2014 NISSAN TEANA Service Manual

towing capacity climate control jack points warning change wheel run flat

Page 2041 of 4801

NISSAN TEANA 2014 Service Manual
FUEL INJECTOR AND FUEL TUBEEM-43
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O• Handle O-rings with bare hands only. Do not wear gloves.
• Do not clean O-rings with solv

FUEL INJECTOR AND FUEL TUBEEM-43
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O• Handle O-rings with bare hands only. Do not wear gloves.
• Do not clean O-rings with solvent.
• Make sure that O-ring and its mating part are free of foreign material.
• Be careful not to scratch O- rings during installation.
• Do not twist or stretch the O-ring. If the O-ring was stretched while it is attached, do not insert it
into the fuel tube immediately.
2. Install the fuel injector (5) into the fuel tube (1) with the following procedure:
(2): O-ring (black)
(4): O-ring (green)
a. Insert the new clip (3) into the clip mounting groove (F) on fuel injector (5).
• Insert the clip (3) so that prot rusion (E) of fuel injector (5)
matches cutout (C) of the clip (3).
CAUTION:
• Do not reuse clip (3), replace it with a new one.
• Be careful to keep clip from interfering with O-ring. If
interference occurs, replace O-ring.
b. Insert fuel injector (5) into fuel tube (1) with clip (3) attached. • Insert fuel injector (5) so that protrusion (A) of fuel tube (1)
matches cut-out (B) of the clip (3).
• Check that fuel tube flange (G) is securely fixed in flange
groove (D) on the clip (3).
c. Check that installation is comple te by checking that fuel injector
(5) does not rotate or come off.
3. Install fuel tube and fuel injector assembly with the following procedure.
a. Insert the tip of each fuel injector into intake manifold.
b. Tighten the bolts to specification in the numerical order as shown.
CAUTION:
After properly connecting fu el tube assembly to injector
and fuel hose, check co nnection for fuel leaks.
4. Connect the fuel hose quick connector.
a. Make sure no foreign substances are deposited in and around the fuel tube and quick connector, and there is no damage to them.
b. Thinly apply new engine oil around the fuel tube tip end. Fuel tube side : Black
Nozzle side : Green
AWBIA1262GB
AWBIA1261GB
Revision: November 20132014 Altima NAM

Page 2042 of 4801

NISSAN TEANA 2014 Service Manual
EM-44
< REMOVAL AND INSTALLATION >[QR25DE]
FUEL INJECTOR AND FUEL TUBE
c. Align center to insert quick connector straight onto fuel tube.
d. Insert fuel tube into quick connector (1) until the top s

EM-44
< REMOVAL AND INSTALLATION >[QR25DE]
FUEL INJECTOR AND FUEL TUBE
c. Align center to insert quick connector straight onto fuel tube.
d. Insert fuel tube into quick connector (1) until the top spool (B) on fuel tubes is inserted completely and the second level spool (C)
is positioned slightly below the quick connector bottom end.
CAUTION:
• Hold at position (A) as show n, when inserting the fuel
tube into the quick connector.
• Carefully align to center to avoid inclined insertion to pre-
vent damage to the O-ring inside the quick connector.
• Insert the fuel tube until you hear a “click” sound and
actually feel the engagement.
• To avoid misidentification of engagement with a similar
sound, be sure to perform the next step.
• Do not reuse O-ring.
e. Before clamping the fuel hose with the hose clamp, pull the quick connector hard by hand, holding at the
(A) position, as shown. Make sure it is completely engaged (connected) so that it does not come off of the
fuel tube.
NOTE:
Recommended pulling force is 50 N (5.1 kg, 11.2 lb).
f. Install quick connector cap (1) over fuel hose side (B) and fuel tube side (A).
NOTE:
Direct arrow mark on quick connector cap (1) to fuel hose side.
5. Installation of the remaining components is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
Make sure there are no fuel leaks at connections as follows:
1. Apply fuel pressure to fuel lines by turning ignition switch ON (with engine stopped). Then check for fuel leaks at connections.
2. Start the engine and rev it up and check for fuel leaks at connections. • Perform procedures for “Throttle Valve Closed Posi tion Learning” after finishing repairs. Refer to EC-
178, "Work Procedure".
• If electric throttle control actuator is replaced, perform procedures for “Idle Air Volume Learning” after
finishing repairs. Refer to EC-179, "Work Procedure"
.
WARNING:
Do not touch engine immediately after stopping as engine is extremely hot.
NOTE:
Use mirrors for checking on connections out of the direct line of sight.
ALBIA0896GB
ALBIA0890GB
Revision: November 20132014 Altima NAM

Page 2043 of 4801

NISSAN TEANA 2014 Service Manual
ROCKER COVEREM-45
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
ROCKER COVER
Exploded ViewINFOID:0000000009460490
Removal and InstallationINFOID:0000000009460491
REMOVAL
1. D

Page 2044 of 4801

NISSAN TEANA 2014 Service Manual
EM-46
< REMOVAL AND INSTALLATION >[QR25DE]
ROCKER COVER
1. Apply liquid gasket to the position shown (A) with the following
procedure:
a. Apply liquid gasket to joint part of No.1 camshaft bracket (1

Page 2045 of 4801

NISSAN TEANA 2014 Service Manual
CAMSHAFTEM-47
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
CAMSHAFT
Exploded ViewINFOID:0000000009460492
Removal and InstallationINFOID:0000000009460493
REMOVAL
1. Remove th

Page 2046 of 4801

NISSAN TEANA 2014 Service Manual
EM-48
< REMOVAL AND INSTALLATION >[QR25DE]
CAMSHAFT
7. Loosen the valve timing control cover bolts in the reverse order
shown.
a. Remove the valve timing control cover bolts.
8. Remove the valve tim

Page 2047 of 4801

NISSAN TEANA 2014 Service Manual
CAMSHAFTEM-49
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
c. At the same time, make sure that the mating marks (outer
groove) (B) on camshaft sprockets are lined up with th

Page 2048 of 4801

NISSAN TEANA 2014 Service Manual
EM-50
< REMOVAL AND INSTALLATION >[QR25DE]
CAMSHAFT
12. Loosen the camshaft bracket bolts in the order as shown, and
remove the camshaft brackets and camshafts.
NOTE:
Remove No.1 camshaft bracket b
