Page 5225 of 5598
![INFINITI QX56 2011 Factory Service Manual
P1705 TP SENSORTM-137
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P1705 TP SENSOR
DTC LogicINFOID:0000000006226852
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECON INFINITI QX56 2011 Factory Service Manual
P1705 TP SENSORTM-137
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P1705 TP SENSOR
DTC LogicINFOID:0000000006226852
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECON](/manual-img/42/57033/w960_57033-5224.png)
P1705 TP SENSORTM-137
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P1705 TP SENSOR
DTC LogicINFOID:0000000006226852
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “SLCT LVR POSI” and “VHCL/S SE-A/T ” in “Data Monitor” in “TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 5 seconds or more.
4. Perform “Self Diagnostic Resu lts” in “TRANSMISSION”.
Is
“P1705” detected?
YES >> Go to TM-137, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226853
1.CHECK DTC OF ECM
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Results” in “ENGINE”.
Is any DTC detected?
YES >> Check DTC detect ed item. Refer to EC-98, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF TCM
With CONSULT-III
Perform “Self Diagnostic Resu lts” in “TRANSMISSION”.
Is any DTC other than
“P1705” detected?
YES >> Check DTC detect ed item. Refer to TM-78, "DTC Index".
NO >> GO TO 3.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P1705 Accelerator Peda
l Position Sen-
sor Signal Circuit TCM detects the difference be-
tween two accelerator pedal po-
sition signals received from
ECM via CAN communication.Harness or connectors
(Sensor circuit is open or short-
ed.)
SLCT LVR POSI : D
VHCL/S SE-A/T : 5 km/h (3 MPH) or more
Revision: 2010 May2011 QX56
Page 5226 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-138
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1721 VEHICLE SPEED SIGNAL
P1721 VEHICLE SPEED SIGNAL
DescriptionINFOID:0000000006226854
The vehicle speed signal is transmitted from combinati
on meter INFINITI QX56 2011 Factory Service Manual
TM-138
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1721 VEHICLE SPEED SIGNAL
P1721 VEHICLE SPEED SIGNAL
DescriptionINFOID:0000000006226854
The vehicle speed signal is transmitted from combinati
on meter](/manual-img/42/57033/w960_57033-5225.png)
TM-138
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1721 VEHICLE SPEED SIGNAL
P1721 VEHICLE SPEED SIGNAL
DescriptionINFOID:0000000006226854
The vehicle speed signal is transmitted from combinati
on meter to TCM via CAN communication line. The sig-
nal functions as an auxiliary device to the output speed sensor when it is malfunctioning. The TCM will then
use the vehicle speed signal.
DTC LogicINFOID:0000000006226855
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
Be careful not to rev engine into the red zone on the tachometer.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “VHCL/S SE-A/T” in “Data Monitor” in “TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 60 seconds or more.
4. Perform “Self Diagnostic Results” in “TRANSMISSION”.
Is
“P1721” detected?
YES >> Go to TM-139, "Diagnosis Procedure".
NO >> INSPECTION END
DTC Trouble diagnosis name DTC is detected if... Possible cause
P1721 Vehicle Speed Signal Circuit The vehicle speed transmit-
ted from the combination
meter to TCM is 5 km/h
(3MPH) or less when the ve-
hicle speed detected by the
output speed sensor is 20
km/h or more. (Only when
starts after the ignition switch
is turned ON.)
The vehicle speed detected by the output speed sensor
does not decrease despite
the 36 km/h (23 MPH) or
more of deceleration in vehi-
cle speed received from the
combination meter when the
vehicle speed transmitted
from the combination meter
to TCM is 36 km/h (23 MPH)
or more and the vehicle
speed detected by the output
speed sensor is 24 (15 MPH)
or more. Harness or connectors
(Sensor circuit is open or short-
ed.)
VHCL/S SE-A/T : 40 km/h (25 MPH) or more
Revision: 2010 May2011 QX56
Page 5227 of 5598
P1721 VEHICLE SPEED SIGNALTM-139
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Diagnosis ProcedureINFOID:0000000006226856
1.CHECK DTC OF UNIFIED METER AND A/C AMP.
With CONSULT-III
Perform “Self Diagnostic Results” in “METER/M&A”.
Is any DTC detected?
YES >> Check DTC detect ed item. Refer to MWI-43, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF TCM
With CONSULT-III
Perform “Self Diagnostic Resu lts” in “TRANSMISSION”.
Is any DTC other than
“P1721” detected?
YES >> Check DTC detect ed item. Refer to TM-78, "DTC Index".
