Page 1033 of 4801

NISSAN TEANA 2014 Service Manual
COMPONENT PARTSEC-33
< SYSTEM DESCRIPTION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Knock SensorINFOID:0000000009462074
The knock sensor is attached to t
he cylinder block. It senses engine
knockin

Page 1034 of 4801

NISSAN TEANA 2014 Service Manual
EC-34
< SYSTEM DESCRIPTION >[QR25DE]
COMPONENT PARTS
<Reference data>
*: These data are reference values and are measured between ECM terminals.
Cooling FanINFOID:0000000009462077
The ECM controls th

Page 1035 of 4801

NISSAN TEANA 2014 Service Manual
COMPONENT PARTSEC-35
< SYSTEM DESCRIPTION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
EVAP Canister Vent Control ValveINFOID:0000000009462080
The EVAP canister vent control valve is located on the EV

COMPONENT PARTSEC-35
< SYSTEM DESCRIPTION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
EVAP Canister Vent Control ValveINFOID:0000000009462080
The EVAP canister vent control valve is located on the EVAP canis-
ter and is used to seal the canister vent.
This solenoid valve responds to signals from the ECM. When the
ECM sends an ON signal, the coil in the solenoid valve is energized.
A plunger will then move to seal the canister vent. The ability to seal
the vent is necessary for the on board diagnosis of other evaporative
emission control system components.
This solenoid valve is used only for diagnosis, and usually remains
opened.
When the vent is closed, under normal purge conditions, the evapo-
rative emission control system is depressurized and allows “EVAP
Control System” diagnosis.
EVAP Control System Pressure SensorINFOID:0000000009462081
The EVAP control system pressure sensor detects pressure in the
purge line. The sensor output voltage to the ECM increases as pres-
sure increases.
Battery Current Sensor (With Battery Temperature Sensor)INFOID:0000000009462082
OUTLINE
The power generation voltage variable control enables fuel con-
sumption to be decreased by reducing the engine load which is
caused by the power generation of the generator.
Based on sensor signals, ECM judges whether or not the power
generation voltage variable contro l is performed. When performing
the power generation voltage variable control, ECM calculates the
target power generation voltage based on the sensor signal. And
ECM sends the calculated value as the power generation command
value to IPDM E/R. For the details of the power generation voltage
variable control, refer to CHG-10, "System Description"
.
CAUTION:
Never connect the electrical co mponent or the ground wire
directly to the battery terminal. The connection cau ses the malfunction of the power generation volt-
age variable control, and then the battery discharge may occur.
BATTERY CURRENT SENSOR
The battery current sensor is installed to the battery negative cable. The sensor measures the charging/dis-
charging current of the battery.
BATTERY TEMPERATURE SENSOR
PBIB1263E
PBIB3370E
JPBIA3262ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1036 of 4801

NISSAN TEANA 2014 Service Manual
EC-36
< SYSTEM DESCRIPTION >[QR25DE]
COMPONENT PARTS
Battery temperature sensor is int
egrated in battery current sensor.
The sensor measures temperature around the battery.
The electrical resistanc

EC-36
< SYSTEM DESCRIPTION >[QR25DE]
COMPONENT PARTS
Battery temperature sensor is int
egrated in battery current sensor.
The sensor measures temperature around the battery.
The electrical resistance of the t hermistor decreases as temperature
increases.

*: These data are reference values and are measured between battery temperature
sensor signal terminal and sensor ground.
Malfunction Indicator lamp (MIL)INFOID:0000000009462083
The Malfunction Indicator lamp (MIL) is located on the combination
meter.
The MIL will illuminate when the ignition switch is turned ON without
the engine running. This is a bulb check.
When the engine is started, the MI L should turn OFF. If the MIL
remains illuminated, the on board diagnostic system has detected an
engine system malfunction.
For details, refer to EC-74, "DIAGNOSIS DESCRIPTION : Malfunc-
tion Indicator Lamp (MIL)".
Oil Pressure Warning LampINFOID:0000000009462084
Oil pressure warning lamp is located on the combination meter.
It indicates the low pressure of the engine oil and the malfunction of
the engine oil pressure system.
Combination meter turns the oil pressure warning lamp ON/OFF
according to the oil pressure warning lamp signal received from
ECM via CAN communication.
For details, refer to EC-55, "ENGINE PROTECTION CONTROL AT
LOW ENGINE OIL PRESSURE : System Description".
Refrigerant Pressure SensorINFOID:0000000009462085
The refrigerant pressure sensor is installed at the c ondenser of the air conditioner system. The sensor uses an
electrostatic volume pressure transducer to convert refrigerant pressure to voltage. The voltage signal is sent
to ECM, and ECM controls cooling fan system.
Stop Lamp Switch & Brake Pedal Position SwitchINFOID:0000000009462086
Stop lamp switch and brake pedal position switch are installed to brake pedal bracket.
ECM detects the state of the brake pedal by those two types of input (ON/OFF signal).
Temperature [°C ( °F)]
Vo l ta g e* (V) Resistance (k
Ω)
25 (77) 3.333 1.9 - 2.1
90 (194) 0.969 0.222 - 0.258
SEF012P
JSBIA1315ZZ
PBIA8559J
PBIB2657E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1037 of 4801

NISSAN TEANA 2014 Service Manual
COMPONENT PARTSEC-37
< SYSTEM DESCRIPTION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ASCD Steering SwitchINFOID:0000000009462087
ASCD steering switch has variant values of electrical
resistance for

Page 1038 of 4801

NISSAN TEANA 2014 Service Manual
EC-38
< SYSTEM DESCRIPTION >[QR25DE]
STRUCTURE AND OPERATION
STRUCTURE AND OPERATION
Positive Crankcase VentilationINFOID:0000000009462089
This system returns blow-by gas to the intake manifold.
The

Page 1039 of 4801

NISSAN TEANA 2014 Service Manual
STRUCTURE AND OPERATIONEC-39
< SYSTEM DESCRIPTION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
On Board Refueling Vapor Recovery (ORVR)INFOID:0000000009462090
From the beginning of refueling, the air

Page 1040 of 4801

NISSAN TEANA 2014 Service Manual
EC-40
< SYSTEM DESCRIPTION >[QR25DE]
SYSTEM
SYSTEM
ENGINE CONTROL SYSTEM
ENGINE CONTROL SYSTEM : System DescriptionINFOID:0000000009462091
SYSTEM DIAGRAM
SYSTEM DESCRIPTION
JPBIA5968GB
Revision: Nov
