Page 2393 of 5598

INFINITI QX56 2011 Factory Service Manual
P0527 COOLING FAN SPEED SENSOREC-369
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is inspection result normal?
YES >> Check intermittent incident. Refer to
GI-40, "Intermittent

P0527 COOLING FAN SPEED SENSOREC-369
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is inspection result normal?
YES >> Check intermittent incident. Refer to
GI-40, "Intermittent Incident".
NO >> Repair or replace error-detected parts.
6.CHECK COOLING FAN SPEED SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electrically-contro lled cooling fan coupling harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and to power.
Is inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts.
7.CHECK COOLING FAN SPEED SENSOR
1. Reconnect all harness connectors disconnected.
2. Perform cooling fan speed sensor component inspection. Refer to EC-369, "
Component Inspection (Cool-
ing Fan Speed Sensor)".
Is inspection result normal?
YES >> GO TO 8.
NO >> Replace electrically-controlled cooling fan coupling.
8.CHECK COOLING FAN ROTATIONAL CONDITION
Rotate the cooling fan by hand.
Dose the cooling fan rotates smoothly?
YES >> GO TO 9.
NO >> Check that the cooling fan is not interfered with other parts.
9.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING SYSTEM
Refer to EC-495, "
Diagnosis Procedure".
Is inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace error-detected parts.
Component Inspection (C ooling Fan Speed Sensor)INFOID:0000000006217869
1.CHECK COOLING FAN SPEED SENSOR
1. Turn ignition switch OFF.
2. Disconnect electrically-controlled c ooling fan coupling harness connector.
3. Rotate the electrically-controlled cooling fan coupling slowly with hand and check the voltage between
electrically-controlled cooling fan coupling c onnector terminals under the following conditions.
+
−Continuity
ECM
Connector Terminal F 111 1 0 Ground Existed
E80 174
175
+
−
Continuity
Electrically-controlled cooling fan
coupling ECM
Connector Terminal Connector Terminal F39 5 F111 37 Existed
Revision: 2010 May2011 QX56

Page 2394 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-370
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0527 COOLING FAN SPEED SENSOR
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace Electrically-controlled cooling fan coupling.
+
−
Condit

Page 2395 of 5598

INFINITI QX56 2011 Factory Service Manual
P0550 PSP SENSOREC-371
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0550 PSP SENSOR
DTC LogicINFOID:0000000006217870
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITI

Page 2396 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-372
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0550 PSP SENSOR
Is inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect EC

Page 2397 of 5598

INFINITI QX56 2011 Factory Service Manual
P0550 PSP SENSOREC-373
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
6.CHECK PSP SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.

Page 2398 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-374
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0603 ECM POWER SUPPLY
P0603 ECM POWER SUPPLY
DTC LogicINFOID:0000000006217873
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn igniti

Page 2399 of 5598

INFINITI QX56 2011 Factory Service Manual
P0603 ECM POWER SUPPLYEC-375
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Refer to
GI-40, "Intermittent Incident".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair

Page 2400 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-376
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0605 ECM
P0605 ECM
DTC LogicINFOID:0000000006217875
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at
