Page 3553 of 4801

NISSAN TEANA 2014 Service Manual
PWC-46
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW MOTOR
4. Check continuity between rear power window switch RH connector D303 and ground.
Is the inspection result normal?
YES

Page 3554 of 4801

NISSAN TEANA 2014 Service Manual
ENCODERPWC-47
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
ENCODER
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000009460865
Detects condition of the fr

Page 3555 of 4801

NISSAN TEANA 2014 Service Manual
PWC-48
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
ENCODER
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3. CHECK HARNESS CONTINUITY 1
1. Turn ignition switch OFF.
2. Disco

PWC-48
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
ENCODER
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3. CHECK HARNESS CONTINUITY 1
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unl ock switch and front power window motor LH.
3. Check continuity between main power window and door lock/unlock switch connector D12 and front power window motor connector D9.
4. Check continuity between main power window and door lock/unlock switch connector D12 and ground.
Is the inspection result normal?
YES >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-49, "DRIVER SIDE : Special Repair Requirement".
NO >> Repair or replace harness or connectors.
4. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front power window motor LH.
3. Check continuity between front power window motor LH connector D9 and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5. CHECK HARNESS CONTINUITY 2
1. Disconnect main power window and door lock/unlock switch.
2. Check continuity between main power window and door lock/unlock switch connector D12 and front
power window motor LH connector D9.
Is the inspection result normal?
YES >> Check main power window and door lock/unlock switch. Refer to PWC-33, "POWER WINDOW
MAIN SWITCH : Component Inspection".
NO >> Repair or replace the harness or connectors.
6. CHECK HARNESS CONTINUITY 3
1. Disconnect main power window and door lock/unlock switch.
Te r m i n a l
Vo l ta g e
(Approx.)
(+)
(–)
Front power window motor LH connector Terminal
D9 2 Ground 10
Main power window and door lock/unlock switch connector Te r m i n a lFront power window motor LH
connector Terminal Continuity
D12 14 D9 2 Yes
Main power window and door lock/unlock switch con- nector Te r m i n a l
GroundContinuity
D12 14 No
Front power window motor LH connector Terminal GroundContinuity
D9 4 Yes
Main power window and door lock/un- lock switch connector Te r m i n a lFront power window motor LH
connector Terminal Continuity
D12 12D94Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3556 of 4801

NISSAN TEANA 2014 Service Manual
ENCODERPWC-49
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
2. Check continuity between main power window D12 and door lock/unlock switch connector and fro

Page 3557 of 4801

NISSAN TEANA 2014 Service Manual
PWC-50
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
DOOR SWITCH
DOOR SWITCH
DescriptionINFOID:0000000009460869
Detects door open/close condition.
Component Function CheckINFOID:000000000946087

Page 3558 of 4801

NISSAN TEANA 2014 Service Manual
DOOR SWITCHPWC-51
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM c

Page 3559 of 4801

NISSAN TEANA 2014 Service Manual
PWC-52
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW LOCK SWITCH
POWER WINDOW LOCK SWITCH
DescriptionINFOID:0000000009460873
Ground circuit of main power window and door lock/unloc

Page 3560 of 4801

NISSAN TEANA 2014 Service Manual
POWER WINDOWS DO NOT OPERATE WITH ANY POWER WINDOW SWITCH-
ES
PWC-53
< SYMPTOM DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
SYMPTOM DIAGNOSIS
POWER WINDOWS DO NOT OPERAT
