2014 NISSAN TEANA OBD port

EC-1
ENGINE
C
D E
F
G H
I
J
K L
M
SECTION EC
A
EC
N
O P
CONTENTS
ENGINE CONTROL SYSTEM
QR25DE
PRECAUTION ................ ..............................
15
PRECAUTIONS .............................................. ....15
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ....
15
Precaution for Procedure without Cowl Top Cover ....15
On Board Diagnostic (OBD) System of Engine
and CVT .............................................................. ....
15
General Precautions ...............................................16
PREPARATION ...........................................19
PREPARATION .............................................. ....19
Special Service Tools .......................................... ....19
Commercial Service Tools ......................................19
SYSTEM DESCRIPTION .............................21
COMPONENT PARTS ................................... ....21
Component Parts Location ................................ ....21
ECM ........................................................................25
Accelerator Pedal Position Sensor ...................... ....25
Electric Throttle Control Actuator ........................ ....25
Ignition Coil With Power Transistor .........................26
Fuel Injector ........................................................ ....26
Fuel Level Sensor Unit and Fuel Pump .............. ....26
Fuel Tank Temperature Sensor .......................... ....27
Mass Air Flow Sensor (With Intake Air Tempera-
ture Sensor) ........................................................ ....
27
Manifold Absolute Pressure Sensor ........................28
Engine Coolant Temperature Sensor .................. ....28
Crankshaft Position Sensor (POS) ..........................29
Camshaft Position Sens or (PHASE) .......................29
Intake Valve Timing Cont rol Solenoid Valve ...........30
Intake Valve Timing Intermediate Lock Control
Solenoid Valve .................................................... ....
30
Exhaust Valve Timing Control Position Sensor .......30
Exhaust Valve Timing Control Solenoid Valve ........31
Intake Manifold Runner Control Valve ................. ....31
Intake Manifold Tuning Valve ..................................31
Air Fuel Ratio (A/F) Sensor 1 ..................................32
Heated Oxygen Sensor 2 ........................................32
Knock Sensor ..........................................................33
Engine Oil Pressure Sensor ....................................33
Engine Oil Temperature Sensor .......................... ....33
Cooling Fan .............................................................34
EVAP Canister .........................................................34
EVAP Canister Purge Volu me Control Solenoid
Valve .................................................................... ....
34
EVAP Canister Vent Control Valve ..........................35
EVAP Control System Pres sure Sensor ..................35
Battery Current Sensor (With Battery Tempera-
ture Sensor) ......................................................... ....
35
Malfunction Indicator lamp (MIL) .............................36
Oil Pressure Warning Lamp ....................................36
Refrigerant Pressure Sensor ............................... ....36
Stop Lamp Switch & Brake Pedal Position Switch ....36
ASCD Steering Switch .............................................37
Information Display ..................................................37
STRUCTURE AND OPERATION .....................38
Positive Crankcase Ventilation ................................38
On Board Refueling Vapor Recovery (ORVR) ........39
SYSTEM ............................................................40
ENGINE CONTROL SYSTEM ........................ ...........40
ENGINE CONTROL SYSTEM : System Descrip-
tion ....................................................................... ....
40
ENGINE CONTROL SYSTEM : Fail Safe ..............41
MULTIPORT FUEL INJECTION SYSTEM ................43
MULTIPORT FUEL INJECTION SYSTEM : Sys-
tem Description (with auto matic air conditioner) ......
43
MULTIPORT FUEL INJECTION SYSTEM : Sys-
tem Description (with manual air conditioner) .........
46
ELECTRIC IGNITION SYSTEM .................................48
ELECTRIC IGNITION SYSTEM : System De-
scription ............................................................... ....
48
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-8
POSITIVE CRANKCASE VENTILATION ........539
Inspection ............................................................ ..539
REMOVAL AND INSTALLATION ..............540
ECM ................................................................ .540
Removal and Installation ..................................... ..540
SERVICE DATA AND SPECIFICATIONS
(SDS) .............. ............................................
541
SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................... .
541
Idle Speed ........................................................... ..541
Ignition Timing .......................................................541
Calculated Load Value ..........................................541
Mass Air Flow Sensor ............................................541
VQ35DE
PRECAUTION .............. ..............................
542
PRECAUTIONS .............................................. .542
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. ..
542
On Board Diagnostic (OBD) System of Engine
and CVT .............................................................. ..
542
General Precautions ..............................................543
PREPARATION ..........................................546
PREPARATION .............................................. .546
Special Service Tools .......................................... ..546
Commercial Service Tools .....................................546
SYSTEM DESCRIPTION ...........................548
COMPONENT PARTS .................................... .548
ENGINE CONTROL SYSTEM .................................548
ENGINE CONTROL SYSTEM : Component Parts
Location ............................................................... ..
