2014 NISSAN TEANA Service Manual

air condition lane assist wiper size seat memory remote start 4WD

Page 1873 of 4801

NISSAN TEANA 2014 Service Manual
P050A, P050E COLD START CONTROLEC-873
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P050A, P050E COLD START CONTROL
DescriptionINFOID:0000000009462723
ECM controls ignition timi

P050A, P050E COLD START CONTROLEC-873
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P050A, P050E COLD START CONTROL
DescriptionINFOID:0000000009462723
ECM controls ignition timing and engine idle speed when engine is started with pre-warming up condition.
This control promotes the activation of three way ca talyst by heating the catalyst and reduces emissions.
DTC LogicINFOID:0000000009462724
DTC DETECTION LOGIC
NOTE:
If DTC P050A, P050E is displayed with other DTC, first perform the trouble diagnosis for other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 11 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
With CONSULT
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Select “DATA MONITOR” mode with CONSULT.
4. Check the indication of “COOLAN TEMP/S”.
With GST
Follow the procedure “With CONSULT” above.
Is the value of
“COOLAN TEMP/S” between 4°C (39°F) and 36°C (97°F)?
YES >> GO TO 3.
NO-1 [If it is below 4 °C (39 °F)]>>Warm up the engine until the value of “COOLAN TEMP/S” reaches 4 °C
(39 °F) or more. Retry from step 1.
NO-2 [If it is above 36 °C (97 °F)]>>Cool engine down to less than 36 °C (97 °F). Retry from step 1.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
With CONSULT
1. Set the select lever in N range.
2. Start the engine and warm up in idle with the value of “COOLAN TEMP/S” between 4°C (39 °F) and 40 °C
(104 °F) for more than 15 seconds.
3. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-874, "Diagnosis Procedure".
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P050A Cold start idle air control system
performance ECM does not control engine idle speed properly
when engine is started with pre-warming up con-
dition. • Lack of intake air volume
• Fuel injection system
•ECM
P050E Cold start engine exhaust temper-
ature too low The temperature of the catalyst inlet does not
rise to the proper temperature when the engine
is started with pre-warming up condition.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1874 of 4801

NISSAN TEANA 2014 Service Manual
EC-874
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P050A, P050E COLD START CONTROL
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462725
1.PERFORM IDLE AIR VOLUME LEARNING
Perform EC-683, "Work Proc

Page 1875 of 4801

NISSAN TEANA 2014 Service Manual
P0520 EOP SENSOREC-875
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0520 EOP SENSOR
DTC LogicINFOID:0000000009462726
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDI

Page 1876 of 4801

NISSAN TEANA 2014 Service Manual
EC-876
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0520 EOP SENSOR
2.CHECK EOP SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connectors.
3. Check the continuity between EOP se

Page 1877 of 4801

NISSAN TEANA 2014 Service Manual
P0520 EOP SENSOREC-877
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EOP sens

Page 1878 of 4801

NISSAN TEANA 2014 Service Manual
EC-878
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0524 ENGINE OIL PRESSURE
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000009462729
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
If “ EC-879,

EC-878
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0524 ENGINE OIL PRESSURE
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000009462729
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
If “ EC-879, "Diagnosis Procedure"
” is unfinished, be sure to perform Step 3 and 4.
1.PRECONDITIONING-1
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TEST CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PRECONDITIONING-2
Is
“Diagnosis Procedure” of DTC P0524 finished?
YES >> GO TO 3.
NO >> GO TO 4.
3.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Maintain the following conditions for about 10 consecutive seconds.
NOTE:
With engine speed set around 4,000 rpm, the phenomenon can be reproduced more easily.
3. Check DTC.
Is DTC detected?
YES >> Proceed to EC-879, "Diagnosis Procedure".
NO >> INSPECTION END
4.CHECK ENGINE OIL LEVEL
Check engine oil level. Refer to LU-25, "Inspection"
.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Proceed to EC-879, "Diagnosis Procedure"
.
5.CHECK ENGINE OIL PRESSURE
With CONSULT
DTC No. Trouble diagnosis
(Trouble diagnosis content) DTC detecting condition Possible cause
P0524 ENGINE OIL PRESSURE
(Engine oil pressure too low) An EOP sensor signal voltage applied to
ECM remains lower than the specified value
continuously for 10 seconds or more when
the engine speed is 1,000 rpm or more. • Decrease in engine oil pressure
• Decrease in engine oil level
• Engine oil condition
•EOP sensor
• Engine body
Selector lever P or N position
Engine coolant temperature 70 °C (158 °F) or more
Engine speed 1,000 rpm or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1879 of 4801

NISSAN TEANA 2014 Service Manual
P0524 ENGINE OIL PRESSUREEC-879
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
3. S

P0524 ENGINE OIL PRESSUREEC-879
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
3. Start the engine and check that “EOP SENSOR” changes, according to engine speeds.
Without CONSULT
Check engine oil pressure. Refer to LU-25, "Inspection"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Proceed to EC-879, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009462730
1.CHECK ENGINE OIL LEVEL
1. Turn ignition switch OFF.
2. Check engine oil level. Refer to LU-25, "Inspection"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK ENGINE OIL PRESSURE
With CONSULT
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
3. Start the engine and check that “EOP SENSOR” changes, according to engine speeds.
Without CONSULT
Check engine oil level. Refer to LU-25, "Inspection"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check oil pump. Refer to LU-29, "Removal and Installation"
.
3.CHECK EOP SENSOR
Check EOP sensor. Refer to EC-880, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace error-detected parts.
4.CHECK ENGINE OIL LEAKAGE
Check engine oil leakage. Refer to LU-23, "Lubrication Circuit"
.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
Monitor item Condition Va l u e
(Approx.)
EOP SENSOR • Engine oil temperature: 80
°C (176 °F)
• Selector lever: P or N position
• Air conditioner switch: OFF
•No load Engine speed:
Idle 1,450 mV or more
Engine speed:
2,000 rpm 2,850 mV or more
Monitor item Condition Va l u e
(Approx.)
EOP SENSOR • Engine oil temperature: 80
°C (176 °F)
• Selector lever: P or N position
• Air conditioner switch: OFF
•No load Engine speed:
Idle 1,450 mV or more
Engine speed:
2,000 rpm 2,850 mV or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1880 of 4801

NISSAN TEANA 2014 Service Manual
EC-880
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0524 ENGINE OIL PRESSURE
5.CHECK CAUSE OF ENGINE OIL CONSUMPTION
Check the following item.
>> Repair or replace error-detected parts.
Component InspectionINF
