door with door request switch.
Refer to DLK-19, "
DOOR LOCK FUNCTION : System Description".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check Intelligent Key system (door lock function). Refer to DLK-172, "
ALL DOOR REQUEST
SWITCHES : Diagnosis Procedure".
Revision: 2010 May2011 QX56

Page 4759 of 5598

INFINITI QX56 2011 Factory Service Manual
SEC-152
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY SYSTEM CANNOT BE SET
2.CHECK HOOD SWITCH
Check hood swiwtch.
Refer to SEC-141, "
ComponentFunctionCheck".
Is the inspectio

Page 4760 of 5598

INFINITI QX56 2011 Factory Service Manual
VEHICLE SECURITY ALARM DOES NOT ACTIVATE
SEC-153
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY ALAR M DOES NOT ACTIVATE
DescriptionINFOID:0000
