Page 449 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
BCM
BCS-61
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K L
B A
O P
N
JCMWM8294GB
Revision: 2010 May2011 QX56

Page 450 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-62
< WIRING DIAGRAM >
BCM
JCMWM8295GB
Revision: 2010 May2011 QX56

Page 451 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
BCM
BCS-63
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K L
B A
O P
N
JCMWM8296GB
Revision: 2010 May2011 QX56

Page 452 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-64
< WIRING DIAGRAM >
BCM
JCMWM8297GB
Revision: 2010 May2011 QX56

Page 453 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
BCM
BCS-65
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K L
B A
O P
N
JCMWM8298GB
Revision: 2010 May2011 QX56

Page 454 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-66
< WIRING DIAGRAM >
BCM
JCMWM8299GB
Revision: 2010 May2011 QX56

Page 455 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
INSPECTION AND ADJUSTMENTBCS-67
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
B A
O P
N
BASIC INSPECTION
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN RE
PLACING CONTROL UNIT (BCM)
ADDITIONAL SERVI

BCS
INSPECTION AND ADJUSTMENTBCS-67
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
B A
O P
N
BASIC INSPECTION
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN RE
PLACING CONTROL UNIT (BCM)
ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT (BCM) : Description
INFOID:0000000006324908
BEFORE REPLACEMENT
When replacing BCM, save or print current vehicle specification with CONSULT-III configuration before
replacement.
NOTE:
If “READ CONFIGURATION” can not be used, use the “WRITE CONFIGURATION - Manual selection” after
replacing BCM.
AFTER REPLACEMENT
CAUTION:
When replacing BCM, you must perform “W RITE CONFIGURATION” with CONSULT-III.
- Complete the procedure of “WRITE CONFIGURATION” in order.
- If you set incorrect “WRITE CONF IGURATION”, incidents might occur.
- Configuration is different for each vehicle model. Confirm conf iguration of each vehicle model.
When replacing BCM, perform the system initialization (NATS).
ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT (BCM) : Work Proce-
dure
INFOID:0000000006324909
1.SAVING VEHICLE SPECIFICATION
CONSULT-III Configuration
Perform “READ CONFIGURATION” to save or prin t current vehicle specification. Refer to BCS-67, "
CONFIG-
URATION (BCM) : Description".
NOTE:
If “READ CONFIGURATION” can not be used, use the “WRITE CONFIGURATION - Manual selection” after
replacing BCM.
>> GO TO 2.
2.REPLACE BCM
Replace BCM. Refer to BCS-81, "
Removal and Installation".
>> GO TO 3.
3.WRITING VEHICLE SPECIFICATION
CONSULT-III Configuration
Perform “WRITE CONFIGURATION - Config file” or “W RITE CONFIGURATION - Manual selection” to write
vehicle specification. Refer to BCS-68, "
CONFIGURATION (BCM) : Work Procedure".
>> GO TO 4.
4.INITIALIZE BCM (NATS)
Perform BCM initialization. (NATS)
>> WORK END
CONFIGURATION (BCM)
CONFIGURATION (BCM) : DescriptionINFOID:0000000006324910
Vehicle specification needs to be written with CONSULT- III because it is not written after replacing BCM.
Revision: 2010 May2011 QX56

Page 456 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-68
< BASIC INSPECTION >
INSPECTION AND ADJUSTMENT
Configuration has three functions as follows.
NOTE:
Manual setting item: Items which need selection by vehicle specifications
Automatic setting i

BCS-68
< BASIC INSPECTION >
INSPECTION AND ADJUSTMENT
Configuration has three functions as follows.
NOTE:
Manual setting item: Items which need selection by vehicle specifications
Automatic setting item: Items which are written in automatically (Setting can not be changed)
CAUTION:
When replacing BCM, you must perform “WRITE CONFIGURATION” with CONSULT-III.
Complete the procedure of “WRITE CONFIGURATION” in order.
If you set incorrect “WRITE CONF IGURATION”, incidents might occur.
Configuration is different for each vehicle mode l. Confirm configuration of each vehicle model.
Never perform “WRITE CONFIGURATION” except for new BCM.
CONFIGURATION (BCM) : Work ProcedureINFOID:0000000006324911
1.WRITING MODE SELECTION
CONSULT-III Configuration
Select “CONFIGURATION” of BCM.
When writing saved data>>GO TO 2.
When writing manually>>GO TO 3.
2.PERFORM “WRITE CONFIGURATION - CONFIG FILE”
CONSULT-III Configuration
Perform “WRITE CONFIGURATION - Config file”.
>> WORK END
3.PERFORM “WRITE CONFIGURATION - MANUAL SELECTION”
CONSULT-III Configuration
1. Select "WRITE CONFIGURA TION - Manual selection".
2. Identify the correct model and configuration list. Refer to BCS-69, "
CONFIGURATION (BCM) : Configura-
tion list".
3. Confirm and/or change setting value for each item. CAUTION:
Thoroughly read and understan d the vehicle specification. Incorrect settings may result in
abnormal control of ECU.
If items are not displayed, touch “SETTING”. Refer to BCS-69, "
CONFIGURATION (BCM) : Con-
figuration list" for written items and setting value.
4. Select "SETTING". CAUTION:
Make sure to select “SETTING” even if the indicat ed configuration of brand new BCM is same as
the desirable configuration. If not, configuratio n which is set automatically by selecting vehicle
model can not be memorized.
5. When "COMMAND FINISHED", select "END".
>> GO TO 4.
4.OPERATION CHECK
Confirm that each function controlled by BCM operates normally.
>> WORK END
Function Description
READ CONFIGURATION Reads the vehicle configuration of current BCM.
Saves the read vehicle configuration.
WRITE CONFIGURATION - Manual selection Writes the vehicle configuration with manual selection.
WRITE CONFIGURATION - Config file Writes the vehicle configuration with saved data.
Revision: 2010 May2011 QX56