548
Accelerator Pedal Position Sensor ........................552
Air Fuel Ratio (A/F) Sensor 1 ................................552
ASCD Steering Switch ...........................................553
Battery Current Sensor (With Battery Tempera-
ture Sensor) ......................................................... ..
553
Camshaft Position Sensor (PHASE) .....................554
Cooling Fan ......................................................... ..554
Crankshaft Position Sensor (POS) ........................554
ECM .......................................................................555
Electric Throttle Control Actuator ......................... ..555
Electronic Controlled Engine Mount .................... ..556
Engine Coolant Temperature Sensor ....................556
Engine Oil Pressure Sensor ................................ ..557
Engine Oil Temperature Sensor ............................557
EVAP Canister ..................................... ..................557
EVAP Canister Purge Volu me Control Solenoid
Valve .................................................................... ..
557
EVAP Canister Vent Control Valve ........................558
EVAP Control System Pressu re Sensor ................558
Fuel Injector ......................................................... .558
Fuel Level Sensor Unit and Fuel Pump (With Fuel
Tank Temperature Sensor) .................................. .
558
Heated Oxygen Sensor 2 ......................................559
Ignition Coil (With Power Transistor) ....................560
Intake Valve Timing Control Solenoid Valve .........560
Knock Sensor ....................................................... .560
Malfunction Indicator lamp (MIL) ...........................560
Mass Air Flow Sensor (With Intake Air Tempera-
ture Sensor) ......................................................... .
560
Oil Pressure Warning Lamp ..................................561
Power Valve Actuator 1 and 2 ..............................561
Refrigerant Pressure Sensor ................................562
Stop Lamp Switch & Brak e Pedal Position Switch .562
VIAS Control Solenoid Valve 1 and 2 .................. .562
STRUCTURE AND OPERATION .....................563
Positive Crankcase Ventilation (PCV) ...................563
On Board Refueling Vapor Recovery (ORVR) ..... .564
SYSTEM ...........................................................565
ENGINE CONTROL SYSTEM ................................ .565
ENGINE CONTROL SYSTEM : System Descrip-
tion ....................................................................... .
565
ENGINE CONTROL SYSTEM : Fail-safe .............566
MULTIPORT FUEL INJECTION SYSTEM ............. .568
MULTIPORT FUEL INJECTION SYSTEM : Sys-
tem Description .................................................... .
568
ELECTRIC IGNITION SYSTEM ............................. .571
ELECTRIC IGNITION SYSTEM : System De-
scription ................................................................ .
571
AIR CONDITIONING CUT CONTROL ................... .572
AIR CONDITIONING CUT CONTROL : System
Description ........................................................... .
573
AUTOMATIC SPEED CONTROL DEVICE (ASCD) .574
AUTOMATIC SPEED CONTROL DEVICE (AS-
CD) : System Description ..................................... .
574
COOLING FAN CONTROL .................................... .575
COOLING FAN CONTROL : System Description .575
ELECTRONIC CONTROLLED ENGINE MOUNT .. .577
ELECTRONIC CONTROLLED ENGINE MOUNT
: System Description ............................................ .
577
EVAPORATIVE EMISSION SYSTEM .....................579
EVAPORATIVE EMISSION SYSTEM : System
Description ........................................................... .
580
THROTTLE CONTROL ...........................................581
THROTTLE CONTROL : Syst em Description ......581
INTAKE VALVE TIMING CONTROL ..................... .582
INTAKE VALVE TIMING CONTROL : System De-
scription ................................................................ .
583
ENGINE PROTECTION CONTROL AT LOW EN-
GINE OIL PRESSURE ........................................... .
583
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PREPARATIONEC-19
< PREPARATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000009462051
The actual shape of the tools may di
ffer from those illustrated here.
Commercial Service ToolsINFOID:0000000009462052
Tool number
(TechMate No.)
Tool name Description
(J-44321)
Fuel pressure gauge
kit Checks fuel pressure
KV10120000
Fuel tube adapter Measures fuel pressure
LEC642
JSBIA0410ZZ
Tool name
(TechMate No.) Description
Leak detector
i.e.: (J-41416) Locates the EVAP leak
EVAP service port
adapter
i.e.: (J-41413-OBD) Applies positive pressure through EVAP service
port
Fuel filler cap adapter
i.e.: (MLR-8382) Checks fuel tank vacuum relief valve opening
pressure
S-NT703
S-NT704
S-NT815
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EVAP LEAK CHECKEC-537
< PERIODIC MAINTENANCE > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
EVAP LEAK CHECK
InspectionINFOID:0000000009462466
CAUTION:
• Do not use compressed air or a high pressure pump.
