Connecting Rod Bearing (Big End)
1. Install the connecting rod bearing to the connecting rod and cap.

CYLINDER BLOCKEM-243
< UNIT DISASSEMBLY AND ASSEMBLY > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Connecting Rod Bearing (Big End)
1. Install the connecting rod bearing to the connecting rod and cap.
2. Install the connecting rod cap to the connecti ng rod. Tighten to specification. Refer to EM-224, "Disassem-
bly and Assembly".
3. Measure the inner diameter (C) of each connecting rod (big end) as shown.
4. Measure the outer diameter (Dp) of each crankshaft pin journal.
5. Calculate the connecting rod bearing clearance. Connecting rod bearing clearance = (C) - (Dp)
6. If the calculated clearance exceeds the specified limit, replace the bearings.
7. If the clearance cannot be adjusted within the standard of any bearing, grind the crankshaft journal and use undersized bear-
ings.
8. If the crankshaft is replaced with a new one, select the connect-
ing rod bearings according to the following table:
Connecting Rod Bearing Grad e Number (Identification
Color)
These numbers are punched in eit her Arabic or Roman numer-
als.
Method B (Using Plastigage)
• Remove oil and dust on the crankshaft pin and the surfaces of each bearing completely.
• Cut a Plastigage slightly shorter than the bearing width, and place it in crankshaft axial direction, avoiding oil holes.
• Install the connecting rod bearings to the connecting rod cap, and tighten the connecting rod nuts to the specified torque.
CAUTION:
Do not rotate the crankshaft.
• Remove the connecting rod cap and bearings, and using the scale on the Plastigage bag, measure the Plastigage width.
NOTE:
The procedure when the measured value exceeds the repair limit
is same as that described in "Method A (Using Bore Gauge and Micrometer)".
DRIVE PLATE RUNOUT
AEM027
Standard : 0.020 - 0.045 mm (0.0008 - 0.0018 in)
Limit : 0.070 mm (0.0028 in)
AEM034
Crankshaft pin journal grade number Connecting rod bearing grade
number
0 0 (black)
1 1 (brown)
2 2 (green)
SEM452G
SEM142
Revision: November 20132014 Altima NAM
