INFINITI QX56 2011 Factory Service Manual SE-134 < REMOVAL AND INSTALLATION > SECOND SEAT 3. Remove the retainer (A) of the armrest trim. Remove the arm-rest trim from the armrest pad and frame. ASSEMBLY Assemble in the reverse order of disa

Page 4594 of 5598

INFINITI QX56 2011 Factory Service Manual SECOND SEATSE-135 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B SE N O P 1. Align to hole and insert top end (A) of seatback frame side of seat cushion control wire (1). 2. Fit 2nd groove from

Page 4595 of 5598

INFINITI QX56 2011 Factory Service Manual SE-136 < REMOVAL AND INSTALLATION > SECOND SEAT - Fit 3rd groove from the top end of adjusting plastic portion (A)to the end of groove. - Check that ball of wire tor end is only visible from sponge

Page 4596 of 5598

INFINITI QX56 2011 Factory Service Manual THIRD SEATSE-137 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B SE N O P THIRD SEAT Exploded ViewINFOID:0000000006217435 1. Headrest RH 2. Headrest holder (free) 3. Headrest holder (locked) 4. S

Page 4597 of 5598

INFINITI QX56 2011 Factory Service Manual SE-138 < REMOVAL AND INSTALLATION > THIRD SEAT Removal and Installation INFOID:0000000006217436 REMOVAL CAUTION: When removing and installi ng, use shop cloths to protect parts from damage. 1. Remove

Page 4598 of 5598

INFINITI QX56 2011 Factory Service Manual THIRD SEATSE-139 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B SE N O P Install in the reverse order of removal. Disassembly and AssemblyINFOID:0000000006217437 SEATBACK Disassembly 1. Remove t

Page 4599 of 5598

INFINITI QX56 2011 Factory Service Manual SE-140 < REMOVAL AND INSTALLATION > THIRD SEAT 1. Remove the headrest holder.CAUTION: Before installing headrest ho lder check its orientation. (front/rear and right/left) 2. Remove the seatback tri

Page 4600 of 5598

INFINITI QX56 2011 Factory Service Manual POWER SEAT SWITCHSE-141 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B SE N O P POWER SEAT SWITCH Removal and InstallationINFOID:0000000006217438 REMOVAL CAUTION: When removing and in stalling,
