Page 2889 of 5598

INFINITI QX56 2011 Factory Service Manual EXT-34 < REMOVAL AND INSTALLATION > DOOR PARTING SEAL DOOR PARTING SEAL Exploded ViewINFOID:0000000006367619 Removal and InstallationINFOID:0000000006367620 REMOVAL 1. Fully open door. 2. Disengage t

Page 2890 of 5598

INFINITI QX56 2011 Factory Service Manual DOOR PARTING SEALEXT-35 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P  When installing, check visually th e clips, then replace them with new parts if they have been dam- aged.  Whe

Page 2891 of 5598

INFINITI QX56 2011 Factory Service Manual EXT-36 < REMOVAL AND INSTALLATION > SILL MOLDING SILL MOLDING Exploded ViewINFOID:0000000006367621 Removal and InstallationINFOID:0000000006367622 REMOVAL 1. Fully open front and rear door. 2. Diseng

Page 2892 of 5598

INFINITI QX56 2011 Factory Service Manual DOOR SASH COVEREXT-37 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P DOOR SASH COVER Exploded ViewINFOID:0000000006367623 Removal and InstallationINFOID:0000000006367624 FRONT DOOR SAS

Page 2893 of 5598

INFINITI QX56 2011 Factory Service Manual EXT-38 < REMOVAL AND INSTALLATION > DOOR SASH COVER 2. Insert a remover tool (A) between front door sash cover (1) anddoor panel, cut double-sided tape using a cutter (B) while lifting front door sas

Page 2894 of 5598

INFINITI QX56 2011 Factory Service Manual DOOR SASH COVEREXT-39 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P  When installing, slide and inst all rear door sash cover (2) from door front, so that rear door outside molding (

Page 2895 of 5598

INFINITI QX56 2011 Factory Service Manual EXT-40 < REMOVAL AND INSTALLATION > FRONT PILLAR FINISHER FRONT PILLAR FINISHER Exploded ViewINFOID:0000000006367625 Removal and InstallationINFOID:0000000006367626 REMOVAL 1. Remove roof drip moldi

Page 2896 of 5598

INFINITI QX56 2011 Factory Service Manual REAR SPOILEREXT-41 < REMOVAL AND INSTALLATION > C DE F G H I J L M A B EXT N O P REAR SPOILER Exploded ViewINFOID:0000000006367627 Removal and InstallationINFOID:0000000006367628 REMOVAL 1. Remove ba