• Do not exceed 4.12 kPa (0.042 kg/cm
2, 0.6 psi) of pressure in EVAP system.
NOTE:
• Do not start engine.
• Improper installation of EVAP service port adapter [commercial service tool: (J-41413-OBD)] to the EVAP
service port may cause a leak.
1.EVAP LEAK CHECK
With CONSULT
1. Install EVAP service port adapter [commercial service tool: (J- 41413-OBD)] and pressure pump to EVAP service port.
2. Turn ignition switch ON.
3. Select the “EVAP SYSTEM CLOSE” in “WOR K SUPPORT” mode of “ENGINE” using CONSULT.
4. Touch “START”. A bar graph (Pressure indicating display) will appear on the screen.
5. Apply positive pressure to the EVAP system until t he pressure indicator reaches the middle of the bar
graph.
6. Remove EVAP service port adapter [commercial service tool: (J-41413-OBD)] and hose with pressure
pump.
7. Locate the leak using a leak detector [commercial service tool: (J-41416)]. Refer to EC-62, "EVAPORATIVE EMISSION SYS-
TEM : System Description".
Without CONSULT
1. Install EVAP service port adapter [commercial service tool: (J- 41413-OBD)] and pressure pump to EVAP service port.
SEF462UA
SEF200U
SEF462UA
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-538
< PERIODIC MAINTENANCE >[QR25DE]
EVAP LEAK CHECK
2. Apply battery voltage between the terminals of EVAP
canister vent control valve to make a closed EVAP
system.
3. To locate the leak, deliver positive pressure to the EVAP system until pressure gauge points reach 1.38 to
2.76 kPa (0.014 to 0.028 kg/cm
2, 0.2 to 0.4 psi).
4. Remove EVAP service port adapter [commercial service tool: (J-41413-OBD)] and hose with pressure
pump.
5. Locate the leak using a leak detector [commercial service tool: (J-41416)]. Refer to EC-62, "EVAPORATIVE EMISSION SYS-
TEM : System Description".
>> INSPECTION END
SEF200U
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-546
< PREPARATION >[VQ35DE]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000009462478
The actual shape of the tools may differ from those illustrated here.
Commercial Service ToolsINFOID:0000000009462479
Tool number
(TechMate No.)
Tool name Description
(J-44321)
Fuel pressure gauge
kit Checks fuel pressure
(J-44321-6)
Fuel pressure adapter Connects fuel pressure gauge to quick connector
type fuel lines
LEC642
LBIA0376E
Tool name
(TechMate No.) Description
(J-45488)
Quick connector re-
lease Removes fuel tube quick connectors in engine
room
Leak detector
i.e.: (J-41416) Locates the EVAP leakage
EVAP service port
adapter
i.e.: (J-41413-OBD) Applys positive pressure through EVAP service
port
PBIC0198E
S-NT703
S-NT704
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN
TROUBLE DIAGNOSISLAN-15
< SYSTEM DESCRIPTION > [CAN FUNDAMENTAL]
C
D E
F
G H
I
J
K L
B
A
O P
N
• Response to the system call
• Control unit diagnosis information
• Self-diagnosis
• CAN diagnostic support monitor
Self-DiagnosisINFOID:0000000009461399
If communication signals cannot be transmitted or rece ived among control units communicating via CAN com-
munication line, CAN communication-related DTC is displayed on the CONSULT “Self Diagnostic Result”
screen.
NOTE:
The following table shows examples of CAN communicati on-related DTC. For other DTC, refer to the applica-
ble sections.
CAN Diagnostic Support MonitorINFOID:0000000009461400
MONITOR ITEM (CONSULT)
Example: CAN DIAG SUPPORT MNTR indication
Without PAST
DTC Self-diagnosis item
(CONSULT indication) DTC detection condition Inspection/Action
U1000 CAN COMM CIRCUIT ECM
When ECM is not transmitting or receiving CAN
communication signal of OBD (emission-relat-
ed diagnosis) for 2 seconds or more.
Start the inspection. Re-
fer to the applicable sec-
tion of the indicated
control unit.
Except
for ECM When a control unit (except for ECM) is not
transmitting or receiving CAN communication
signal for 2 seconds or more.
U1001 CAN COMM CIRCUIT When ECM is not transmitting or receiving CAN communi-
cation signal other than OBD (emission-related diagnosis)
for 2 seconds or more.
U1002 SYSTEM COMM When a control unit is not transmitting or receiving CAN
communication signal for 2 seconds or less.
U1010 CONTROL UNIT(CAN) When an error is detected during the initial diagnosis for
CAN controller of each control unit. Replace the control unit
indicating “U1010”.
JSMIA0964GB
Item PRESENT Description
Initial diagnosis OK Normal at present
NG Control unit e rror (Except for some control units)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
