Page 2209 of 5598

INFINITI QX56 2011 Factory Service Manual
P0037, P0038, P0057, P0058 HO2S2 HEATER
EC-185
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONI

Page 2210 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-186
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0037, P0038, P0057,
P0058 HO2S2 HEATER
Component Inspection (HO2 Sensor 2 Heater)
INFOID:0000000006217780
1.CHECK HEATED OXYGEN SENSOR 2 HEATER
1. Turn igni

Page 2211 of 5598

INFINITI QX56 2011 Factory Service Manual
P006A, P0101 MAF SENSOREC-187
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P006A, P0101 MAF SENSOR
DTC LogicINFOID:0000000006288269
DTC DETECTION LOGIC
NOTE:
If DTC P006A or P01

P006A, P0101 MAF SENSOREC-187
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P006A, P0101 MAF SENSOR
DTC LogicINFOID:0000000006288269
DTC DETECTION LOGIC
NOTE:
If DTC P006A or P0101 is displayed with other DTC,
first perform the trouble diagnosis for other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If engine will not start or stops soon, wait at leas t 10 seconds with engine stopped (Ignition switch ON) instead
of running engine at idle speed.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode with CONSULT-III.
2. Start engine and warm it up to normal operating temperature.
3. Accelerate the vehicle from 0 km/h (0 MPH) to 88 km/h (55 MPH) under the following conditions:
CAUTION:
Always drive at a safe speed.
NOTE:
Accelerate with the accelerator pedal kept constant.
The acceleration at engine speed 2,000 and 3,000 rpm allows easy diagnoses
4. Check 1st trip DTC. WITHOUT CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. With selector lever in D position, accelerate the vehicle from 0 km/h (0 MPH) to 88 km/h (55 MPH) under
the following conditions:
NOTE:
Accelerate with the accelerator pedal kept constant.
The acceleration at engine speed 2,000 and 3,000 rpm allows easy diagnoses.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P006A MAP-MAF CORELTION-B1
(Manifold pressure
- mass air
flow correlation) A difference exceeding the specified value develops
between a value transmitted from the manifold absolute
pressure sensor to ECM and an estimated intake pres-
sure of intake manifold calculated by ECM, based on a
mass sir flow sensor signal. Harness or connectors
(The sensor circuit is open
or shorted.)
Mass air flow sensor
Manifold absolute pressure
sensor
EVAP control system pres-
sure sensor
Intake air leaks
Intake air temperature sen- sor
P0101 MAF SEN/CIRCUIT-B1
(Mass air flow sensor circuit
range/performance) A difference exceeding the specified value develops
between a signal transmitted from the mass air flow
sensor to ECM.
Mass air flow sensor
ACCEL SEN 1 1.4 – 2.0 V
Selector lever D position
Revision: 2010 May2011 QX56

Page 2212 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-188
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P006A, P0101 MAF SENSOR
CAUTION:
Always drive at a safe speed.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-188, "Diagnosis Procedur

Page 2213 of 5598

INFINITI QX56 2011 Factory Service Manual
P006A, P0101 MAF SENSOREC-189
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit, short to ground or short t

P006A, P0101 MAF SENSOREC-189
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK MASS AIR FLOW SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between mass air flow sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
6.CHECK MANIFOLD ABSO LUTE PRESSURE SENSOR
Check manifold absolute pressure sensor. Refer to EC-208, "
Component Inspection (MAP Sensor)".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace manifold absolute pressure sensor. Refer to EM-30, "
Removal and Installation".
7.CHECK INTAKE AIR TEMPERATURE SENSOR
Check intake air temperature sensor. Refer to EC-225, "
Component Inspection (Intake Air Temperature Sen-
sor)".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace mass air flow sensor (with intake air temperature sensor). Refer to EM-27, "
Removal and
Installation".
8.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR
Refer to EC-335, "
Component Inspection (EVAP Control System Pressure Sensor)".
Is the inspection result normal?
YES-1 (Only DTC P006A is detected)>>GO TO 9.
YES-2 (DTC P006A and P0101 are detected)>>GO TO 10.
NO >> Replace EVAP control system pressure sensor. Refer to FL-12, "
Removal and Installation".
9.CHECK MASS AIR FLOW SENSOR
Refer to EC-190, "
Component Inspection (MAF Sensor)".
Is the inspection result normal?
YES >> GO TO 11.
NO >> Replace mass air flow sensor.
10.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor. Refer to EC-190, "
Component Inspection (MAF Sensor)".
Is the inspection result normal?
YES >> GO TO 11.
NO >> Replace mass air flow sensor. Refer to EM-27, "
Removal and Installation".
11 .CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Mass air flow sensor ECM Continuity
Connector Terminal Connector Terminal
F 3 1 3 F 111 2 2 E x i s t e d
Revision: 2010 May2011 QX56

Page 2214 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-190
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P006A, P0101 MAF SENSOR
Component Inspection (MAF Sensor)
INFOID:0000000006288271
1.CHECK MASS AIR FLOW SENSOR-I
WITH CONSULT-III
1. Turn ignition switch OFF.

