Page 5329 of 5598
TRANSMISSION ASSEMBLYTM-241
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
56. Remove manual plate (1) from detent spring (2).
57. Remove parking rod (3) from manual plate.
58. Install manual plate to detent spring.
59. Use a pin punch [4 mm (0.16 in) dia. commercial service tool] to knock out retaining pin (1).
60. Remove manual plate from manual shaft.
61. Remove manual shaft from transmission case.
62. Remove manual shaft oil seals using a flat-bladed screwdriver. CAUTION:
Be careful not to scratch transmission case.
JPDIA1131ZZ
JPDIA1132ZZ
SCIA5715E
SCIA5716E
SCIA2331E
Revision: 2010 May2011 QX56
Page 5330 of 5598
TM-242
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
63. Remove detent spring (1) from transmission case.
64. Remove needle bearing (1) from rear extension (2WD) or
adapter case (4WD).
65. Remove parking actuator support from rear extension (2WD) or adapter case (4WD).
66. Remove parking pawl (with return spring) and pawl shaft from rear extension (2WD) or adapter case (4WD).
67. Remove return spring (1) from parking pawl (2).
: Bolt
JPDIA1134ZZ
SCIA6179J
SCIA3423E
SCIA3424E
SCIA6180J
Revision: 2010 May2011 QX56
Page 5331 of 5598
TRANSMISSION ASSEMBLYTM-243
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
68. Remove rear oil seal from rear extension (B) or adapter case (C) using a flat-bladed screwdriver (A).
CAUTION:
Be careful not to scratch adapter case.
AssemblyINFOID:0000000006226918
1. As shown in the figure, use a drift [22 mm (0.87 in) dia. commer-cial service tool] to drive manual shaft oil seals into the transmis-
sion case until it is flush.
CAUTION:
Never reuse manual shaft oil seals.
Apply ATF to manual shaft oil seals.
2. Install detent spring to transmission case. Tighten detent spring bolt to the specified torque.
B: 2WD
C: 4WD
JSDIA0157ZZ
SCIA5259E
: Bolt
JPDIA1134ZZ
Revision: 2010 May2011 QX56
Page 5332 of 5598
TM-244
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
3. Install manual shaft to transmission case.
4. Install parking rod (1) to manual plate (2).
5. Install manual plate (with parking rod) to manual shaft.
6. Install retaining pin (1) into the manual plate and manual shaft.
a. Fit pinhole of the manual plate to pinhole of the manual shaft
with a pin punch.
b. Use a hammer to tap the retaining pin into the manual plate.
CAUTION:
Drive retaining pin to 2 ±0.5 mm (0.08 ±0.020 in) over the
manual plate.
7. Install retaining pin into the transmission case and manual shaft.
a. Fit pinhole of the transmission case to pinhole of the manual shaft with a pin punch.
b. Use a hammer to tap the retaining pin into the transmission case.
CAUTION:
Drive retaining pin to 5 ±1 mm (0.20 ±0.04 in) over the trans-
mission case.
SCIA5716E
JSDIA1820ZZ
SCIA5715E
A : Approx. 2 mm (0.08in)
JPDIA1133ZZ
SCIA2427E
Revision: 2010 May2011 QX56
Page 5333 of 5598
TRANSMISSION ASSEMBLYTM-245
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
8. Install D-rings in reverse brake piston.
9. Install reverse brake piston in transmission case.
10. Install needle bearing to drum support edge surface. CAUTION:
Check the direction of needle bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
11. Install seal rings to drum support.
12. Install reverse brake spring retainer and reverse brake return spring in transmission case.
SCIA6330E
SCIA2325E
SCIA2796E
SCIA3333E
SCIA2324E
Revision: 2010 May2011 QX56
Page 5334 of 5598
TM-246
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
13. Set the clutch spring compressor (SST: KV31102400) on
reverse brake spring retainer and install snap ring (fixing spring
retainer) in transmission case while compressing return spring.
CAUTION:
Securely assemble them using a flat-bladed screwdriverso that snap ring te nsion is slightly weak.
Be careful not to damage snap ring.
14. Install reverse brake drive plates, driven plates, dish plates and retaining plate in transmission case.
CAUTION:
Check order of plates.
15. Assemble N-spring.
16. Install reverse brake retaining plate in transmission case.
SCIA6700E
1: Snap ring
2 : Retaining plate
3 : Drive plate (eight pieces)
4 : Driven plate (eight pieces)
5: Dish plate
6: Dish plate
JSDIA1858ZZ
SCIA5249E
Revision: 2010 May2011 QX56
Page 5335 of 5598
![INFINITI QX56 2011 Factory Service Manual
TRANSMISSION ASSEMBLYTM-247
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
17. Install snap ring in transmission case. CAUTION:
Be careful not to damage snap ring.
1 INFINITI QX56 2011 Factory Service Manual
TRANSMISSION ASSEMBLYTM-247
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
17. Install snap ring in transmission case. CAUTION:
Be careful not to damage snap ring.
1](/manual-img/42/57033/w960_57033-5334.png)
TRANSMISSION ASSEMBLYTM-247
< UNIT DISASSEMBLY AND ASSEMBLY > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
17. Install snap ring in transmission case. CAUTION:
Be careful not to damage snap ring.
18. Measure clearance between retaining plate and snap ring. If not within specified clearance, select proper retaining plate.
19. Install needle bearing to transmission case. CAUTION:
Check the direction of needle bearing. Refer to TM-222,
"Location of Needle Bearings and Bearing Races".
20. Install output speed sensor (1) to transmission case. Tighten revolution sensor bolt to the specified torque.
CAUTION:
Never subject it to impact by dropping or hitting it.
Never disassemble.
Never allow metal filings, etc. to get on the sensor's front
edge magnetic area.
Never place in an area affected by magnetism.
SCIA2439E
Specified clearance “A”
Standard: TM-298, "
Reverse Brake Clearance".
Retaining plate: Refer to TM-298, "
Reverse Brake Clear-
ance"
SCIA3129E
SCIA5031E
: Bolt
JSDIA1321ZZ
Revision: 2010 May2011 QX56
Page 5336 of 5598
TM-248
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
21. As shown in the figure, use the drift to drive rear oil seal into the
rear extension (2WD) (A) or adapter case (4WD) (B) until it is
flush.
CAUTION:
Never reuse rear oil seal.
Apply ATF to rear oil seal.
22. Install return spring (1) to parking pawl (2).
23. Install parking pawl (with return spring) and pawl shaft to rear extension (2WD) or adapter case (4WD).
24. Install parking actuator support to rear extension (2WD) or adapter case (4WD).
1 : Drift [SST: 33400001 (J-26082)]
2 : Drift [Commercial service tool Ø64 mm (2.52 in)]
JSDIA1914ZZ
SCIA6180J
SCIA3424E
SCIA3423E
Revision: 2010 May2011 QX56
