Page 577 of 4801

NISSAN TEANA 2014 Service Manual
DAS-144
< REMOVAL AND INSTALLATION >[LDW]
REAR VIEW CAMERA WA
SHER CONTROL UNIT
REAR VIEW CAMERA WASHER CONTROL UNIT
Exploded ViewINFOID:0000000009978537
Removal and InstallationINFOID:00000000099785

Page 578 of 4801

NISSAN TEANA 2014 Service Manual
DAS
REAR VIEW CAMERA AIR PUMP MOTORDAS-145
< REMOVAL AND INSTALLATION > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
REAR VIEW CAMERA AIR PUMP MOTOR
Exploded ViewINFOID:0000000009978539
Removal and Installa

Page 579 of 4801

NISSAN TEANA 2014 Service Manual
DAS-146
< PRECAUTION >[BSW]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951647
The Supplemental Re

DAS-146
< PRECAUTION >[BSW]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951647
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000009464801
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a s hop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Precautions For Harness RepairINFOID:0000000009464802
ITS communication uses a twisted pair line. Be careful when repairing it.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 580 of 4801

NISSAN TEANA 2014 Service Manual
DAS
PRECAUTIONSDAS-147
< PRECAUTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
• Solder the repaired area and wrap tape around the soldered area. NOTE:
A fray of twisted lines must be within 110 mm

Page 581 of 4801

NISSAN TEANA 2014 Service Manual
DAS-148
< PREPARATION >[BSW]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009464804
The actual shapes of the tools may
differ from those illustrated here.
Tool number
(Tech

Page 582 of 4801

NISSAN TEANA 2014 Service Manual
DAS
COMPONENT PARTSDAS-149
< SYSTEM DESCRIPTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000009464805
AWOIA0037ZZ
Revision: Novemb

Page 583 of 4801

NISSAN TEANA 2014 Service Manual
DAS-150
< SYSTEM DESCRIPTION >[BSW]
COMPONENT PARTS
Component Description
INFOID:0000000009464806
1. Combination meter 2. Vehicle information display 3. BCM (view with combination meter re- moved)
4.

DAS-150
< SYSTEM DESCRIPTION >[BSW]
COMPONENT PARTS
Component Description
INFOID:0000000009464806
1. Combination meter 2. Vehicle information display 3. BCM (view with combination meter re- moved)
4. Blind spot warning indicator RH 5. Blind spot warning indicator LH 6. TCM
7. ECM 8. Warning systems switch 9. Warning systems ON indicator
10. Rear view camera washer control unit 11. Rear view camera air pump motor 12. Rear view camera
13. AV control unit (center display) (with navi- gation system and bose audio system)
Audio unit (center display) (with display
audio system and bose audio system) 14. ITS control unit
(view with center console removed) 15. Steering angle sensor
(view with steeri ng wheel removed)
16. Washer fluid level switch (view with front fascia removed)
Component Description
ITS control unit • Being connected with rear view camera via ITS communication, receives vehicle detection signal
and transmits Blind Spot Warning indicator signal and Blind Spot Warning indicator dimmer sig-
nal to the rear view camera
• Being connected with lane camera unit via ITS communication, receives detected lane condition
signal
• Receives steering angle sensor signal from steering angle sensor via CAN communication
• Judges a Blind Spot Warning indicator ON/OFF state and an approach state to the lane marker,
based on each signal.
• Activates the warning buzzer and warning systems ON indicator
• Transmits Blind Spot Warning ON indicator signal to combination meter via CAN communication
Blind Spot Warning indicator LH/
RH Receives Blind Spot Warning indicator operation signal from rear view camera and turns OFF, turns
ON or blinks
Warning systems switch Inputs the switch signal to ITS control unit
Warning systems ON indicator
(On the warning systems switch) Indicates BSW system status
Rear view camera • Detects the lane marker by the built-in camera
• Transmits detected lane condition signal to ITS control unit
ABS actuator and electric unit
(control unit) • Transmits vehicle speed signal to ITS control unit via CAN communication
• Transmits yaw rate signal/side G sensor signal to ITS control unit via CAN communication
Buzzer (combination meter) Receives buzzer signal from ITS control unit and sounds buzzer.
Combination meter • Turns the Blind Spot Warning indicator ON/OFF according to the signals from the ITS control unit
via CAN communication
• Receives Blind Spot Warning ON indicator signal via CAN communication.
Steering angle sensor Transmits steering angle sensor signal to ITS control unit via CAN communication
BCM • Transmits turn signal indicator to ITS control unit via CAN communication
• Transmits dimmer signal to ITS control unit via CAN communication
ECM Transmits engine speed signal to ITS control unit via CAN communication
TCM Transmits the output shaft speed signal, input speed signal, current gear position signal and shift
position signal to ITS control unit via CAN communication
AV c o n t r o l u n i t
(with navigation system and bose
audio system) Receives the various systems and camera signals via CAN communication and routes them to the
center display
Audio unit
(with display audio system and
bose audio system) Receives the various systems and camera signals and routes them to the center display
Center display Displays the various system screen signals according to the priority level received via CAN com-
munication
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 584 of 4801

NISSAN TEANA 2014 Service Manual
DAS
COMPONENT PARTSDAS-151
< SYSTEM DESCRIPTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
Rear view camera washer control
unit Controls the air pump to drive air to the rear camera lens according to