EC-190
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P006A, P0101 MAF SENSOR
Component Inspection (MAF Sensor)
INFOID:0000000006288271
1.CHECK MASS AIR FLOW SENSOR-I
WITH CONSULT-III
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Start engine and warm it up to normal operating temperature.
4. Connect CONSULT-III and select “DATA MONITOR” mode.
5. Select “MAS A/F SE-B1”, and check the indication.
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
WITHOUT CONSULT-III
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Start engine and warm it up to normal operating temperature.
4. Check the voltage between ECM harness connector terminals under the following conditions.
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK FOR THE CAUSE OF UNEVEN AIR FL OW THROUGH MASS AIR FLOW SENSOR
1. Turn ignition switch OFF.
2. Check for the cause of uneven air flow through mass air flow sensor. Refer to the following.
- Crushed air ducts
- Malfunctioning seal of air cleaner element
- Uneven dirt of air cleaner element
- Improper specification of intake air system parts
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK MASS AIR FLOW SENSOR-II
WITH CONSULT-III
1. Repair or replace malfunctioning part.
2. Start engine and warm it up to normal operating temperature.
3. Connect CONSULT-III and select “DATA MONITOR” mode.
4. Select “MAS A/F SE-B1””, and check the indication.
Monitor item Condition Indication (V)
MAS A/F SE-B1 Ignition switch ON (Engine stopped.) Approx. 0.4
Idle (Engine is warmed-up to normal operating temperature.) 0.9 - 1.1
2,500 rpm (Engine is warmed-up to normal operating temperature.) 1.4 - 1.9
Idle to about 4,000 rpm 0.9 - 1.1 to Approx. 2.4*
ECM Condition Voltage (V)
Connector +–
Terminal Terminal
F 111 22
(MAF sensor signal) 25Ignition switch ON (Engine stopped.) Approx. 0.4
Idle (Engine is warmed-up to normal operat-
ing temperature.)
0.9 - 1.1
2,500 rpm (Engine is warmed-up to normal
operating temperature.) 1.4 - 1.9
Idle to about 4,000 rpm 0.9 - 1.1 to Approx. 2.4*
Revision: 2010 May2011 QX56

Page 2215 of 5598

INFINITI QX56 2011 Factory Service Manual
P006A, P0101 MAF SENSOREC-191
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
WITHOUT CON

P006A, P0101 MAF SENSOREC-191
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
WITHOUT CONSULT-III
1. Repair or replace malfunctioning part.
2. Start engine and warm it up to normal operating temperature.
3. Check the voltage between ECM harness connector terminals under the following conditions.
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 4.
4.CHECK MASS AIR FLOW SENSOR-III
WITH CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect mass air flow sensor har ness connector and reconnect it again.
3. Start engine and warm it up to normal operating temperature.
4. Connect CONSULT-III and select “DATA MONITOR” mode.
5. Select “MAS A/F SE-B1” , and check the indication.
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
WITHOUT CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect mass air flow sensor har ness connector and reconnect it again.
3. Start engine and warm it up to normal operating temperature.
4. Check the voltage between ECM harness connector terminals under the following conditions.
Monitor item Condition Indication (V)
MAS A/F SE-B1 Ignition switch ON (Engine stopped.) Approx. 0.4
Idle (Engine is warmed-up to normal operating temperature.) 0.9 - 1.1
2,500 rpm (Engine is warmed-up to normal operating temperature.) 1.4 - 1.9
Idle to about 4,000 rpm 0.9 - 1.1 to Approx. 2.4*
ECM
Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
F 111 22
(MAF sensor signal) 25Ignition switch ON (Engine stopped.) Approx. 0.4
Idle (Engine is warmed-up to normal operat-
ing temperature.)
0.9 - 1.1
2,500 rpm (Engine is warmed-up to normal
operating temperature.) 1.4 - 1.9
Idle to about 4,000 rpm 0.9 - 1.1 to Approx. 2.4*
Monitor item Condition Indication (V)
MAS A/F SE-B1 Ignition switch ON (Engine stopped.) Approx. 0.4
Idle (Engine is warmed-up to normal operating temperature.) 0.9 - 1.1
2,500 rpm (Engine is warmed-up to normal operating temperature.) 1.4 - 1.9
Idle to about 4,000 rpm 0.9 - 1.1 to Approx. 2.4*
Revision: 2010 May2011 QX56

Page 2216 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-192
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P006A, P0101 MAF SENSOR
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection result normal?
YES >> INS

Load next 8 pages

Page: < prev 1-10 ... 2177-2184 2185-2192 2193-2200 2201-2208 2209-2216 2217-2224 2225-2232 2233-2240 2241-2248 ... 5600 next >

rear view mirror start stop button warning light 4WD homelink key fob