NO >> GO TO 3.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
Revision: 2010 May2011 QX56
Page 5228 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-140
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1730 INTERLOCK
P1730 INTERLOCK
DescriptionINFOID:0000000006226857
Fail-safe function to detect interlock conditions.
DTC LogicINFOID:0000000006226858
D INFINITI QX56 2011 Factory Service Manual
TM-140
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1730 INTERLOCK
P1730 INTERLOCK
DescriptionINFOID:0000000006226857
Fail-safe function to detect interlock conditions.
DTC LogicINFOID:0000000006226858
D](/manual-img/42/57033/w960_57033-5227.png)
TM-140
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1730 INTERLOCK
P1730 INTERLOCK
DescriptionINFOID:0000000006226857
Fail-safe function to detect interlock conditions.
DTC LogicINFOID:0000000006226858
DTC DETECTION LOGIC
NOTE:
When the vehicle is driven fixed
in 2GR, an input speed sensor malfunction is displayed, but this is
not an input speed sensor malfunction.
DTC CONFIRMATION PROCEDURE
CAUTION:
“TM-141, "
Diagnosis Procedure"” must be performed before star ting “DTC CONFIRMATION PROCE-
DURE”.
Never perform “DTC CONFIRMATION PROCEDURE” before completing the repair, which may cause
secondary malfunction.
Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “SLCT LVR POSI” and “GEAR” in “Data Monitor” in “TRANSMISSION”.
3. Drive vehicle the following condition.
4. Perform “Self Diagnostic Results” in “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P1730” detected?
YES >> Go to TM-141, "Diagnosis Procedure".
NO >> INSPECTION END
Judgment of InterlockINFOID:0000000006226859
Refer to TM-74, "Fail-Safe".
DTC Trouble diagnosis name DTC is detected if... Possible cause
P1730 Interlock The output speed sensor de-
tects the deceleration of 12 km/
h (7 MPH) or more for 1 sec-
ond. Harness or connectors
(Solenoid valve circuit is open
or shorted.)
Input clutch solenoid valve
Direct clutch solenoid valve
High and low reverse clutch solenoid valve
Front brake solenoid valve
Low brake solenoid valve
2346 brake solenoid valve
Anti-interlock solenoid valve
Each clutch
Hydraulic co ntrol circuit
SLCT LVR POSI : D
GEAR : 1st through 7th
Revision: 2010 May2011 QX56
Page 5229 of 5598
P1730 INTERLOCKTM-141
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Diagnosis ProcedureINFOID:0000000006226860
1.DETECT MALFUNCTIONING ITEM
Disassemble the A/T assembly to check component parts. Refer to TM-226, "
Disassembly".
NOTE:
Check the component parts, referring to “Possibl e cause” in “DTC DETECTION LOGIC”. Refer to TM-140,
"DTC Logic".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
Revision: 2010 May2011 QX56
Page 5230 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-142
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1734 7GR INCORRECT RATIO
P1734 7GR INCORRECT RATIO
DescriptionINFOID:0000000006226861
This malfunction is detected when the A/T does not shift
into 7G INFINITI QX56 2011 Factory Service Manual
TM-142
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1734 7GR INCORRECT RATIO
P1734 7GR INCORRECT RATIO
DescriptionINFOID:0000000006226861
This malfunction is detected when the A/T does not shift
into 7G](/manual-img/42/57033/w960_57033-5229.png)
TM-142
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1734 7GR INCORRECT RATIO
P1734 7GR INCORRECT RATIO
DescriptionINFOID:0000000006226861
This malfunction is detected when the A/T does not shift
into 7GR position as instructed by TCM. This is not
only caused by electrical malfunction (circuits open or s horted) but by mechanical malfunction such as control
valve sticking, improper solenoid valve operation, etc.
DTC LogicINFOID:0000000006226862
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
“ TM-143, "
Diagnosis Procedure"” must be performed before star ting “DTC CONFIRMATION PROCE-
DURE”.
Never perform “DTC CONFIRMATION PROCEDURE” before completing the repair, which may cause secondary malfunction.
Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK ATF TEMPERATURE
With CONSULT-III
1. Start the engine.
2. Select “ATF TEMP 1” in “Data Monitor” in “TRANSMISSION”.
3. Check ATF temperature is in the following range.
With GST
1. Start the engine.
2. Drive vehicle for approximately 5 minutes in urban areas.
Is ATF temperature within specified range?
YES >> GO TO 3.
NO >> Drive vehicle to warm ATF or stop engine to cool ATF.
