Page 2793 of 5598

INFINITI QX56 2011 Factory Service Manual U1010 CONTROL UNIT (CAN)EXL-83 < DTC/CIRCUIT DIAGNOSIS > [XENON TYPE] C D E F G H I J K M A B EXL N O P U1010 CONTROL UNIT (CAN) DTC LogicINFOID:0000000006213951 DTC DETECTION LOGIC Diagnosis Procedu

Page 2794 of 5598

INFINITI QX56 2011 Factory Service Manual EXL-84 < DTC/CIRCUIT DIAGNOSIS >[XENON TYPE] POWER SUPPLY AND GROUND CIRCUIT POWER SUPPLY AND GROUND CIRCUIT AFS CONTROL UNIT AFS CONTROL UNIT : Diagnosis ProcedureINFOID:0000000006213953 1.FUSE INSP

Page 2795 of 5598

INFINITI QX56 2011 Factory Service Manual EXTERIOR LAMP FUSEEXL-85 < DTC/CIRCUIT DIAGNOSIS > [XENON TYPE] C D E F G H I J K M A B EXL N O P EXTERIOR LAMP FUSE Diagnosis ProcedureINFOID:0000000006213954 1.CHECK FUSE Check that the following f

Page 2796 of 5598

INFINITI QX56 2011 Factory Service Manual EXL-86 < DTC/CIRCUIT DIAGNOSIS >[XENON TYPE] HEADLAMP (HI) CIRCUIT HEADLAMP (HI) CIRCUIT Component Function CheckINFOID:0000000006213955 1.CHECK HEADLAMP (HI) OPERATION CONSULT-III ACTIVE TEST 1. Sel

Page 2797 of 5598

INFINITI QX56 2011 Factory Service Manual HEADLAMP (HI) CIRCUITEXL-87 < DTC/CIRCUIT DIAGNOSIS > [XENON TYPE] C D E F G H I J K M A B EXL N O P 2. Check that the following fuses are not fusing. Is the inspection result normal? YES >> Replace

Page 2798 of 5598

INFINITI QX56 2011 Factory Service Manual EXL-88 < DTC/CIRCUIT DIAGNOSIS >[XENON TYPE] HEADLAMP (LO) CIRCUIT HEADLAMP (LO) CIRCUIT Component Function CheckINFOID:0000000006213957 1.CHECK HEADLAMP (LO) OPERATION CONSULT-III ACTIVE TEST 1. Sel

Page 2799 of 5598

INFINITI QX56 2011 Factory Service Manual HEADLAMP (LO) CIRCUITEXL-89 < DTC/CIRCUIT DIAGNOSIS > [XENON TYPE] C D E F G H I J K M A B EXL N O P Is the inspection result normal? YES >> Replace IPDM E/R. NO >> GO TO 4. 4.CHECK HEADLAMP (LO) SHO

Page 2800 of 5598

INFINITI QX56 2011 Factory Service Manual EXL-90 < DTC/CIRCUIT DIAGNOSIS >[XENON TYPE] XENON HEADLAMP XENON HEADLAMP Diagnosis ProcedureINFOID:0000000006213959 1.CHECK XENON BULB Install the normal bulb to the applicable headlamp. Turn the l
