NISSAN TEANA 2014 Service Manual
ROCKER COVEREM-171
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
• Tighten the rocker cover bolts in two steps in the order as shown.
: Engine front
Rocker cover bolts
Ste

Page 2170 of 4801

NISSAN TEANA 2014 Service Manual
EM-172
< REMOVAL AND INSTALLATION >[VQ35DE]
INTAKE VALVE TIMING CONTROL
INTAKE VALVE TIMING CONTROL
Exploded ViewINFOID:0000000009460559
Intake Valve Timing Control
Solenoid Valve (LH) (bank 2)INFOI

Page 2171 of 4801

NISSAN TEANA 2014 Service Manual
INTAKE VALVE TIMING CONTROLEM-173
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
5. Remove intake valve timing control solenoid valve (LH) (bank 2) and O-ring from intake valv

Page 2172 of 4801

NISSAN TEANA 2014 Service Manual
EM-174
< REMOVAL AND INSTALLATION >[VQ35DE]
FRONT TIMING CHAIN CASE
FRONT TIMING CHAIN CASE
Exploded ViewINFOID:0000000009460562
Removal and InstallationINFOID:0000000009460563
NOTE:
• This sectio

Page 2173 of 4801

NISSAN TEANA 2014 Service Manual
FRONT TIMING CHAIN CASEEM-175
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
REMOVAL
1. Remove engine under cover. Refer to
EXT-28, "Removal and Installation".
2. Drain the

FRONT TIMING CHAIN CASEEM-175
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
REMOVAL
1. Remove engine under cover. Refer to
EXT-28, "Removal and Installation".
2. Drain the engine coolant from the radiator. Refer to MA-23, "ENGINE COOLANT : Changing Engine Cool-
ant".
3. Drain the engine oil. Refer to MA-27, "ENGINE OIL : Changing Engine Oil"
.
4. Drain the power steering fluid. Refer to ST-30, "Draining and Refilling"
.
5. Remove engine room cover. Refer to EM-143, "Removal and Installation"
.
6. Remove front air duct. Refer to EM-144, "Removal and Installation"
.
7. Remove battery tray. Refer to PG-74, "Removal and Installation (Battery Tray)"
.
8. Remove the hood ledge covers (LH/RH).
9. Remove cowl top and cowl top extension. Refer to EXT-24, "Removal and Installation"
.
10. Remove upper radiator hose.
11. Disconnect engine coolant reservoir hose from t he radiator and remove engine coolant reservoir.
12. Remove cooling fan assembly. Refer to CO-42, "Removal and Installation"
.
13. Disconnect lower radiator hose from engine.
14. Remove the radiator. Refer to CO-41, "Removal and Installation"
.
15. Disconnect the power steering fluid reservoir tank hose from the power steering pump and fluid cooler and
remove the power steering fluid reservoir tank. Refer to ST-38, "Exploded View"
.
16. Remove the front RH wheel and tire. Refer to MA-39, "WHEELS : Adjustment"
.
17. Remove the fender protector side cover (RH). Refer to EXT-26, "FENDER PROTECTOR : Removal and
Installation".
18. Remove the drive belt. Refer to EM-134, "Removal and Installation"
.
19. Remove the rocker covers, if necessary. Refer to EM-168, "Removal and Installation LH"
and EM-169,
"Removal and Installation RH".
NOTE:
Necessary only when removing timing chains.
20. If removing the timing chains, obtain compression TDC of No. 1 cylinder as follows:
a. Rotate crankshaft pulley clockwise to align timing mark (grooved line without color) with timing indicator.
b. Check that intake and exhaust camshaft lobes on No. 1 cylinder (right bank of engine) are located as shown.
• If not, turn the crankshaft one revolution (360 °) and align as
shown.
21. Remove the access plate and lock the ring gear using Tool. CAUTION:
JMBIA1135GB
SEM418G
Tool number : — (J-50288)
Revision: November 20132014 Altima NAM

Page 2174 of 4801

NISSAN TEANA 2014 Service Manual
EM-176
< REMOVAL AND INSTALLATION >[VQ35DE]
FRONT TIMING CHAIN CASE
Do not damage the ring gear teeth, or the signal
plate teeth behind the ring gear, when installing
Tool.
22. Remove the crankshaft

EM-176
< REMOVAL AND INSTALLATION >[VQ35DE]
FRONT TIMING CHAIN CASE
Do not damage the ring gear teeth, or the signal
plate teeth behind the ring gear, when installing
Tool.
22. Remove the crankshaft pulley as follows:
a. Loosen crankshaft pulley and locate bolt seating surfac e at 10 mm (0.39 in) from its original position.
b. Position a pulley puller at recess hole of crankshaft pulley to remove crankshaft pulley.
CAUTION:
Do not use a puller claw on crankshaft pulley periphery.
23. Remove the power steering pump. Refer to ST-38, "Removal and Installation"
.
24. Remove the lower oil pan. Refer to EM-156, "Removal and Installation (Lower Oil Pan)"
.
25. Remove upper oil pan bolts (1) and (2) as shown. Refer to EM-
157, "Removal and Installation (Upper Oil Pan)".
26. Remove the generator. Refer to CHG-32, "Removal and Installation"
.
27. Disconnect the A/C tubes from the A/C compressor and position aside. Refer to HA-23, "Recycle Refriger-
ant".
28. Remove the A/C compressor bolts and the A/C compressor. Refer to HA-30, "COMPRESSOR : Removal
and Installation".
29. Remove the generator bracket. Refer to CHG-32, "Removal and Installation"
.
30. Support the engine with suitable jack and remove the RH engine insulator, mount and torque rod. Refer to EM-220, "Removal and Installation"
.
31. Disconnect the oil pressure switch harness connector.
32. Disconnect the intake valve timing control solenoid valve harness connector.
33. Remove the intake valve timing control solenoid valve cover bank 1 (RH) (A) and intake timing control solenoid valve cover
bank 2 (LH) (B).
• Loosen the intake valve timing control solenoid valve cover bolts in the reverse order as shown.
CAUTION:
The shaft in the intake valve ti ming control solenoid valve
cover is inserted into the center hole of the intake cam-
shaft sprocket. Remove the in take valve timing control
solenoid valve cover by pull ing straight out until the
intake valve timing control so lenoid valve cover disengages from the camshaft sprocket.
34. Remove the drive belt auto-tensioner. Refer to EM-134, "Removal and Installation"
.
35. If necessary, remove the water pump cover.
EMQ0477D
WBIA0259E
(C) : Dowel pin hole
JPBIA1639ZZ
Revision: November 20132014 Altima NAM

Page 2175 of 4801

NISSAN TEANA 2014 Service Manual
FRONT TIMING CHAIN CASEEM-177
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
36. Remove the front timing chain case.
a. Loosen the front timing chain case bolts in the order

Page 2176 of 4801

NISSAN TEANA 2014 Service Manual
EM-178
< REMOVAL AND INSTALLATION >[VQ35DE]
FRONT TIMING CHAIN CASE
40. Use a scraper to remove all of the old Silicone RTV Sealant from
the front timing chain case and opposite mating surfaces.
CAU