3.CHECK SYMPTOM (PART 1)
With CONSULT-III
1. Select “7TH GR FNCTN P1734” in “DTC & SRT confirmation” in “TRANSMISSION”.
2. Drive vehicle with manual mode and maintain the following conditions.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P1734 Gear 7 Incorrect Ratio The gear ratio is:
0.821 or more
0.729 or less Input clutch solenoid valve
Direct clutch solenoid valve
High and low reverse clutch
solenoid valve
Front brake solenoid valve
Low brake solenoid valve
2346 brake solenoid valve
Anti-interlock solenoid valve
Each clutch and brake
Output speed sensor
Input speed sensor 1, 2
Hydraulic control circuit
ATF TEMP 1 : 20 °C (68 °F) – 140 °C (284 °F)
Revision: 2010 May2011 QX56
Page 5231 of 5598
![INFINITI QX56 2011 Factory Service Manual
P1734 7GR INCORRECT RATIOTM-143
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
3. Keep the current driving status for 2 seconds or more if CONSULT-III screen changes from INFINITI QX56 2011 Factory Service Manual
P1734 7GR INCORRECT RATIOTM-143
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
3. Keep the current driving status for 2 seconds or more if CONSULT-III screen changes from](/manual-img/42/57033/w960_57033-5230.png)
P1734 7GR INCORRECT RATIOTM-143
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
3. Keep the current driving status for 2 seconds or more if CONSULT-III screen changes from “OUT OF
CONDITION” to “TESTING”.
CAUTION:
When “TESTING” is not indicated on CONSULT-III for a long time, check “Self Diagnostic Results”
in “TRANSMISSION”. When a DTC other than “P1734” is detected, check the DTC. Refer to TM-78,
"DTC Index".
With GST
1. Drive vehicle and maintain the following conditions for 2 seconds or more.
2. Check DTC.
Is
“OUT OF CONDITION”, “STOP VEHICLE” or “COMPLETED RESULT NG” displayed? / Is “P1734”
detected?
YES-1 (OUT OF CONDITION) >>Perform “Step 3” again.
YES-2 (STOP VEHICLE)>>GO TO 4.
YES-3 (COMPLETED RESULT NG)>>Go to TM-143, "
Diagnosis Procedure".
YES-4 (“P1734” is detected)>>Go to TM-143, "
Diagnosis Procedure".
NO >> GO TO 4.
4.CHECK SYMPTOM (PART 2)
With CONSULT-III
1. Stop vehicle.
2. Drive vehicle in “D” position allowing it to shift from 1GR to 7GR and check shift timing and shift shock.
>> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226863
1.DETECT MALFUNCTIONING ITEM
Disassemble the A/T assembly to check component parts. Refer to TM-226, "
Disassembly".
NOTE:
Check the component parts, referring to “Possibl e cause” in “DTC DETECTION LOGIC”. Refer to TM-142,
"DTC Logic".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
GEAR : 7th
ACCELE POSI : 0.7/8 or more
VEHICLE SPEED : 10 km/h (7 MPH) or more
Selector lever : “M” position
Gear position : 7th
Accelerator pedal opening : 0.7/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Revision: 2010 May2011 QX56
Page 5232 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-144
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1815 M-MODE SWITCH
P1815 M-MODE SWITCH
DTC LogicINFOID:0000000006226864
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONF INFINITI QX56 2011 Factory Service Manual
TM-144
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1815 M-MODE SWITCH
P1815 M-MODE SWITCH
DTC LogicINFOID:0000000006226864
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONF](/manual-img/42/57033/w960_57033-5231.png)
TM-144
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P1815 M-MODE SWITCH
P1815 M-MODE SWITCH
DTC LogicINFOID:0000000006226864
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “SLCT LVR POSI” and “MANU MODE SW ” in “Data Monitor” in “TRANSMISSION”.
3. Maintain the following each conditions more than 2 seconds.
4. Perform “Self Diagnostic Results” in “TRANSMISSION”.
Is
“P1815” detected?
YES >> Go to TM-144, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226865
1.CHECK MANUAL MODE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect A/T shift selector connector.
3. Turn ignition switch ON.
4. Check voltage between A/T shift selector vehicle side harness connector terminals.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK MANUAL MODE SWITCH
DTC Trouble diagnosis name DTC is detected if... Possible cause
P1815 Manual Mode Switch Circuit TCM monitors manual mode,
non manual mode, up or down
switch signal, and detects as ir-
regular when impossible input
pattern occurs 2 second or
more. Harness or connectors
(These switches circuit is
open or shorted.)
Manual mode switch
SLCT LVR POSI : D
MANU MODE SW : ON
A/T shift selector vehicle side harness connector
Voltage (Approx.)
Connector Te r m i n a l
+ −
M57 1
4 Battery voltage
2
3
5
Revision: 2010 May2011 QX56
